Assembly Instructions
Tristan Desk
SKU - 566668
THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTION PERTAINING TO THE
ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT THE NEAREST COST PLUS WORLD
MARKET STORE. IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL
CENTER TOLL FREE AT 877- 967- 5362 FOR ASSISTANCE.
NOT FOR COMMERCIAL USE.
Page 1
Advertisement
Table of Contents
Related Manuals for World Market 566668
Summary of Contents for World Market 566668
- Page 1 Assembly Instructions Tristan Desk SKU - 566668 THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTION PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT THE NEAREST COST PLUS WORLD MARKET STORE. IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOMER SERVICE CALL CENTER TOLL FREE AT 877- 967- 5362 FOR ASSISTANCE.
-
Page 2: Component List
Component List LABEL DESCRIPTION Hutch Desk Top Leg 1 Leg 2 Stretcher Page 2... -
Page 3: Hardware List
Hardware List LABEL DESCRIPTION Short Bolt M6 x 35mm Spring Washer M6 x 11mm Large Flat Washer M6 x 18mm Long Bolt M6 x 70mm Small Flat Washer M6 x 13mm Cam Bolt M7 x 38mm Cam Lock M15 x 13mm ANTI TIPPING KIT CHECK LIST CODE COMPONENT... -
Page 4: Assembly Preparation
Assembly Preparation Before Beginning: Unpack all hardware bags and components to ensure you have all parts. Read instructions, cover to cover. Have 2 adults on hand for assembly. Do not assemble on flooring or carpet. Assemble on a clean non-marring surface (packing foam). Save all packaging until finished. -
Page 5: Assembly Steps
Assembly Steps Step 1: 2X SIDE (H-1) Short Bolt M6 x 35mm 12 PCS (H-2) Spring Washer M6 x 11mm 12 PCS (H-3) Flat Washer M6 x 18mm 12 PCS (T-1) Allen Key M4 x 30 x 110mm 1 PC * Position and align Leg 2 (D) onto the corresponding side of the Desk Top (B). - Page 6 Assembly Steps Step 3: 2X CORNERS (T-2) Phillips Screwdriver (Not Provided) 1 PC 4 PCS (H-6) Cam Bolt M7 x 38mm * Turn the assembled desk up right. Avoid placing pressure on any legs while turning it. * Install 4 pieces Cam Bolts (H-6) into the Desk Top (B) as shown. Fully tighten all Cam Bolts using a Phillips Screwdriver (T-2), not provided.
- Page 7 Assembly Steps Step 5: Adjust levelers on legs if needed for stability. * Tristan Desk is now ready to use. Page 7...
- Page 8 Assembly Steps Anti Tip Kit Installation Instruction: 1. Attach mounting brackets (05) securely near the back edges of the furniture piece with the short screw (02). Refer to picture B. 2. Determine the final position of the furniture piece. Mark location on the wall approximately 2" below the brackets mounted to the back of the furniture.
-
