H-4601
LOW PROFILE FLOOR
SCALE PRINTER
WARNING!
Avoid using the printer in any harsh
environment.
Only trained professionals are allowed to do
repair work.
Turn power off before connecting or
disconnecting the power source.
Do not spill liquids on the printer.

PRINTER SETUP WITH LP-7510 / DISPLAY INDICATOR

1.
With the LP-7510 display on and displaying weight,
press the PRINT and TOTAL buttons at the same time
to get into Setup. Display should now show
a. Use the LB/KG and GROSS buttons to move the
flashing digit left or right.
b. Use the TARE and ZERO buttons to increase and
decrease the flashing digit.
2. Change the display to show
PRINT (Enter) button.
a. Display shows the date in Y/M/D format.
b. Enter the correct date and press the PRINT (Enter)
button.
PAGE 1 OF 6
1-800-295-5510
uline.com

OVERVIEW

SETUP

C 01
.
C 16
and press the

PREPARATION

1. Carefully remove contents from the package.
2. Connect the interface cable (included) from the
printer to the RS-232 serial port of the indicator.
Tighten the screws on both sides.
3. Turn the printer's ON/OFF switch to the off position.
4. Plug in the power adapter from the printer to a
surge-protected power outlet.
5. Turn the printer's ON/OFF switch to the on position.
C 17
3. Display shows
. Press the PRINT (Enter) button.
a. Display shows the time in H/M/S format.
b. Enter the correct time and press the PRINT (Enter)
button.
C 18
4. Display shows
. Press the PRINT (Enter) button.
C 18
a. Display shows
b. Change the number on the right to "2" and press
the PRINT (Enter) button. The number 2 indicates
that the printer is connected.
C 19
5. Display shows
. Press the PRINT (Enter) button.
C 19
a. Display shows
b. Change the number on the right to a "3" and
press the PRINT (Enter) button. The number 3
signifies the 9600 BaudRate.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
and a number on the right.
and a number on the right.
0621 IH-4601
