For more information contact our team: service.ec@foagrop.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7844F
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 6
(Included)
(Not Included)
Rev: 16-12-06
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7844F
Summary of Contents for Furniture of America CM7844F
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagrop.com CM7844F ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 8pcs Bolt Ø1/4"x3-1/8" Headboard Bookcase #2 x 1pc #B x 8pcs Barrel Nut Ø1/4"x1/2"...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Page 4 of 6...
- Page 5 Insert barrel nuts (#B) to the holes of the side rails (#3). Align side rails (#3) to the holes of the headboard bookcase (#1) and footboard (#2). Secure with bolts (#A) by inserting bolts (#A) to the barrel nuts (#B). #A x 8pcs #B x 8pcs Align support legs (#5) to the holes of the center support...
- Page 6 Align the slats kit (#6) to the side rails (#3) and the holes of the center support (#4). Secure with screws (#C). #C x 9pcs ASSEMBLY IS COMPLETED Page 6 of 6...
