Epson Stylus Pro 4000 Product Information

Epson Stylus Pro 4000 Product Information

Epson stylus pro 4000: product information
Hide thumbs Also See for Stylus Pro 4000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Reference Manual, User Manual

Printer Parts

-
roll paper cover
paper lever
exhaust port cover
top cover
paper lever
ink cartridge
compartments
roll paper
spindle
AC inlet
USB interface
connector
IEEE 1394 FireWire
®
interface connector

Printer Specifications

Printing
Printing
method
control
Nozzle
panel
configuration
Resolution
Print direction
Control code
Line spacing
Paper feed speed 215 ±10 milliseconds per 1/6-inch line
RAM
Engine Reliability
Total print
volume
Print head life
Periodic
maintenance
Cutter blade life Approximately 2,000 B0+ sheets (Epson
4/04

Epson Stylus Pro 4000

On-demand ink jet
Photo ink set:
×
Black: 180 nozzles
3 (photo black, matte
black, light black)
×
Color: 180 nozzles
5 (cyan, magenta, light
cyan, light magenta, yellow)
Maximum 2880 dpi × 1440 dpi
Unidirectional/Bidirectional
Epson ESC/P
®
Raster
Photographic Driver
1/6 inch or programmable in
1/1440-inch increments
32MB
20,000 A2 images (360 × 360 dpi)
8.4 billion dots per nozzle
Pump unit, head cleaner, and cap assembly
require replacement approximately every
18,000 pages (A1-size plain paper)
media up to 4.33 mil thick); approximately
1,000 B0+ coated sheets
Epson Stylus Pro 4000 - 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Stylus Pro 4000 and is the answer not in the manual?

Questions and answers

Related Manuals for Epson Stylus Pro 4000

Summary of Contents for Epson Stylus Pro 4000

  • Page 1: Epson Stylus Pro

    Paper feed speed 215 ±10 milliseconds per 1/6-inch line Engine Reliability Total print volume Print head life Periodic maintenance roll paper Cutter blade life Approximately 2,000 B0+ sheets (Epson spindle AC inlet USB interface connector ® 4/04 Epson Stylus Pro 4000...

  • Page 2: Safety Approvals

    Pro 4000 printer will be rated up to 100 years under glass on specific 17 x 22 in. Epson media. Data indicate the lightfastness of black and white (432 x 559 mm) UltraChrome™ images will be rated as greater than 100 years under —...

  • Page 3: Consumables And Accessories

    8 minutes to initialize the printer. Do not interrrupt this process by turning off the printer, opening the top cover, or releasing the paper lever, or the printer will have to re- initialize. In that case, there may not be enough ink left in the original cartridges and you may have to replace them with new ones.

  • Page 4: Control Panel

    Epson Paper and Other Media Epson papers, which are especially designed for the inks used in the printer, ensure high-quality results. The following table lists the product codes for the Epson media available for your printer. Paper type Roll sizes and codes Photo Quality Ink Jet —...

  • Page 5: Error Messages

    B Ink light Ink cartridge(s) Install ink cartridges not installed or or lower the ink ink lever raised. lever (page 7). Paper Paper has Remove the light jammed in the jammed paper. flashing printer. Epson Stylus Pro 4000 - 5...
  • Page 6 Paper is too thick PAPER light on for head cleaning. Printer could not feed the printer page. 6 - Epson Stylus Pro 4000 Message/ Response Light Open the top cover SERVICE REQ. and remove the uncut paper. Reload paper if necessary.

  • Page 7: Printing A Status Check

    NOTE: You can replace the ink cartridges, cutter blade, and maintenance tank yourself. Other parts need to be replaced by an authorized Epson service technician. Follow these steps to print the status check sheet: 1. Make sure paper is loaded in the tray.
  • Page 8 Banding can be caused by several problems, such as clogged print head nozzles or a misaligned print head. It can also be caused by using a paper that is not defined in the Epson printer driver or in a third-party RIP. To correct this problem, make sure you select the correct paper type in the driver.

  • Page 9: Running A Power Cleaning Cycle

    Follow these steps to align the print head using the control panel: 1. Make sure the printer is turned on. Then load paper. Epson Enhanced Matte paper is recommended. 2. Press the Menu 3.

  • Page 10: Replacing The Cutter Blade

    For a list of media that do not work with the cutter, see the Printer Guide. Make sure that the printer is on and the front cover is closed. 1. Press the Menu 2. Press...

  • Page 11: Replacing The Maintenance Tank

    3. Place your hand under the right ink compartment and gently pull out the maintenance tank. CAUTION: Be careful not to spill ink from the tank when removing it. Hold it upright at all times. 4/04 Epson Stylus Pro 4000 Epson Stylus Pro 4000 - 11...

  • Page 12: Related Documentation

    Select Drivers & Support from the left menu, then navigate to the Epson Stylus Pro 4000 to see if there are any updates posted. Check back regularly to maintain compatibility with existing and future applications.
