WARNING & SAFETY INSTRUCTIONS Before you begin the installation of the appliance, we advise you read and carefully follow the instructions contained in this manual. It contains important information about safety, installation, use and maintenance of the product. The actual system that you have received, may differ from the pictures/illustrations/descriptions in these Instructions.
OPERATING CONDITIONS & REQUIREMENTS APPLICATION LIMITATIONS: pH: 5-10 maximum contaminant content: Water hardness 75 °f / 42 °d Iron (Fe 15 mg/L Manganese (Mn 3 mg/L Oxidizability (O 4 mg/L Ammonia (NH 4 mg/L OPERATING PRESSURE MIN-MAX: 1,4-8,0 bar / 20-116 psi ...
Page 5
OPERATING CONDITIONS & REQUIREMENTS OPTIONAL Wi-Fi: to order your system with the optional Wi-Fi function, indicate this by adding “-W” to the corresponding part number: PN 35810 Softener 1”, Simplex 25L 35810-W Softener 1”, Simplex 25L - Wi-Fi enabled 2400VS/J4JB/PRL1 Control Valve 1”, Multimix 24L 2400VS/J4JB/PRL1-W...
4. Remove the lid from the brine well. 5. Make sure the correct elbow connection is installed on the brine valve (⅜” for PF-MMX); replace if necessary. 6. Run the polytube from the control valve through the hole in the sidewall of the brine tank, to the inside of the brine tank.
It allows to turn off the water to the appliance, while maintaining full-flow (untreated) water supply to the user. for PF-MMX with factory bypass (optional) Picture 4 Picture 2 1.
COMMISSIONING ELECTRICAL 1. Connect the appliances power cord to the transformers output. 2. Plug the transformer into an electrical outlet. PRESSURIZING 1. Put the bypass system in 'bypass' position. 2. Make sure the electronic controller of the appliance is in service mode.
ELECTRONIC CONTROL PANEL While the appliance will continue to operate normally, it is Picture 5 recommended to have preventive maintenance performed by a professional. symbol button function to advance to the next SCROLL SERVICE MODE parameter to increase the value of the In service mode the display shows: parameter on 1...
Page 10
ELECTRONIC CONTROL PANEL 1. Press the scroll button repeatedly until the display shows: Holiday: OFF Press the up or down button to activate the holiday mode by setting the number of full days away from home, or deactivate the holiday mode (OFF). Once the control panel is back in service mode, the display will show: 8:01...
Page 11
ELECTRONIC CONTROL PANEL PROGRAMMING INSTRUCTIONS - PROGRAMMING INSTRUCTIONS - BASIC SETTINGS CONFIGURATION PARAMETERS Before entering the programming mode, make sure that Before entering the programming mode, make sure that the appliance is in the service mode. the appliance is in the service mode. ...
Page 12
ELECTRONIC CONTROL PANEL 6. Press the scroll button again; the display will show: 11. Press the scroll button again; the display will show (only when the regeneration mode is set to ‘Dlyd’ or Resin:XXX liters ‘Dlyd/Immd’): Rsrv Variable Press the up or down button to set the volume ...
Page 13
ELECTRONIC CONTROL PANEL DIAGNOSTICS MODE In the Diagnostics mode several operating parameters can be consulted; particularly during a service intervention, these parameters can be helpful to identify the cause of a problem or malfunction. Before entering the Diagnostics mode, make sure that the appliance is in service mode.
MAINTENANCE RECOMMENDATION WATER CONDITIONER SALT Notwithstanding the reliability of the appliance, we strongly This appliance needs 'brine' for its periodic regenerations. recommend to have it serviced and maintained on a regular This brine solution is made from water, that is automatically basis by a competent and duly trained technician.
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Untreated water to Open or defective bypass Close or replace bypass service Appliance in regeneration Wait until regeneration finishes or manually advance regeneration to end No salt in brine tank Add salt and initiate regeneration manually Salt bridging in brine tank Break salt bridge(s) and initiate regeneration manually...
Page 17
TROUBLESHOOTING PROBLEM CAUSE SOLUTION Control valve fails to Improper refill time setting Verify that refill time corresponds to salt level and refill brine tank amount of filter media Plugged refill flow control Clean refill flow control Loss of filter media Lower and/or upper distributor damaged Replace distributor(s) Leak between riser tube and upper distributor...
ELECTRICAL WIRING DIAGRAMS = position switches = flow meter = power lead = drive motor = auxilliary contacts (24 VDC, max. 500mA) AUX1 = PF-SOF1-SIM: service valve NO (optional) = PF-SOF1-PRL: service valve NO = PF-SOF1-ALT: service valve NC AUX2 = PN 74372 is needed, to use this contact ...
COMPOSITION OVERVIEW Media Control valve, incl. transformer, Pressure tank, Model Filter media volume 1” BSP male connections incl. distributor assy (12 kg bag) model model 35690 2400VS/J4JB/PRL1 10x35 35691 2400VS/J1JB/PRL1 10x47 35692 2400VS/J1LD/PRL1 12x48 35693 2400VS/J1ND/PRL1 14x65 Page 20...
Page 27
EXPLODED VIEW - PF-MMX - VALVE BODY Item Description Remark 39121 Drain elbow 19 mm 568/271/J Drain Line Flow Control J (9,8 Ltr/min) 24 Ltr, 36 Ltr 568/271/L Drain Line Flow Control K (15,1 Ltr/min) 48 Ltr 568/271/N Drain Line Flow Control N (22,7 Ltr/min)
