Installation Guide
4 Modbus communication connection.
5 Power connection
Heat pump
1
Cooling module (with factory connec-
ted Expansion card)
6 Modbus connection
Heat pump
1
Cooling module (with factory connected Expansion card)
If the cooling module shall be able to produce cooling and heating at the same time, it is recommended that a
system supply line sensor is installed on the heating circuit.
12
Cooling module for domestic heat pump (Genesis platform),
Passive and Passive/Active
J4 BM
VIMAB102
1
2
3
4A
4B
5
6
7
(
Cooling module
2
Power supply 230VAC (Total power input is less
than 0,25 kW)
)
Cooling module
2
Heat Pump (Domestic)
Danfoss Heating Solutions
