D-Link DAP-1755 Quick Installation Manual

Quick Installation Guide
DAP-1755
AC1750 Mesh Wi-Fi Range Extender
Setup and How To videos available here:
YouTube.com/DLinkTutorials
INSTALLATION
D-LINK WI-FI APP SETUP
1
Plug the Range Extender into a power
outlet near your router.
/
Did you know? From automatic firmware updates to seeing what devices are connected to your network, the D-Link Wi-Fi app makes
setup and management of your Range Extender quick and simple.
?
FREQUENTLY ASKED QUESTIONS
Why can't I connect wirelessly or my wireless connection drops?
1. Verify that your Range Extender is within range of your wireless router. Try
plugging it into a location closer to the router and verify the Status LED is
solid green.
2. Note that when extending a wireless signal from a router or access point,
devices connected to the Range Extender will not get the same speed/
throughput as when connected directly to the router.
Signal Strength Indicator
Very Weak (1 x Amber) Weak (1 x Green) Good (2 x Green)
How do I change the wireless settings on my Range Extender?
1. Open a web browser (e.g., Internet Explorer, Firefox, Chrome, or Safari) and
go to the URL found on the QIC or on the back of the Range Extender
(i.e., http://dlinkapXXXX.local./).
2. At the login screen, enter your Admin Password (If WPS Setup was used, the
password is "password" by default) and click Log in.
3. Go to Settings > Extender.
4. Enter a new Wi-Fi Network Name (SSID) and modify the security (Wi-Fi
password) settings as needed.
5. Click Save.
What is Mesh Smart Roaming?
With Mesh Smart Roaming, your Wi-Fi device (e.g. SmartPhone, Tablet) will
automatically roam to the strongest Wi-Fi signal, eliminating the need to
switch between your Router's and Range Extender's Wi-Fi signal as you
move around your home.
Mesh Smart Roaming Requirements:
1. The Wi-Fi device (e.g. SmartPhone, Tablet) must support the 802.11k/v
standard.
2. The Wireless Name (SSID) & Wireless Password must be the same
on both the Mesh Wi-Fi Range Extender and your Wireless Router.
D-LINK WI-FI MESH
You can easily can pair your AC1750 Mesh Wi-Fi Range Extender
(DAP-1755) with any D-Link Wi-Fi Mesh-enabled Router to create a
seamless mesh network that covers every corner of your home.
TECHNICAL SUPPORT
Having trouble installing your new product? D-Link's support website
contains live chat, video tutorials, commonly asked questions, the
latest user documentation and software updates for D-Link products.
Canada
1-800-361-5265
https://support.dlink.ca/DAP-1755
YouTube.com/DLinkTutorials
2
Download the D-Link Wi-Fi app
/ and launch it.
D-Link Wi-Fi
Strong (3 x Green)
PACKAGE CONTENTS
• DAP-1755 || AC1750 Mesh Wi-Fi Range Extender
• Quick Installation Guide
• Quick Installation Card
3
Tap Install New Device. Scan the QR
/ code on the Quick Installation Card.
Follow the on-screen instructions to
complete the setup.
D-Link Wi-Fi
Tip: Before you start, make sure you know
your current router's Wi-Fi name and
password as you will need this info to
complete the setup.
What if I forgot my Range Extender's Admin password
or want to reset my Range Extender?
1. If you forgot your Admin password or want to reset your
Range Extender back to the factory default settings, press
and hold the reset button on the bottom of the extender
using a paper clip and release after the Status light turns red.
Note: This process will erase all your settings.
2. Setup your Range Extender using your preferred method.
How do I setup my Range Extender using WPS?
IMPORTANT
WPS may be disabled on some Routers or Modems. If the WPS Status LED on your Router or
Modem does not start blinking when you have pressed the WPS button, try again and hold it
a little longer. If it still does not blink, STOP, and configure your Range Extender using the
D-Link Wi-Fi App Setup.
1. Plug your Range Extender into an available outlet
near your wireless router and wait until the
Status LED is blinking amber (this may take up
to 3 minutes). You can move it to a more suitable
location after it is set up. If the status LED does
not light up, ensure the power toggle switch
underneath is in the "on" position.
2. Press the WPS (Wi-Fi Protected Setup) button on
your wireless router for 3 seconds. An LED should
start blinking on your router. If it does not blink, see the important note
above.
3. Once confirmed that the WPS light is blinking on your router, within one
minute, press the WPS button on your Range Extender for 2-3 seconds. The
Status LED should start to blink green.
4. When the Status LED turns solid green (may take up to 3 minutes), this
indicates that your Range Extender is securely connected to your wireless
router.
Your setup is complete! You can now unplug and move your Range Extender
to a location between your Wireless Router and the area where you want
wireless coverage. By default, your Range Extender will share the same
Wi-Fi name and password as your Router. When using WPS setup, the default
Admin Password is "password".
If after moving your Range Extender, the signal strength indicator is showing one
single amber bar or if your Range Extender LED does not turn solid green within 3
minutes, move your Range Extender to a wall outlet closer to your wireless router.
GPL CODE STATEMENT
i
This D-Link product includes software code de-
veloped by third parties, including software code
subject to the GNU General Public License ("GPL")
or GNU Lesser General Public License ("LGPL"). As
applicable, the terms of the GPL and LGPL, and
information on obtaining access to the GPL code
and LGPL code used in this product, are available
to view the full GPL Code Statement at:
https://tsd.dlink.com.tw/GPL
The GPL code and LGPL code used in this product
is distributed WITHOUT ANY WARRANTY and is
subject to the copyrights of one or more authors.
For details, see the GPL code and the LGPL code
for this product and the terms of the GPL and
LGPL.
Model Name: DEVICE
Wi-Fi Name: dlink-XXXX
SETUP QR CODE
Password: XXXXXXXX
S/N: 123456789
Reset
Button
WPS
Button
Written Offer for GPL and LGPL Source Code
Where such specific license terms entitle you
to the source code of such software, D-Link will
provide upon written request via email and/or
traditional paper mail the applicable GPL and LG-
PLsource code files via CD-ROM for a nominal cost
to cover shipping and media charges as allowed
under the GPL and LGPL.
Please direct all inquiries to:
Snail Mail: Email:
Attn: GPLSOURCE REQUEST GPLCODE@dlink.com
D-Link Systems, Inc.
17595 Mt. Herrmann Street
Fountain Valley, CA 92708
2020/09/02_90x130 v1.01(CA) 29072600P755A13
