Summary of Contents for Fisher Scientific Isotemp 500 Series
- Page 1 Instruction Manual Fisher 500 Series Isotemp Incubator Model 506D (Small) 11-690-506D (120V) 11-690-507D (240V) Model (Large) 11-690-516D (120V) 11-690-517D (240V) Manual Part Number 103044 Rev C Date 12/2002...
- Page 2 to be a shelf. Do not set items directly on heater cover. The Fisher 500 series Isotemp Incubators are compact and temperature of this surface is greater than set temperature. economically priced units. Designed to handle most of the basic heating applications in the laboratory.
- Page 3 SERVICE 4. Remove the 4 screws that secure the control board to the front panel. Fisher 500 Series Isotemp Incubators are fabricated of high- quality long-life components. However, even with normal use, Note: Mark the leads so that reconnection to the replacement certain parts may need to be replaced.
- Page 4 See Defective thermocouple above. Defective controller. See Defective thermocouple above. Figure 1 Schematics ACCESSORIES Item Catalog Number 11-682-30 Thermometer, 40° to 240°C Fisher Scientific Assistance Shelf for: Fisher Technical Service: 1-800-926-0505 11-690-506D, -507D 13-245-6S Fisher Service Division: 1-800-395-5442 11-690-516D, -517D 13-245-15S...
