Installation
Refer to your individual pump installation sheets for mounting diagrams.
The two inlets on the base of the dispenser are labelled A and B. Ensure that the inlet A is
connected to the (mineral) diesel tank and the inlet B is connected to the bio-diesel tank.
Dispensing Hose and Nozzles
The unit may or may not be supplied with dispensing hose and nozzle assemblies.
The dispensing equipment shall be installed to prevent the delivery hose from contacting the
ground when not in use.
If customer supplied hose assemblies, pylons, reels, safe breaks and nozzles are used they
must comply with the requirements outlined in AS/NZS 2229
Wiring
For general wiring instructions, refer to the C4000 Master Manual.
On the C4000 Power Supply the motors and solenoids are connected to the following terminals:
▪ Mineral pump motor is T1
▪ Mineral solenoids are T2 and T3
▪ Bio pump is T4
▪ Bio solenoids are T5 and T6
On the C4000 Board the meters are connected to the following terminals:
▪ Mineral meter plugs into J3
▪ Bio Diesel meter plugs into J4
Supply Pumps
The Bioblend gauge must always be 2 PSI higher than the diesel gauge. These can be adjusted
by setting supply pumps. The location of the gauges can be seen in Hydraulics (see page 12.)
11.
