Page 1: Table Of Contents
BATH FAN / LED LIGHT MODEL GBR100LED-DECOR TABLE OF CONTENTS Package Contents General Safety Information Preparation Assembly Instructions New Construction Existing Construction Glass shade installation Care and Maintenance Troubleshooting Dimensions Product Specifications List of Compatible Dimmers Warranty READ AND SAVE THESE INSTRUCTIONS Address: 46101 Fremont Boulevard, Fremont, CA 94538 US Toll Free Number: 1-888-979-9889 www.deltabreez.com... -
Page 2: Package Contents
PACKAGE CONTENTS PART DESCRIPTION ❶ Duct Connector ❷ Fan Body ❸ Grille Bracket LED Module Glass Shade Decorative Caps and Finial Nuts: 4 sets chrome, brushed nickel, brushed bronze, and polished white HARDWARE CONTENTS (Images are to scale) Long Wood Screw ( ∅ 4 x 25) Cap set X 4 surface treatment Machine Screw ( #8-32 x 5/16”) Suspension Bracket... -
Page 3: General Safety Information
GENERAL SAFETY INFORMATION READ AND SAVE THESE INSTRUCTIONS GENERAL SAFETY INFORMATION 7. If this unit is to be installed over a tub or shower, it must 1. Make sure that the electric service supply voltage is AC be marked as appropriate for the application and be 120V, 60Hz. -
Page 4: Preparation
PREPARATION Tools Required for Assembly (not included): Hammer, Roof cap (with built-in Flathead Screwdriver, Wire Nuts, Nails, Duct Tape, damper) Short piece of flexible Phillips Head Screwdriver, Utility Knife duct helps alignment and absorbs Helpful Tools (not included): Electric Drill, Drill Bits sound Fan housing WARNING: Turn off electricity at breaker box... -
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS BEFORE INSTALLATION Turn off power source. Review all safety precautions. NEW CONSTRUCTION Tabs MOUNT HOUSING WITH FLANGE: Joist make housing tabs contact the bottom of the joist. The housing mounts with 4 long screws (ø 4×25). Screw housing to joist through lowest holes in each mounting flange, then through the other holes. -
Page 6: Existing Construction
ASSEMBLY INSTRUCTIONS (Continued) EXISTING CONSTRUCTION–ACCESSIBLE 1. Remove existing fan. Measure the ceiling opening to ensure it is large enough to accommodate the new fan (8 in. x 8 in.) 2. If this fan is not replacing an existing fan, be sure to cut a 8 in. -
Page 7: Glass Shade Installation
ASSEMBLY INSTRUCTIONS (Continued) 1. CONNECT WIRING A. Follow all local electrical code and ANSI/NFPA70. B. NEVER place a switch where it can be reached from a tub or shower. C. Remove the fan junction box cover. Using wire nuts (not supplied) connect house wires to fan wires as shown in the wiring diagram on page 4. -
Page 8: Care And Maintenance
CARE AND MAINTENANCE TURN OFF POWER SOURCE. REVIEW ALL SAFETY PRECAUTION. See safety information before proceeding. Routine maintenance should be done at least once a year. • Never use solvents, thinner or harsh chemicals when cleaning the fan. • Do not allow water to enter the motor. •... -
Page 9: Troubleshooting
TROUBLESHOOTING PROBLEM POSSIBLE CAUSE CORRECTIVE ACTION The fan is not turning on 1. Power off 1. Make sure power supply is on. 2. Faulty switch 2. Test or replace switch. 3. Faulty wire connection 3. Check wire in switch box. The fan seems louder 1. -
Page 10: Dimensions
DIMENSIONS “ “ “ “ “ “ PRODUCT SPECIFICATIONS SPECIFICATIONS Fan Power Air Flow Noise Frequency LED light Voltage Weight Model No. @0.1”SP @0.1”SP @0.1”SP (lb.) (Hz) spec. (CFM) (Sones) 13 Watts, GBR100LED-DECOR 13.0 950Lumens, 3000K LIST OF COMPATIBLE DIMMERS(NOT SUPPLIED) Brand Model Brand... -
Page 11: Warranty
6. To qualify for warranty service, you must notify Delta Electronics at the address or telephone number below. 7. Delta Electronics shall have no liability to the original owner-user with respect to any defect caused by abuse, misuse, neglect, improper transportation or storage, improper testing, improper installation, improper operation,... - Page 12 Model: GBR100LED-DECOR...
