STEP 4
Attach Top Panel (D) on top of the assembled unit
using Screw (1).
D
(1)x 4pcs
E
A
E
E
D
STEP 6
Attach Back Panel (F) to the back of assembled unit with Power Pin (2) using rubber mallet.
Recommended Maximum Weight
10
10
10
10
10
*Unit in Pound(lbs)
10
10
STEP 5
Attach Right Side Panel (B) to assembled unit
using Screw (1).
(1)x 8pcs
D
E
E
D
(2)x 20pcs
F
F
WARNING:
>This unit has been designed to support the
maximum loads shown. Exceeding these
load limits could cause sagging, instability,
product collapse, and/or serious injury.
>DO NOT allow children to climb on unit.
>Put heavier items on lower shelves.
B
Approx. 30 minutes
Recomm. 2 Person
Tools Required
www.furinno.com
Assembly Instruction
Furinno
7-Cube Reversible Open Shelf
MODEL
:
Customer Support
NEED HELP? For replacement requests or product inquiries,
please contact our Customer Service Team by emailing us at
support@furinno.com. Thank you for selecting Furinno!
11048WH-PI
11048WH-PI20180406
