Epson powerlite 53c: product information
Hide thumbs Also See for PowerLite 53c:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Remote control receiver
Foot
Focus ring
Lens cap
Computer/Component Video port
Monitor Out port
S-Video port
Remote control
receiver
Power inlet
Audio1 port
Audio2 L and R ports

Specifications

General
Type of display
Poly-silicon TFT active matrix
73: with MLA (Micro Lens Array)
53: without MLA (Micro Lens Array)
LCD panels (3)
Diagonal size: 0.7 inches (17.8 mm)
Lens
F=1.70 to 1.87,
focal length=21.3 to 25.6 mm
Resolution
1024
×
800
Color
Full color, 16.7 million colors
reproduction
Brightness
53: 1700 lumens (High brightness mode)
(ANSI)
1400 lumens (Low brightness mode)
73: 1500 lumens (High brightness mode)
1200 lumens (Low brightness mode)
Contrast ratio
500:1
Image size
30 to 300 inches (0.8 to 7.6 meters)
Control panel
Foot release lever
Foot
Composite video port
USB ports
Security lock port
RS-232C port
×
768 pixels (73)
600 pixels (53); (native formats)
Projection
distance
Projection
methods
Internal
sound system
Zoom ring
Optical aspect
ratio
Zoom ratio
Noise level
Keystone
correction angle
Projection Lamp
Power
consumption
Lamp life
Part number
Remote Control
Range
Battery
Mouse Compatibility
Dimensions
Height
Width
Depth
Weight
Electrical
Rated frequency
Power supply
Power
consumption
Environmental
Temperature
Humidity
(non-condensing) Storage: 10 to 90% RH
11/02
EPSON PowerLite 53c/73c Projector
2.9 to 34.4 feet (0.9 to 10.5 meters)
Front, rear, upside-down (ceiling
mount)
1 W monaural
4:3 (horizontal : vertical)
1 : 1.2
36 dB (High brightness mode)
33 dB (Low brightness mode)
±
15° vertical (maximum)
165 W
About 1500 hours
V13H010L21
20 feet (6 meters)
CR2025 lithium
Supports USB
3.4 to 3.8 inches (87 to 97 mm)
12.4 inches (315 mm)
9.5 inches (240 mm)
6.4 lb (2.9 kg)
50/60 Hz
100 to 120 VAC, 2.6 A
200 to 240 VAC, 1.3 A
Operating: 240 W
Standby: 2.6 W
Operating: 41 to 95 °F (5 to 35 °C)
Storage: 14 to 140 °F (–10 to 60 °C)
Operating: 20 to 80% RH,
EPSON PowerLite 53c/73c Projector
