Summary of Contents for STM 1701054
- Page 1 5:1 High Ratio Oil Pump Manual...
- Page 2 Profile Oil pumps can be used to transfer lubrication oil, waste oil and antifreeze liquids. This manual is applicable to the following pump only, please confirm your pump is included. Specification Item No. 1701054 1701055 1701056 Compression Ratio Operating Pressure(bar/psi) 5-8 / 70-115 Max.
- Page 3 5:1 Series Oil Pump Exploded View of 7...
- Page 4 5:1 Series Oil Pump Part List Appendix Code Name Quantity Code Name Quantity Air motor cover Side cover Air motor shell inside Outlet Slider Suction tube Bracket Spring circlip Air center cover Valve seat Press piece Filter Slider Quick coupling Securing washer Silencer Goasket...
- Page 5 Storage and Maintenance Pumps are delivered in appropriate carton boxes. Packaging material should be properly disposed. Handling and storage of the new pump do not require any special procedures. However after the pump has been used, empty the used oil in the suction tube into an appropriate container.
- Page 6 onto the ground Never point the pistol at people or object. Press the pistol knob Always cut off the air supply after use so that oil can’t leak out in case one of the pump’s components should break Use only original spare parts in case the pump has to be repaired or its components have to be replaced Empty all the oil from the pump in case it has to be disposed of 10.
- Page 7 Wall Installed Part List Code Name Quantity Oil pump Wall bracket Pump adapter Flexible suction hose Suction hose adapter Bung adapter Rigid suction tube Spring circlip Ball Valve seat Filter Proceed As Follows Secure the bracket to the wall using the dowels at about 1200mm height appropriate for the tank’s dimensions.
- Page 8 Extension Transfer Part List Code Name Quantity Oil pump Bung adapter Top connection Extension 500mm tube Extension sleeve Extension 200mm tube Foot connection Foot valve Filter Proceed as follows Depending on the length of the suction tube the desired extension length. Can be realized by using the modular extension elements (See the examples given above) Example of possible application to pump with drum or rigid suction tube for obtaining personalized lengths according to needs.
