Above Ground
Storage tank
CAUTION:
The pump inlet must not be pressurised at any time. This will cause fuel to flow from
the air eliminator. Unregulated connection to an above ground tank will cause pressurisation.
CAUTION:
For above ground tanks a regulator valve such as a Tokheim valve or similar device
MUST be used so that the inlet of the pump cannot become pressurised at any time.
NOTE: The air switch is not to be disconnected. Disconnection will void NSC and TMU approvals.
NOTE: The air eliminator chamber is not to be piped back to the tank. This will prevent it from
working and may damage the pump.
Shut-off valve
Solenoid valve
(wire so that valve
is open only when
the pump motor is
running)
Tokheim valve
(mounted directly
under pump)
8.
Shear section
level with bottom
of base
Pipe vent to top of
storage tank or vent
to atmosphere -
Do not plug
