Page 1: Water Filter
Technical Manual WATER FILTER Models: PF-GAC1 PF-AG1 PF-GAC1,5 PF-AG1,5 © 2017 erie water treatment TM-EN-PF-GAC_AG-Rev2017.01... -
Page 2: Table Of Contents
Composition overview ......................Page 14 Exploded view - PF-GAC1 & PF-AG1 - System ...............Page 16 Exploded view - PF-GAC1 & PF-AG1 - Timer assembly ............Page 18 Exploded view - PF-GAC1 & PF-AG1 - Valve body ..............Page 20 Exploded view - PF-GAC1,5 & PF-AG1,5 - System ..............Page 22 Exploded view - PF-GAC1,5 &... -
Page 3: Warning & Safety Instructions
WARNING & SAFETY INSTRUCTIONS Before you begin the installation of the appliance, we advise you read and carefully follow the instructions contained in this manual. It contains important information about safety, installation, use and maintenance of the product. The actual system that you have received, may differ from the pictures/illustrations/descriptions in these Instructions. -
Page 4: Operating Conditions & Requirements
OPERATING CONDITIONS & REQUIREMENTS OPERATING PRESSURE MIN-MAX: 2,5-8,0 bar / 36-116 psi low operating pressure may lead to insufficient backwash of the filter media, resulting in an increase in pressure drop and/or a reduction of the filtration capacity during the service cycle. ... -
Page 5: Assembly
1 cuft; it must be loaded on-site, after CONTROL VALVE positioning of the pressure tank. only for PF-GAC1 & PF-AG1 Check the content of the system, using the Composition Overview in these Instructions. Identify and lay-out the 1. -
Page 6: Installation
PF-GAC1 & PF-AG1: appliance, always install and use an air gap (drain adaptor with factory bypass (optional) with air gap included with PF-GAC1 & PF-AG1), to connect the drain hose to the sewerage system. Picture 1 ... -
Page 7: Commissioning
COMMISSIONING ELECTRICAL 1. Connect the appliances power cord to the transformers output. 2. Plug the transformer into an electrical outlet. PRESSURIZING 1. Put the bypass system in 'bypass' position. 2. Make sure the electronic controller of the appliance is in service mode. -
Page 8: Electronic Control Panel
ELECTRONIC CONTROL PANEL Picture 9 REGENERATION MODE In regeneration mode the display shows the remaining symbol button function regeneration time and the remaining cycle time: to advance to the next SCROLL parameter Rgn:123 CycY:456 to increase the value of the parameter The control valve can be reset to service mode at any time by to decrease the value of the... - Page 9 Cycle 1 Backwash Cycle 2 No function Cycle 3 Fast rinse Cycle 4 No function (PF-GAC1,5 & PF-AG1,5) 5. Press the scroll button again; the display will show: Regen @ 0:00 Press the up or down button to set the time of ...
-
Page 10: Maintenance
when it is not necessary to supply treated water to the application. WITH FACTORY BYPASS (optional) (only for PF-GAC1 & PF-AG1) Picture 10.a SERVICE POSITION = inlet valve to appliance is OPEN ... -
Page 11: Troubleshooting
Appliance fails to backwash properly Refer to problem “Appliance fails to backwash properly” PF-GAC1 & PF-AC1 only: valve body and timer Synchronize valve body and timer out of synchronisation Decreasing filter capacity of filter media Clean or replace filter media Loss of filter media Refer to problem “Loss of filter media”... -
Page 12: Electrical Wiring Diagrams
ELECTRICAL WIRING DIAGRAMS PF-GAC1 & PF-AC1 = position switches = power lead = drive motor = service valve NO (optional) = key pad PF-GAC1,5 & PF-AC1,5 = optical switch ... -
Page 13: Default Configuration Parameter Settings
DEFAULT CONFIGURATION PARAMETER SETTINGS Model PF-GAC1 & PF-AG1 Filter media (cuft) Interval (days) Cycle 1: BACKWASH (min) Cycle 2: SLOW RINSE (min) Cycle 3: PURGE (min) Regen @ 0:00 0:00 0:00 Model PF-GAC1,5 & PF-AG1,5 Filter media (cuft) Interval (days) -
Page 14: Composition Overview
COMPOSITION OVERVIEW Media Control valve, incl. transformer, Pressure tank, Filter media Model Underbedding volume 1” male BSP connections incl. distributor assy (1 cuft bag) cuft model model type type 35359 2400TF/JN/SV 10x40 Gravel 2-4 mm Coconut GAC 35370 2400TF/JQ/SV 12x52 Gravel 2-4 mm Coconut GAC 35707... - Page 15 Page 15...
-
Page 16: Exploded View - Pf-Gac1 & Pf-Ag1 - System
EXPLODED VIEW - PF-GAC1 & PF-AG1 - SYSTEM Page 16... - Page 17 EXPLODED VIEW - PF-GAC1 & PF-AG1 - SYSTEM Item Description Remark PT/1040/BA Pressure tank 10x40 1 cuft PT/1252/BA Pressure tank 12x52 2 cuft PT/1465/BA Pressure tank 14x65 3 cuft A1100(BB) Coconut Granular Activated Carbon (GAC) multiple of 1 cuft ...
-
Page 18: Exploded View - Pf-Gac1 & Pf-Ag1 - Timer Assembly
EXPLODED VIEW - PF-GAC1 & PF-AC1 - TIMER ASSEMBLY Page 18... - Page 19 EXPLODED VIEW - PF-GAC1 & PF-AC1 - TIMER ASSEMBLY Item Description Remark 70971 Power lead with plug 72263 Clamp 28/244/1 Plug (large) 71502 Screw, timer cover (3x) 15/222 Screw, back plate (2x) 74135 Socket and cable assembly, Service Valve...
-
Page 20: Exploded View - Pf-Gac1 & Pf-Ag1 - Valve Body
EXPLODED VIEW - PF-GAC1 & PF-AC1 - VALVE BODY Page 20... - Page 21 EXPLODED VIEW - PF-GAC1 & PF-AC1 - VALVE BODY Item Description Remark 21/83 Drain connection 568/271/N Backwash flow control N (22,7 Ltr/min) 1 cuft 568/271/Q Backwash flow control Q (30,3 Ltr/min) 2 cuft 568/271/S Backwash flow control S (37,8 Ltr/min)
-
Page 22: Exploded View - Pf-Gac1,5 & Pf-Ag1,5 - System
EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - SYSTEM Page 22... - Page 23 EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - SYSTEM Item Description Remark PT/1465/4/BA Pressure tank 14x65, 4” top opening 3 cuft PT/1665/4/BA Pressure tank 16x65, 4” top opening 4 cuft PT/1865/4/BA Pressure tank 18x65, 4” top opening 5 cuft ...
-
Page 24: Exploded View - Pf-Gac1,5 & Pf-Ag1,5 - Timer Assembly
EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - TIMER ASSEMBLY Page 24... - Page 25 EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - TIMER ASSEMBLY Item Description Remark EV/50195 Nut, drive motor assembly EV/11538 Bolt, drive motor assembly EV/20644/1 Back plate 74267 Cable clamp EV/20648 Nut, back plate (4x) 74224 Socket and cable assembly, Service Valve...
-
Page 26: Exploded View - Pf-Gac1,5 & Pf-Ag1,5 - Valve Body
EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - VALVE BODY Page 26... - Page 27 EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - VALVE BODY Item Description Remark EV/20961 Bolt, cap (4x) EV/11101/1 EV/11115 Gasket, cap EV/11092 O-ring, inlet/outlet adaptor (2x) EV/11094-1 Inlet/outlet adaptor 1,5” BSP Male (2x) EV/11093 Nut, inlet/outlet adaptor (2x) EV/11088...
-
Page 28: Exploded View - Pf-Gac1,5 & Pf-Ag1,5 - Piston Assembly
EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - PISTON ASSEMBLY Page 28... - Page 29 EXPLODED VIEW - PF-GAC1,5 & PF-AG1,5 - PISTON ASSEMBLY Item Description Remark EV/20646 Piston EV/20654 Stem EV/11104 Bushing EV/11105 O-ring, bushing (2x) EV/11080 Seal disk EV/11082 Spacer (narrow) (2x) EV/11081 Spacer (wide) (3x) EV/11078 Compression spacer EV/11076...
-
Page 30: Technical Data - Pf-Gac1 & Pf-Ag1
TECHNICAL DATA - PF-GAC1 & PF-AG1 Technical specifications: Model PF-GAC1 / PF-AG1 Filter media (cuft) Operating pressure min/max (bar) 2,5/8,3 Operating temperature min/max (°C) 4/48 Electrical connection (V/Hz) 230/50 Max. power consumption (VA) Hydraulic connection inlet/outlet 1” BSP Male Hydraulic connection drain... -
Page 31: Technical Data - Pf-Gac1,5 & Pf-Ag1,5
Technical specifications: Model PF-GAC1,5 / PF-AG1,5 Filter media (cuft) Operating pressure min/max (bar) 2,5/8,0 Operating temperature min/max (°C) 4/48 Electrical connection (V/Hz) 230/50 Max. power consumption (VA) Hydraulic connection inlet/outlet 1,5” BSP Male Hydraulic connection drain 1” BSP Male Pressure tank... - Page 32 Manufactured & Assembled by erie water treatment a division of Aquion, Inc. www.eriewatertreatment.com...
