Summary of Contents for STM DITI1701033
- Page 2 THE MANUAL OF OIL PUMP Read the following precautions and instructions before you begin assembly or using. Failure to comply with these instructions could result in personal injury or property damage. Keep these instructions in a convenient location for future reference. IMPORTANT NOTE The guarantee will be void if the pump has been altered in any way PROFILE...
- Page 3 3:1 SERIES OIL PUMP EXPLODED VIEW...
-
Page 4: Troubleshooting
3:1 SERIES OIL PUMP PART LIST Appendix Quantity Quantity Name Name Code Code Air motor cover Spring Piston Spring seat Air motor shell inside Trip shoe guide Air motor shell outside Press piece Bracket Air control center Outlet Slider Gasket Soft gasket Ball Securing washer... -
Page 5: Storage And Maintenance
STORAGE AND MAINTENANCE Pumps are delivered in appropriate cardboard boxes. Packaging material should be properly disposed. Handling and storage of the new pump do not require any special procedures. However after the pump has been used, empty the used oil in the suction tube into an appropriate container. -
Page 6: How To Use
HOW TO USE DIRECTLY FITTED PUMPS INTO THE DRUM 1. Insert the suction tube of pump into the drum and secure with ring nut, suitable for commercial drums with 57 diameter hole and threading 2''BSP 2. Fit a oil delivery tube for oil outlet of the air operated pump using only high quality tubes (normally 1/2'' or 3/4'', according to DIN-SAE norms), by means of 1/2''BSP threading fitting. -
Page 7: Proceed As Follows
PROCEED AS FOLLOWS: 1. Secure the bracket to the wall using the dowels at about 1200mm height appropriate for the tank's dimensions. Make sure that the wall is solid and thick enough for the dowels. Do not interfere with hydraulic tubes or electric lines. 2. - Page 8 PROCEED AS FOLLOWS: 1. Depending on the length of the suction tube the desired extension length. Can be realized by using the modular extension elements( See the examples given Above) 2. Examples of possible application to pump with drum or rigid suction tube for Obtaining personalized lengths according to needs.
- Page 9 THE MANUAL OF OIL PUMP DISTRIBUTION KITS PRESSURE RELIEF PROCEDURE To reduce the risk of serious bodily injury, including fluid injection, splashing in the eyes or on the skin, or injury from moving parts, please always follow this procedure whenever you shut off the pump, when check or service any part of the spray/dispensing system, when install, clean or chang spray tips/nozzles, and whenever you stop spraying/dispensing.
