Epson PowerLite 5350 Manual

Epson PowerLite 5350 Manual

Epson projector specifications sheet
Hide thumbs Also See for PowerLite 5350:
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual, Installation Manual
control panel
infrared
receiver
speaker
handle
foot adjust lever
zoom ring
Repeater
Computer Out
Audio Out
rear infrared
receiver
R/R-Y G/Y G Sync B/B-Y
Computer 2/BNC switch
power inlet
speaker
infrared receiver
status lights
foot adjust
lever
focus ring
adjustable feet
projection lens
Mouse/Com 2
Computer 2
Audio 2
Audio 1
Mouse/Com 1
1
S-Video
composite video
Video L-Audio-R
HD/Sync VD
Computer 1
EPSON PowerLite 5350/7250/7350 Projector

Projector Specifications

General
Type of display
Poly-silicon Thin Film Transistor (TFT)
Size of liquid
crystal panels
Diagonal: 1.3 inches (33.6 mm)
Lens
F=2.0–2.3, f=55–72 mm
Resolution
PowerLite 5350: SVGA, 800 600 pixels
PowerLite 7250/7350: XGA, 1024 768
pixels
Color
reproduction
24 bit, 16.7 million colors
Brightness
PowerLite 5350: 1400 lumens (ANSI)
PowerLite 7250: 1200 lumens (ANSI)
PowerLite 7350: 1500 lumens (ANSI)
Image size
Wide angle: 23 to 300 inches (at 3.9 to
40.6 feet distance)
Tele angle: 23 to 230 inches (at 5.1 to 54
feet distance)
Projection
distance
3.18 to 54.8 feet (1.18 to 16.7 meters)
Projection
methods
Front, rear, upside-down (ceiling mount)
Internal speaker
system
3 3 W stereo output
2 3 W 8 (ohm) speakers
Optical aspect
ratio
4:3 (horizontal:vertical)
Zoom ratio
1:1.3
Tilt angle
0° to 12°
Supported video
interface standards NTSC, PAL, PAL-M, PAL-N, SECAM
Projection Lamp
Type
UHE (Ultra High Efficiency)
Power
consumption
150 W
Lamp life
1500 to 2000 hours (typical)
Part number
ELPLP09
Remote Control
Range
32.8 feet (10 meters)
Batteries
Alkaline AA (2)
8/99
EPSON
PowerLite 5350/7250/7350 Projector - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerLite 5350 and is the answer not in the manual?

Questions and answers

Related Manuals for Epson PowerLite 5350

Summary of Contents for Epson PowerLite 5350

  • Page 1: Projector Specifications

    Batteries 8/99 Poly-silicon Thin Film Transistor (TFT) Diagonal: 1.3 inches (33.6 mm) F=2.0–2.3, f=55–72 mm PowerLite 5350: SVGA, 800 600 pixels PowerLite 7250/7350: XGA, 1024 768 pixels 24 bit, 16.7 million colors PowerLite 5350: 1400 lumens (ANSI) PowerLite 7250: 1200 lumens (ANSI) PowerLite 7350: 1500 lumens (ANSI) Wide angle: 23 to 300 inches (at 3.9 to...
  • Page 2 EPSON PowerLite 5350/7250/7350 Projector Mouse Compatibility Supports PS/2, USB, serial, ADB Remote IR Receiver Supports EPSON remote IR receiver, 10-foot cable (typical for rear screen projection) Mechanical Height 5.1 inches (129 mm), including feet Width 11.8 inches (300 mm) Depth 15.8 inches (400 mm), including lens...
  • Page 3 300 inches* (762 cm) 200 inches (508 cm) 100 inches (254 cm) * For an image size of 300 inches, the projector may be up to 54 feet away from the screen, depending on the setting of the zoom ring. 8/99...

  • Page 4: Projector Status Lights

    Minimum projection distance = (3.4721 diagonal size) - 14.3256 EPSON PowerLite 5350/7250/7350 Projector Projector Status Lights The status lights on top of the projector tell you the projector’s operating status. power light temperature light Caution: A red light warns you if a serious problem occurs.

  • Page 5: Using The Remote Control

    The remote control uses a line-of-sight infrared signal. To use the remote control, point it towards one of the infrared receivers located at the front and back of the projector. You can use the remote control up to about 32.8 feet (10 meters) from the projector.

  • Page 6: Using The Control Panel

    Keystone Volume Shift You can use the control panel to control the projector instead of the remote control. However, you can program and access the custom features only with the remote control. The following table summarizes the functions on the control panel.

  • Page 7: Replacing The Lamp

    1. Turn off the projector and unplug the power cable. 2. Turn the projector on its side so that the handle is on top and you can access the filter easily. Note: Standing the projector with the handle at the top keeps dust from getting inside the projector housing.
  • Page 8 EPSON PowerLite 5350/7250/7350 Projector 6. Gently insert the new lamp unit by lowering it into position. Make sure it’s inserted securely. Tighten the screws on the new lamp unit. 7. Replace the lamp cover and tighten the cover screws. (Make sure the lamp cover is securely fastened.
