- Page 1 Model 1335ET Revision 4.2 Updated Sept 19, 2016 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 • www.atlatt.com...
- Page 2 Technical Manual & Parts Lists Page...
- Page 3 Attachment Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials.
-
Page 4: Table Of Contents
Technical Manual & Parts Lists Contents Important Safety Instruction ........................1 Liability ..............................2 Safety Equipment on the Machines ......................3 Protective Eyewear ............................. 4 Important Notices............................5 Maintenance ..............................7 Repair ................................8 A Word to the End User..........................9 Safety Precautions ............................ - Page 5 Technical Manual & Parts Lists General Machine Maintenance ......................... 25 Daily ................................25 Weekly ..............................25 Reflective Tape Maintenance ........................25 1335M Folder Spacer Reference Chart ..................... 26 Assembly Drawings & Parts Lists ......................27 11335ET-RUFFLER WORK STATION, ECONOMY ................30 4059-FP301D FOOT PEDAL ASSY, EFKA ...................
-
Page 6: Important Safety Instruction
Technical Manual & Parts Lists Important Safety Instruction This part of the Instruction Material is provided for the safe use of your equipment. It contains important information to help work safely with the unit and describes the dangers inherent in machinery. Some of these dangers are obvious, while others are less evident. -
Page 7: Liability
Technical Manual & Parts Lists Our machines are designed and built in line with the state of the art and the accepted safety rules. However, all machines may endanger the life and limb of their users and/or third parties and be damaged or cause damage to other property, particularly if they are operated incorrectly or used for purposes other than those specified in the Instruction Manual. -
Page 8: Safety Equipment On The Machines
Technical Manual & Parts Lists the machine should only be carried out by skilled personnel, under the management and supervision of a duly qualified engineer. This not only applies when the machine is used for production, but also for special work associated with its operation (start-up and maintenance), especially when it concerns work on the hydraulic or electrical systems, as well as on the software/serial bus system. -
Page 9: Protective Eyewear
Technical Manual & Parts Lists If any changes capable of impairing safety are observed in the machine or its mode of operation, such as malfunctions, faults or changes in the machine or tools, appropriate steps must be taken immediately, the machine switched off and a proper lockout tagout procedure followed. -
Page 10: Important Notices
Technical Manual & Parts Lists Smoking and open flame (e.g. welding work) should be prohibited in the production area due to the risk of fire and explosions. Workplace A clear working area without any obstructions whatsoever is essential for safe operation of the machine. The floor should be level and clean, without any waste. - Page 11 The packaging and machine must immediately be examined for signs of damage in transit. Such damage must be reported to the shipper/transporter within the applicable time limits. Contact Atlanta Attachment Company and/or your transport insurer immediately, if signs of damage are visible. Never operate a damaged machine.
-
Page 12: Maintenance
Technical Manual & Parts Lists Transporting the Machine Disconnect the machine from all external connections and secure any loose assemblies or parts. Never step under a suspended load. When transporting the machine or assemblies in a crate, ensure that the ropes or arms of a forklift truck are positioned as close to the edge of the crate as possible. -
Page 13: Repair
Technical Manual & Parts Lists Retighten all screw connections that have to be loosened for the maintenance and repair work. Any safety mechanisms that have to be dismantled for setting-up, maintenance or repair purposes must be refitted and checked immediately after completing the work. Maintenance, Care, Adjustment The activities and intervals specified in the Instruction Manual for carrying out adjustments, maintenance and inspections must be observed and parts replaced as specified. -
Page 14: A Word To The End User
Technical Manual & Parts Lists The electrical equipment of our machines must be checked at regular intervals and any defects found must be remedied immediately. If it is necessary to carry out work on live parts, a second person should be on hand to operate the emergency OFF switch or master switch with voltage release in the event of an emergency. -
Page 15: General Machine Data
Technical Manual & Parts Lists It is the owner’s responsibility to make certain that the operator reads and understands this manual before operating this equipment. It is also the owner’s responsibility to make certain that the operator is a qualified and physically able individual, properly trained in the operation of this equipment. -
Page 16: Control Box Operation
Technical Manual & Parts Lists Control Box Operation Main Control Box: The front of the main control box has an Auto/Manual Switch, a Manual Ruffle Pushbutton, an Unwinder Reverse Switch, a Fuse Holder, and 6 Thumbwheels. On the back is the power entry socket and an on/off switch. Be sure the on/off switch is always Note: The on/off switch only switches one line and does not make the box safe to work on. -
Page 17: Ruffler Control Box
Technical Manual & Parts Lists The back of the box has an on/off switch, fuse, and cables. Leave the on/off switch on all the time. When working on the box always disconnect the power cord before servicing. Mini Switch (SW1) ... - Page 18 Technical Manual & Parts Lists Thumbwheel 2 controls the sewing speed of the sewing head during ruffling. Each increment is approximately 100 rpm. The normal setting is “6”. Thumbwheels 3 and 4 together make up the Stop count for the corners. This is the stitch count (00‐99 stitches) from when the front eye uncovers until the sewing stops in the corner to start the ruffling cycle.
-
Page 19: Eyes
Technical Manual & Parts Lists The door on the left side of the ruffler control box gives access to the electronic components. The on/off switch (1), the unwinder relay (2), the computer board (3), the thumbwheels (4), the valve assembly (5), the WAGO blocks (6). Do not service this part of the machine while power is still connected. -
Page 20: Efka Motor
Technical Manual & Parts Lists head. The Hand wheel eye (1) reads a piece of reflective tape located on the pulley disks (2). The Hand wheel eye is responsible for reporting to the Efka motor that the sewing head is sewing at the set RPM, stitch counting for all counters, and for needle position when stopping. -
Page 21: Programming
Technical Manual & Parts Lists Programming 1) Press and hold the “P” button while turning on the Main Power Switch. 2) Once “cod” (short for code) appears in the display release the “P” button and press the “>>” button. The code to enter in is “311” 3) 000 will appear on the display with the left 0 blinking. - Page 22 Technical Manual & Parts Lists 4) Display should look like picture to the left with the middle “0” blinking, if not press the “>>” button until the middle “0”is blinking. Press the “+” button once to get a “1” as the middle number. Then press the “>>”...
- Page 23 Technical Manual & Parts Lists Page...
- Page 24 Technical Manual & Parts Lists 7) The display will change to “2.0.0.” this is a parameter number “200”. Any number with the “.” between the digits will be a parameter. To move o the correct parameter you will press either the “+” or “‐”...
- Page 25 Technical Manual & Parts Lists Page...
- Page 26 Technical Manual & Parts Lists 10) The display will show “2.9.1.”, this is the next parameter after “290”. You will use the “+” or “-” buttons to advance to the next parameter on the list, then follow the process in step 9. Continue this until all parameters have been set according to the programming sheet.
-
Page 27: Basic Machine Operation
Technical Manual & Parts Lists Basic Machine Operation Loading the Roll Holder Remove the outer disc from the upper rod. Place a roll of material on the rod and replace the outer disc. Feed the material over the top roller and down to the folder with the good side toward the sewing head. -
Page 28: Loading The Panel
Technical Manual & Parts Lists Loading the Panel Heal back the treadle or step on the foot lift pedal to raise the presser foot. Swing in the stripper blade and the folder/ruffler assembly. Be sure the sensor at the back of the swing-out bracket is lit indicating that the bracket is all the way in to the detent. -
Page 29: Finishing The Panel
Technical Manual & Parts Lists Finishing the Panel After the last corner, sew the panel until the starting edge of the gusset is almost to the presser foot. Stop and activate the “Wipe” switch to raise the folder. Cut the gusset so that there is enough overlap of gusset for finishing. -
Page 30: Puller Drive
Technical Manual & Parts Lists The swing-out stripper blade protects the panel from the ruffler blade while ruffling so that the panel does not get pleated by the blade. It should be positioned as close to the presser foot as possible. The ruffling air pressure should be set as high as practical without it pressing the stripper blade down and pinching the panel while turning. -
Page 31: 1335M Folder Spacer Reference Chart
Technical Manual & Parts Lists 1335M Folder Spacer Reference Chart Page... -
Page 32: Assembly Drawings & Parts Lists
Company. In addition to any confidentiality and non-disclosure obligations that currently exist between you and Atlanta Attachment Company, your use of these materials serves as an acknowledgment of the confidential and proprietary nature of these materials and your duty not to make any unauthorized use or disclosure of these materials. - Page 33 Technical Manual & Parts Lists Page...
- Page 34 Technical Manual & Parts Lists Page...
-
Page 35: 11335Et-Ruffler Work Station, Economy
Technical Manual & Parts Lists 11335ET-RUFFLER WORK STATION, ECONOMY AAC Drawing Number 9004646 Rev 0 NO QTY PART # DESCRIPTION 4059-FP301D FOOT PEDAL ASSY,EFKA 1325145 BASE CONSOLE,TYPICAL 1335930 ROLLHOLDER ASSY,OVERHEAD NNK1/4-20 NUT,KEP,1/4-20 SSHC01144 HEX HEAD BOLTS WWFS1/4 WASHER,FLAT,SAE,1/4 Page... - Page 36 Technical Manual & Parts Lists Page...
-
Page 37: 4059-Fp301D Foot Pedal Assy, Efka
Technical Manual & Parts Lists 4059-FP301D FOOT PEDAL ASSY, EFKA AAC Drawing Number 9000033 Rev 5 PART # DESCRIPTION 4059-EB301A ACTUATOR,TREADLE,9 PIN 26058 ROD, STRAIGHT, 1018 4059030 BASE, FOOT PEDAL, 12X18 4059033 FOOT PEDAL WELDMENT A3502-4 FOOT PEDAL, BRACKET MM94807A029 PUSHNUT,ROUND,1/4 DIA NNJ3/8-16 3/8-16 JAM NUT NNK10-32... - Page 38 Technical Manual & Parts Lists Page...
-
Page 39: 1335930 Roll Holder Assy. Overhead
Technical Manual & Parts Lists 1335930 ROLL HOLDER ASSY. OVERHEAD AAC Drawing Number 1335930 Rev 4 NO QTY PART # DESCRIPTION 11200A BUMPER 5/16-24 1325-346A HOLDER, ROD, 3/4", SLOT 132556-273 LEG, 3/4 X 1-1/2 X 15 LG 1335-319B ARM, 1/2" ROD CLAMP 1335-825 DRAG TENSI ON ASSEMBLY 1335-835A... - Page 40 Technical Manual & Parts Lists Page...
-
Page 41: 1325145 Base Console, Typical
Technical Manual & Parts Lists 1325145 BASE CONSOLE, TYPICAL AAC Drawing Number 1325145 Rev 0 NO QTY PART # DESCRIPTION 1325144 SEW HEAD SUBASSEMBLY 1325165 STAND / MOTOR ASSY AR 1335MF-PD DIAGRAM, PNEUMATIC 1959-112 2 POS THREAD PLATE ASSY 26151 TOOL TRAY, 1X3.5X9 THREAD STAND, 2 THREAD ZX3833... - Page 42 Technical Manual & Parts Lists Page...
-
Page 43: 1325144 Sew Head Sub-Assembly
Technical Manual & Parts Lists 1325144 SEW HEAD SUB-ASSEMBLY AAC Drawing Number 1325144 Rev 1 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 1 1325146 SEW HEAD PLATE 1 AAFCT-11 CLEVI S, CYL, 5/16-24 ,1/4 1 1325147 SEWI NG HEAD, MODI FI ED 1 AAFP18 MUFFLER,1/8 NPT, BRONZ 1 1325148... - Page 44 Technical Manual & Parts Lists Page...
-
Page 45: 1325165 Stand / Motor Assy
Technical Manual & Parts Lists 1325165 STAND / MOTOR ASSY AAC Drawing Number 1325165 Rev 2 NO QTY PART # DESCRIPTION NO QTY PART # DESCRIPTION 0211-702A CABLE,POS. SENSOR,6' 34 2.8 FT EEDF2X2 DUCT,WI RE,2X2, MOD 1278-6689B BRACKET, EYE MOUNT FFHBL4579C RECEPTACLE,3 POLE,3W 1278-6718A... -
Page 46: 1325147 Sewing Head, Modified
Technical Manual & Parts Lists 1325147 SEWING HEAD, MODIFIED AAC Drawing Number 1325147 Rev 0 NO QTY PART # DESCRIPTION 1325164 FOOT LIFT ADJ - MOD 1325176 CLOTH PLATE NODIFIED STYP-GK321-12 SEWING HEAD WITH PULLER 321KIT01 OIL WICK KIT Page... -
Page 47: 1325173 Foot Pressure Assembly
Technical Manual & Parts Lists 1325173 FOOT PRESSURE ASSEMBLY AAC Drawing Number 1325173 Rev 0 NO QTY PART # DESCRIPTION 1335M-108 LEVER 1325171 MTG BRKT, FOOT LIFT AA198RR508 FLOW CONTROL,5/32 X 1/8" AAC7DP-.5 CYLINDER,AIR,DA AAFBP-11C BRKT,PIVOT,1/4 BORE AAFCT-7 HUMPHREY CLEVIS AAFP18 MUFFLER,1/8 NPT, BRONZ NNJ1/4-28... - Page 48 Technical Manual & Parts Lists Page...
-
Page 49: 1325148 Ruffler Assembly
Technical Manual & Parts Lists 1325148 RUFFLER ASSEMBLY AAC Drawing Number 1325148 Rev 0 Page... - Page 50 Technical Manual & Parts Lists Page...
-
Page 51: 1325160 Puller Sub-Assembly
Technical Manual & Parts Lists 1325160 PULLER SUB-ASSEMBLY AAC Drawing Number 1325160 Rev 2 Page... - Page 52 Technical Manual & Parts Lists Page...
-
Page 53: 1325175 Stripper Blade Assembly
Technical Manual & Parts Lists 1325175 STRIPPER BLADE ASSEMBLY AAC Drawing Number 1325175 Rev 0 Page... - Page 54 Technical Manual & Parts Lists Page...
-
Page 55: 1335Mf-500 Control Box Assembly
Technical Manual & Parts Lists 1335MF-500 CONTROL BOX ASSEMBLY AAC Drawing Number 192909B Page... -
Page 56: 1335Mf-Pd Pneumatic Diagram, 1335Mf
Technical Manual & Parts Lists 1335MF-PD PNEUMATIC DIAGRAM, 1335MF Page... -
Page 57: 1335Mf-Wd Wiring Diagram
Technical Manual & Parts Lists 1335MF-WD WIRING DIAGRAM Page... - Page 58 Atlanta Attachment Company (AAC) Statement of Warranty Manufactured Products Atlanta Attachment Company warrants manufactured products to be free from defects in material and workmanship for a period of eight hundred (800) hours of operation or one hundred (100) days whichever comes first. Atlanta Attachment Company warrants all electrical components of the Serial Bus System to be free from defects in material or workmanship for a period of thirty six (36) months.
- Page 59 Declaración de Garantía Productos Manufacturados Atlanta Attachment Company garantiza que los productos de fabricación son libres de defectos de mate-rial y de mano de obra durante un periodo de ochocientos (800) horas de operación o cien (100) días cual llegue primero.
- Page 60 Technical Manual & Parts Lists Atlanta Attachment Company 362 Industrial Park Drive Lawrenceville, GA 30046 770-963-7369 www.atlatt.com Printed in the USA Page...
