STEP 4
Attach Top Panel (D) on top of the unit using
Screw (1), Dowel (2) and Cam-lock
Screw/Nut (5) as shown.
D
(5)x 1pcs
(2)x 4pcs
(1)x 2pcs
E
F
A
E
E
D
STEP 6
Attach Right Side Panel (B) to assembled unit
using Screw (1), Dowel (2) as shown.
Recommended Maximum Weight
10
10
10
10
10
*Unit in Pound(lbs)
10
10
STEP 5
Insert another Back Panel (F) to assembled unit.
D
E
F
E
D
STEP 7
7.1 Attach Back Panel (F) to the back of
assembled unit using L-Support/ Screw (3).
7.2 Cover screw head with Sticker (4).
(3)x 4pcs
F
F
F
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
Approx. 30 minutes
Recomm. 2 Person
Tool Required
Customer Support
NEED HELP? For replacement requests or product inquiries,
please contact our Customer Service Team by emailing us at
support@furinno.com. Thank you for selecting Furinno!
www.furinno.com
Assembly Instruction
Furinno
7-Cube Open Shelf
11048WH
MODEL
:
1104820180406
