SimplyShade UA38278RLD-LS Manual

9 ft umbrella with led lights
Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
ITEM #0804782
9 FT UMBRELLA WITH LED LIGHTS
MODEL #UA38278RLD-LS
ATTACH YOUR RECEIPT HERE
Serial Number
Purchase Date
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1- 844-230-9904, 8 a.m. – 8 p.m., EST, Monday - Friday.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UA38278RLD-LS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SimplyShade UA38278RLD-LS

Summary of Contents for SimplyShade UA38278RLD-LS

  • Page 1 ITEM #0804782 9 FT UMBRELLA WITH LED LIGHTS MODEL #UA38278RLD-LS ATTACH YOUR RECEIPT HERE Serial Number Purchase Date Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1- 844-230-9904, 8 a.m. – 8 p.m., EST, Monday - Friday.
  • Page 2 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. Assemble on a soft, clean, non-abrasive surface to avoid scratching the metal finish or hurting the umbrella fabric. Always keep the umbrella in the closed position when not in use. Do not open the umbrella in high winds or windy conditions. Use a heavy or weighted umbrella base to stabilize the umbrella.
  • Page 3 INSTALLATION OVERVIEW Carefully remove the umbrella and all contents from the box. Locate the Finial (D) and the Solar Panel (C). Separate the Plastic Cap (F) from the Finial (D) by twisting the Cap (F) counter-clockwise approximately 1/4 turn and pulling apart. With the Cap (F) removed from the top of the Finial (D), line the tabs on the bottom of the Solar Panel (C) up with the slots inside the top of the Finial (D).
  • Page 4 INSTALLATION OVERVIEW push- Insert and secure the Bottom Pole (B) into an umbrella base (sold separately). Insert Umbrella (A) into the Bottom Pole (B) ensuring that the push-pin on the Umbrella (A) pole snaps securely into the Bottom Pole (B). OPERATION OVERVIEW Push Button Tilt open...
  • Page 5 OPERATION OVERVIEW 100V~240V AC On/Off Switch To operate the LED lights, press the rocker switch located on the crank housing on or off. NOTE: a) The Finial (D) contains two lithium batteries (2 x 2200mAh). Press the switch to the off position during daylight to allow the solar panel to charge the batteries.
  • Page 6 TROUBLESHOOTING PROBLEM POSSIBLE CAUSE 1. The solar panel, finial may not be properly installed. Remove the solar panel, finial and repeat Step 1 and 2, ensuring that the fixed barrel connectors line up correctly. The umbrella 2. The batteries may be dead. Press the switch to the OFF position. With the solar panel, finial lights only properly installed, allow approximately 8 hours of sunlight on the solar panel or 6 hours with the work when...
