If you're using a Macintosh laptop with OS X:
You may need to set up your system to display on the
projector screen as well as the LCD screen. Follow these steps:
1. From the Apple menu, select
click .
Displays
2. Select or
VGA Display Color LCD
, and make sure
Arrangement
Adjusting the Image
Once you see your image, you may need to make certain
adjustments, as described in this section.

Focusing and Zooming Your Image

Rotate the focus ring to sharpen the image.
Rotate the zoom ring to reduce or enlarge the image.
You can also change the image size by moving the projector
closer to or farther away from the screen. You can use the
buttons on the remote control to zoom in on a
E-Zoom
portion of the image. See page 8 for instructions.
, then
System Preferences
, click or
Arrange
is checked.
Mirror Displays
Focus ring
Zoom ring
EPSON PowerLite 53c/73c Projector

Adjusting the Height of Your Image

If the image is too low, you can raise it by extending the
projector's feet.
1. Stand behind the projector. Press the blue foot release levers
and lift the front of the projector. This unlocks the feet.
2. Once the image is positioned where you want it, release the
levers to lock the feet in position.
3. To fine-tune the height of the image, rotate the projector's
feet.
If the image is no longer rectangular after raising it, see the
next section.

Adjusting the Image Shape

If the projected image isn't rectangular or has a "keystone"
shape, do one or more of the following:
❏ If your image looks like
projector off to one side of the screen, at an angle. Move it
directly in front of the center of the screen, facing the screen
squarely.
❏ If your image looks like
feature has been disabled. You can correct this by turning on
the Auto Keystone feature or by manually adjusting the
keystone correction value.
To turn on Auto Keystone, press the
remote control. Use the directional buttons to select the
menu, then press
Setting
to highlight
Auto Keystone
the button to save your changes, then exit the menu by
Enter
pressing the
Menu
when you're using ceiling or rear projection.)
To manually adjust the keystone correction value, press the
or side of the
correct the shape of the image. After correction, your image
will be slightly smaller.
You can also perform electronic keystone correction using the
projector's Setting menu.
11/02 EPSON PowerLite 53c/73c Projector
or , you've placed the
or , the Auto Keystone
button on the
Menu
. Use the directional buttons
Enter
and to turn the feature on. Press
button. (Auto Keystone is not available
button on the projector to
Keystone
Foot
5
-
