- Page 1 MicroSim COS Cardiac Output Simulator “The one and only that simulates a true waveform” Operating Manual Netech Corporation, 110 Toledo Street Farmingdale, NY 11735 Phone: 631-531-0100 Fax: 631-531-0101 http://www.Netech.Org...
-
Page 2: Warranty
The standard warranty is extended for a second year if the instrument is returned to Netech for its recommended yearly recalibration. During the warranty period, we will repair or, at our option,... -
Page 3: General Information
Copyright Copyright © 2007 by Netech Corporation. All rights reserved. No part of this publication may be reproduced or transmitted in any form other than for the purchaser’s personal use without written permission from Netech Corporation. -
Page 4: Return Procedure
United Parcel Service, Federal Express, or Air Parcel Post. We also recommend that you insure your shipment for its actual replacement cost. Netech Corporation will not be responsible for lost shipments or instruments that are received in damaged condition due to improper packaging or handling. Use the original carton and packaging material for shipment. -
Page 5: Electromagnetic Interface
Electromagnetic Interference FCC CLASS A (USA) MicroSim COS (Simulator Series) has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment EC Directive 04/108/EEC... -
Page 6: Ec Directive
EC Directive 73/23/EEC Low Voltage The system has been type tested and found to meet the requirements of EC Directive 73/23/EEC for Low Voltage. Verification of compliance was conducted to the limits and methods of the following: EN 61010-1... -
Page 7: Table Of Contents
Table of Contents Warranty General Information Return Procedure Electromagnetic Interface EC Directive Table of Contents 1. General Overview Introduction Specifications Accessories 2. Operating Instructions Getting Started Instrument Familiarity Controls and Menu Structure Operating COS 3. Troubleshooting 4. Appendix... -
Page 8: General Overview
Section 1 1.1 Introduction The MICROSIM COS is a compact cardiac out put simulator, designed to test and verify the functionality of most cardiac output monitors. It simulates an ideal cardiac output waveform for various preset values for selected Blood temperature and injectate temperatures. -
Page 9: Operating Instructions
If no damage is found to the shipping box, open the box and perform a visual inspection of the MICROSIM COS. If any damage to the unit is observed please contact Netech Customer Service. The Netech warranty statement is listed in the warranty section of this manual. -
Page 10: Controls And Menu Structure
2.3 Controls and Menu Structure Controls The control consists of four function keys F1 – F4, a left arrow (<), a right arrow (>), Esc key and power On/Off. Each function key is active based on the context of each menu. Function keys are assigned to selections appearing along the bottom line of the display. - Page 11 lower right as simulation starts. It provides a visual indication of the percentage of the elapsed waveform. During a simulation, the COS will not respond to any keys pressed. To show the simulation has completed, the progress bar will become a series of dashes as shown: B T : 3 7 °...
- Page 12 Injectate Temperature Select Menu I n j . t e m p : 5 ° C Injectate Temperature selections simulate the resistance of a Coset Probe thermistor. The two selections available are 5°C and 20°C. The current setting is displayed. Selecting a new value returns you to the Main Screen.
- Page 13 Diagnostic selections: • ROM (F1): Performs a ROM checksum to verify the integrity of the processor's memory. A pass/fail message will display. This function is also performed on power-up. • EP (F2): Performs a non-volatile memory (EEPROM) checksum to verify the integrity of the machine calibration constants. A pass/fail message will display.
-
Page 14: Operating Cos
Allow 10 seconds for the baseline to stabilize. Press the Start button on the monitor under test. Press Str (F4) on the MICROSIM COS to begin a waveform simulation. When the test is complete, verify the reading on the patient monitor. -
Page 15: Troubleshooting
Trouble Shooting Section 3 Error Codes • Error 1: Low Battery. Display reads, “Low Battery”, “Turn unit off.” The battery voltage has fallen below the safe operating limit and all functions have been disabled. Turn off the unit and replace the battery. -
Page 16: Appendix
Appendix Section 4...
