Setup - Video & Audio Setup
Video Configuration
1
2
3
4
5
Live Video Channel Setup - The video can be configured to various settings with a combination of codec and
1
resolution. The camera performance should be considered when setting multiple channels, as the performance
of the camera will be affected.
H.265 (HEVC) codec with a higher bitrate may cause unstable live streaming or reload the webpage.
Codec - Choose the video codec. Depending on the selected codec, the subcategories may be changed
2
accordingly.
Description - Input the additional description of the selected channel. Max. 30 alphanumeric characters may
3
be used, including spaces.
Resolution - Select video resolution.
4
Available Frame Rate may differ even if the same codecs are in use.
<Resolution of Video Format>
2.1MP/
5MP
4MP
(QSXGA)
1080p
2592x1944 2560x1440 1920x1080
Frame Rate - Select the maximum Frame Rate.
5
Available Frame Rate can be different although the same codecs were set up.
768x432
720p/i SVGA
(0.3M)
1280x720 800x600 768x432
14
4CIF D1 VGA
704x576 704x480 640x480
640x360
CIF SIF / 240P
(0.2M)
640x360 352x288 352x240
