Parts List
NOTE:
This mount is shipped with all proper installation hardware and components. Make sure that none of
these parts are missing and/or damaged before beginning installation. If there are parts missing
and/or damaged, please stop the installation and contact Premier Mounts (800-368-9700).
Upper Assembly
(Qty 1)
Plastic Barrel Caps
(Qty 4)
Lag Screws
(#14 x 2")
(Qty 3)
M3 x 16mm
Phillips Head
Screws (Qty 4)
Installation Tools
Phillips Head Screw Driver
Soft Material/ Blanket
Allen Wrench (Supplied)
Tape Measure
Ladder
NOTE:
Mounting screws will vary by projector. Please see the following pages for model specific hardware:
Pages 10, 11, 12, and 13.
Installation Manual
Mounting Bracket
(Qty 1)
M3 Flat Washers
(Qty 4)
Note: Must be used
with the M3 x 16
Phillips screws.
M4 x 12 Security
Head Screws
(Qty 4)
NOTE: The following hardware is included in the hardware
pack but is not required for the installation.
M5 x 12mm Security Head Screws (Qty 4)
M6 x 12mm Security Head Screws (Qty 4)
Portable Drill
Pencil
Level (Supplied)
Stud Finder (Commercially Available)
M5 Allen Wrench
