Delta 1600
User Manual
Intended Use: Delta 1600 AED Tester is a precision instrument that
simulates various cardiac waveforms and measures discharged energy.
It assures AEDs detect the waveforms, audibly advise shock, and
discharge energy as per manufacturer's specifications.
AED TESTER
(Automated External Defibrillator Tester)
Innovative Instruments Since 1987

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Delta 1600 and is the answer not in the manual?

Questions and answers

Related Manuals for Netech Delta 1600

Summary of Contents for Netech Delta 1600

  • Page 1 Delta 1600 User Manual Intended Use: Delta 1600 AED Tester is a precision instrument that simulates various cardiac waveforms and measures discharged energy. It assures AEDs detect the waveforms, audibly advise shock, and discharge energy as per manufacturer’s specifications. AED TESTER...

  • Page 2: Table Of Contents

    Energy Measurement..........6 General Specifications.......... 7 Part Numbers and Ordering Information....Preparation for Use..........Initial Setup.............. 12 Introduction............Shock Advisory Test..........13 AUTO Function Test..........15 ECG Simulation............... 16 Rate Selection ............Amplitude Selection..........Warranty................ 17 2 | Delta 1600 - Quick-Reference Manual...

  • Page 3: Notices

    If no damage is found to the shipping box, open the box and perform a visual inspection of the Delta 1600. If any damage to the unit is observed please contact Netech Customer Service. The Service Return Form may be obtained at our website http://www.

  • Page 4: Intended User

    Intended User The Delta 1600 is intended to be used by a trained technician. The Delta 1600 is intended for testing and verifying the performance of AEDs. The Delta 1600 should never be used in a patient care location where it might come in contact with a patient.

  • Page 5: Introduction

    The dedicated function keys and menu driven display on the unit makes it simple for operation. The Delta 1600 has a built-in load resistance of 50 ohms to simulate the human body impedance. To establish electrical connection between the AED and the Delta 1600, manufacturer specific interface cables are required.

  • Page 6: Specifications

    ECG Rate: 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170, 180, 190, 200, 220, 240. BPM Accuracy: ± 1% Waveform Amplitude: ECG (AMP) ECG Amplitude:1.0, 2.0, 3.0, 4.0 mV Accuracy: ± 5% peak to peak 6 | Delta 1600 - Quick-Reference Manual...

  • Page 7: General Specifications

    Power : 7.4 Volt Li-Ion Rechargeable Battery 100-230 VAC input 8.5V Battery Charger Housing: High impact ABS plastic enclosure Dimensions: D x W x H :10.25 x 6.25 x 2.5 Inch 26 X 16 x 6.4 Cm Delta 1600 - Quick-Reference Manual | 7...

  • Page 8: Part Numbers And Ordering Information

    630-621 CU Medical Systems 630-622 ZOLL CPR-D-padz 630-623 ZOLL AED Plus or ZOLL AED Pro Note: Various Manufacturers’ model specific interface cables are available. Please call for the part numbers or visit www.NetechCorp.us 8 | Delta 1600 - Quick-Reference Manual...

  • Page 9: Preparation For Use

    Peparation for Use The Delta 1600 is shipped with the following items included in the customized hard case: • Delta 1600 AED Tester. • Li-Ion Rechargeable Battery Charger (110/220 V input) • User manual / USB Jump Drive Before getting started it is important to get familiar with the control and operation of the unit.
  • Page 10 Display The Delta 1600 incorporates a high contrast LCD graphics display with an LED backlight for easy viewing. Key Pad The keypad utilizes soft touch tactile keys, providing a fluid resistant barrier to the internal circuitry. The dedicated key functions and interactive menu make it easier to use.
  • Page 11 Battery charge function is active only in the Power OFF mode. Battery Charger: Li-Ion Battery Charger provided with the unit is specifically designed for the Delta 1600. When the battery is fully charged, the red LED on the CHARGER changes to green. Battery: Delta 1600 incorporates a specially designed 7.4V Li-Ion polymer battery with short circuit protection.

  • Page 12: Initial Setup

    Initial Setup Introduction The Delta 1600 is simple to operate and requires minimum setup. However, the user must read the manual thoroughly for safe and proper operation. When the unit is first powered, the screen momentarily shows the software version and the build number. Thereafter, the Main Menu will be displayed as illustrated below.

  • Page 13: Shock Advisory Test

    • Connect the manufacturer specific interface cable between the Delta 1600 (red shrouded banana jacks) and the AED under test. • From the AED Main Menu, press ‘F1’(Arrhythmia Menu) and select the Arrhythmia waveform. (The default waveform is “VFBC”)
  • Page 14 To stop the ‘SHOCK’ advisory, select “ESC” and press F4 from the AED menu to run an ECG (NSR –Normal Sinus Rhythm) waveform. 14 | Delta 1600 - Quick-Reference Manual...

  • Page 15: Auto Function Test

    AUTO Function Test The Delta 1600 Auto function is a very useful method for testing energy discharge of AEDs. “AUTO” function will prevent the need for multiple discharges and helps preserve the battery life of the AED. • Select “AUTO” key and wait for the AED’s response. (The default arrhythmia waveform is set to “VFBC”)

  • Page 16: Ecg Simulation

    ECG Simulation The Delta 1600 simulates ECG (Normal Sinus) waveforms with user selectable rates and amplitudes. Main Menu F4 “ECG” From the select The Rate and amplitude function can be selected from the following ECG selection menu. Rate Selection The default ECG rate is set @90 BPM. ECG rate can be changed in 10 BPM increments from 60 BPM up to 200 BPM and 20 BPM increments from 200 BPM up to 240 BPM by pushing the F1 key.

  • Page 17: Warranty

    Netech warrants this instrument against defects in materials and workmanship. If it fails to conform to these warranties, Netech will repair or replace the unit and/or its components within two weeks of arrival at our facility.
  • Page 18 Netech or one of its authorized service agents. All shipping and handling charges will be billed to the purchaser. THIS WARRANTY EXCLUDES ALL OTHER WARRANTIES, WHETHER EXPRESSED OR IMPLIED, ORAL OR WRITTEN, INCLUDING WITHOUT LIMITATION WARRANTIES MERCHANTABILITY AND / OR FITNESS FOR A PARTICULAR PURPOSE.
  • Page 19 Appendix: A Netech warrants this instrument to the original purchaser, as Current Revision: R1 06/12/17 Delta 1600 - Quick-Reference Manual | 19...
