2003
MITSUBISHI
LANCER
EVOLUTION VIII
BODY
REPAIR MANUAL
FOREWORD
This manual has been prepared for the use of all
service mechanics engaged in the body repair service.
Body
dimensions,
welded
procedures, body sealing application instructions, and
all the other information required to provide quick and
accurate body repair service are contained herein.
One especially important point is the welding method.
All of the vehicle's original strength and durability can
be maintained by following the welding procedures
contained in this manual.
Now that, in order to maximize the efficiency of the
repair work, first, both the extent of the damage and
the replacement parts that are needed must be
calculated accurately, and then the actual work must
be performed accurately and efficiently.
The publications shown on the following page are also
available, and should be used in conjunction with this
manual.
Mitsubishi Motors Corporation reserves the right to make changes in
design or to make additions to or improvements in its products without
imposing any obligations upon itself to install them on its products
previously manufactured.
ã2003 Mitsubishi Motors Corporation
GROUP INDEX
BODY CONSTRUCTION . . . . . . . . .
BODY DIMENSIONS . . . . . . . . . . . . .
WELDED PANEL REPLACEMENT. .
CORROSION PROTECTION . . . . . .
SYNTHETIC-RESIN PARTS . . . . . . .
BODY COLOR . . . . . . . . . . . . . . . . . .
panel
replacement
WIRING AND PIPING DIAGRAM . . .
REFERENCE MATERIAL . . . . . . . . .
BASE OF BODY REPAIR . . . . . . . . .
Printed in USA
Technical Information
Return to Main Menu
MSSP-260B-2003
1
2
3
4
5
6
7
8
9
