  • Page 1: Table Of Contents

    Troubleshooting Cleaning Specifications General information Thank you for purchasing a Panasonic product. Please read this manual before using the product and save it for future reference. 1-62, 4-chome, Minoshima, Hakata-ku, Fukuoka 812-8531, Japan http://www.panasonic.net/ © Panasonic System Networks Co., Ltd. 2013...

  • Page 2: Model No

    Introduction This product is an additional product designed to be used with the following Panasonic Video Intercom Systems. – VL-SWD501BX/VL-SWD501UBX (Main monitor station: VL-MWD501BX) (The corresponding models are subject to change without notice.) R By installing this product, you can extend the range of your Video Intercom System to include areas where reception was previously not available.

  • Page 3: Accessory Information

    Signal range and repeater installation example n Using each repeater connected separately n Using 2 repeaters connected together This extends signals away from the main monitor. This extends the signal away from the main Because signals are sent through the main monitor by sending signals directly between monitor, different types of devices can be repeaters.

  • Page 4: For Your Safety

    R Unplug the product from the power outlet if the For your safety product emits smoke, an abnormal smell or makes unusual noise, or if the product has been dropped or physically damaged. These To prevent severe injury and loss of life/property, conditions can cause fire or electric shock.

  • Page 5: Important Safety Instructions

    Location/avoiding noise interrupted transmissions, distorted images and slow image refresh rates. Obstructions can The repeater and other compatible Panasonic include: units use radio waves to communicate with each – Metal doors or metal shutters.
  • Page 6 These symbols are only valid in the European Union. If you wish to discard these items, please contact your local authorities or dealer and ask for the correct method of disposal. Others R It is prohibited to disassemble or modify this product.

  • Page 7: Controls

    Controls indicator indicator C PROGRAM Understanding the indicator and indicator Indicator Light status Meaning Lit green Registration with the main monitor is complete and the repeater can send signals. Flashing Signals are being sent. indicator green Lit orange Signals are not being sent. Flashing Currently registering to the main monitor.

  • Page 8: Installation/Registering The Repeater To The Main Monitor

    Installation/Registering the repeater to the main monitor Repeater: Connect the AC adaptor, and plug the AC adaptor into a power outlet. R Use only the supplied Panasonic AC adaptor (® page 3). R When the repeater is turned on, the indicator lights in orange.

  • Page 9: Wall Mounting

    Wall mounting Make sure that the wall is strong enough to support the weight of the repeater. Place the reference for wall mounting on the wall to mark the 2 screw positions. Install the 2 screws (locally procured) into the wall. R Make sure that the screw heads are at the same distance from the wall.

  • Page 10: Troubleshooting

    Troubleshooting Problem Cause/solution The repeater does not work. R When the indicators do not light, the AC adaptor is not connected properly. Check the connections. R When the indicators do not light green, move the repeater closer to the main monitor. R When the indicator does not light, the registration with main monitor has not completed successfully.

  • Page 11: General Information

    Mass (weight) Approx. 88 g (excluding the AC adaptor) Operating environment Ambient temperature: approx. 0 °C to +40 °C Relative humidity (non-condensing): up to 90 % Frequency range 1.88 GHz to 1.90 GHz Transmitting range Approx. 100 m (line-of-sight distance from the main monitor) Note: R Design and specifications are subject to change without notice.
  • Page 12 Notes...
