ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7845Q/EK
DIFFICULT
Page 1 of 6
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
(Included)
(Not Included)
Rev: 18-08- 2 0

Advertisement

loading
Need help?

Need help?

Do you have a question about the CM7845Q/EK and is the answer not in the manual?

Questions and answers

Related Manuals for Furniture of America CM7845Q/EK

Summary of Contents for Furniture of America CM7845Q/EK

  • Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7845Q/EK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench assembling a specific product (with 1 being (Included) easy and 5 being difficult).
  • Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
  • Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 10pcs Headboard Bolt Ø5/16" x 1-3/4'' #2 x 2pcs #B x 10pcs Headboard Leg (L&R) Spring Washer Ø5/16"...
  • Page 4 Exploded View Align HB legs (#2R/L) to the headboard (#1) and HB support (#3) to HB legs (#2R/L). Secure by using bolts (#A) with washers (#B,C). #A x 10pcs #B x 10pcs #C x 10pcs Page 4 of 6...
  • Page 5 Align and hook the side rails (#5) into the latch of the headboard (#1) and footboard (#4). Align center slat support (#6) to the slat kit (#7), then secure by using support legs (#9). Adjust the leveler of the support legs (#9) according to ground level.
  • Page 6 Align slat kit (#7) to the side rails (#5), then secure by using screws (#D). #D x 26pcs Place dusty panel (#10) to the bed. Page 6 of 6...
