STEP 5
Attach Right Side Panel (E) to assembled unit
using Screw (1), as shown.
STEP 7
7.1 Install Nail Leg (9) to Panel (D) & (E).
7.2 Attach Back Panel (K) to the back of
assembled unit using Power Pin (10).
STEP 6
6.1 Attach Leg Panel (J) to Panel (E) and Shelf
Panel (H) to Panel (G).
6.2 Attach Left Side Panel (D) to assembled unit
using Screw (1).
STEP 8
8.1 Attach Door Panel (I) to Panel (A)& (B), make
sure Door Holder (4) into the hole.
8.2 Install Handle (7) to Door Panel (I) using
Screw (8).
8.3 Attach Bins (11) to the Shelf.
* Recommended max. weight for every shelf is 15 lbs.
its Space. its Budget
Approx. 30 minutes
Recomm. 1 Person
Tool Required
Tool Required
Customer Service
Tel/Fax: 281.500.9372
Toll Free: 773.299.8111 (Mon - Fri 9am - 5pm)
Email: support@furinno.com
www.furinno.com
Assembly Instruction
Furinno 11068 Living Storage Cabinet
with Bins and Door
11068
MODEL
:
DIMENSION :
23.6"(W) x 31.5"(H) x 11.6"(D)
1106820140919
