- Page 1 Fujitsu Microelectronics Europe MCU-AN-390070-E-V29 Application Note MC-16LX FAMILY SUPPORT TOOL EMULATOR SYSTEM MB2147-01 INSTALLATION GUIDE MB2147-01 APPLICATION NOTE...
-
Page 2: Revision History
2005-01-03 V2.7: M. Willam: Appendix A, B updated 2006-07-12 V2.8: H.Wech: MB90V340 derivates added 2007-11-19 V2.9: M. Willam: 3 Volts/C pin remarks added; Table 5.1 updated This document contains 25 pages. MCU-AN-390070-E-V29 - 2 - © Fujitsu Microelectronics Europe GmbH... -
Page 3: Warranty And Disclaimer
Product or parts thereof, if the Product is returned to Fujitsu Microelectronics Europe GmbH in original packing and without further defects resulting from the customer´s use or the transport. -
Page 4: Table Of Contents
Check Emulation System with the IO-Port Sample Project........17 4 TROUBLESHOOTING..................... 20 Emulator Software does not work in debugging mode..........20 Wrong COM-Port in Softune Workbench ..............20 Emulator MB2147-01 Menu Settings ..............20 Using LAN ....................... 21 MCU-AN-390070-E-V29 - 4 - © Fujitsu Microelectronics Europe GmbH... - Page 5 MB2147 – Installation Guide Contents 5 APPENDIX A ........................22 Adapter Board / Evaluation MCU Table ..............22 6 APPENDIX B ........................23 Table of Emulation System Configuration and supported Starterkits...... 23 © Fujitsu Microelectronics Europe GmbH - 5 - MCU-AN-390070-E-V29...
-
Page 6: Introduction
0 Introduction This installation guide will help you to quickly start setting up the MB2147-01 Emulation Hardware for Fujitsu 16-Bit MCUs and its usage with the Softune Workbench V30L28 or higher. For in-depth information please refer to the following manuals:... -
Page 7: Hardware Requirements
299-Pin Evaluation MCUs 256-Pin Evaluation MCUs • Adapter Board MB2147-20 PGA299P • Adapter Board MB2147-10 PGA256P • Probe Cable • Probe Cable (here: MB2132-469 LQPF120 NQPACK) (here: MB2132-457 QFP-100) (for MB90V390) (for MB90V540) © Fujitsu Microelectronics Europe GmbH - 7 - MCU-AN-390070-E-V29... - Page 8 Starter Kit Board) • RS232-, USB- or LAN-connection cable • Two Power supplies (12V DC) In addition to the emulator, ordered from Fujitsu, a customer should get the ‘Accessories 16’- kit that includes a set of manuals and some cables. MCU-AN-390070-E-V29 - 8 - ©...
-
Page 9: Setting Up The Emulation System
Please refer to the table in the appendix, for which devices what board should be used. MB2147-20 MB2147-10 Figure 2-1: Main-Clock The white arrow marks the crystal-area of the Main-Clock. The DIP-switches and jumpers are identical for both Adapter Boards. © Fujitsu Microelectronics Europe GmbH - 9 - MCU-AN-390070-E-V29... -
Page 10: Main-Clock
Please refer to the graphic above and to the Figure 2-1 how to enable the Main-Clock. Clock Supply Main-Clock on adapter-board Main-Clock on target system : see Sub-Clock : see C-pin Switching Table 2-1: Main-Clock Supply MCU-AN-390070-E-V29 - 10 - © Fujitsu Microelectronics Europe GmbH... -
Page 11: Sub-Clock
Figure 2-4 PGA256: X0A=Pin51 X1A=Pin176 PGA299: X0A=Pin267 X1A=Pin217 Figure 2-5 Dual Clock not available *M: see Main-Clock *C: see C-pin Switching Table 2-2: Sub-Clock Sub-Clock-Setting S2: Figure 2-3 Figure 2-4 Figure 2-5 © Fujitsu Microelectronics Europe GmbH - 11 - MCU-AN-390070-E-V29... -
Page 12: C-Pin Switching
(Dual Clock) MB90V340 Figure 2-5 -101 / -103 MB2147-20 (Single Clock) MB90V390 Figure 2-5 MB2147-20 * see C-pin Switching Table 2-4: Clock Supply Sub-Clock-Setting S2: Figure 2-3 Figure 2-4 Figure 2-5 MCU-AN-390070-E-V29 - 12 - © Fujitsu Microelectronics Europe GmbH... -
Page 13: Power Connection Jumper S1
The Evaluation Chip has a small golden quadrate on one edge. This indicates the Pin Position 1. Then insert the Chip as shown in the right picture and return the lever back in its home position. © Fujitsu Microelectronics Europe GmbH - 13 - MCU-AN-390070-E-V29... -
Page 14: Procedure For Adapter Board Mb2147-10
Pin 1. After inserting, use a small cross tip screwdriver to fix the four screws of the probe cable. Note: The procedure is similar to a 0.5Om target system MCU-AN-390070-E-V29 - 14 - © Fujitsu Microelectronics Europe GmbH... -
Page 15: Check Dip Switches On The Target System (E. G. Mb90V390 Starter Kit)
ON. 2.1.12 Connect the MB2147-01 Emulator to a PC or a LAN network The Emulator has three different communication interfaces. • • RS232 • Choose one of these communication interfaces. © Fujitsu Microelectronics Europe GmbH - 15 - MCU-AN-390070-E-V29... -
Page 16: Power Connection
After this connect a power supply to the target system, i. e. the Starter Kit Board. 2.1.14 Power down Contrariwise to the power-on connection the power on the target system has to switched off first during power-down. The emulator has to be switched off at last. MCU-AN-390070-E-V29 - 16 - © Fujitsu Microelectronics Europe GmbH... -
Page 17: Setting Up The Emulation Software
Open the Softune Workbench. Then choose the Menu File/Open. The following window will pop up: Confirm Workspace/Project file with the OK button. Now choose the IO-Port-Workspace-File IOPort.wsp in the Open File Dialog Window. Then the Softune Workbench window will look like this: © Fujitsu Microelectronics Europe GmbH - 17 - MCU-AN-390070-E-V29... - Page 18 • MB2147-01_COM1.sup • MB2147-01_LAN.sup • MB2147-01_USB.sup After a short moment, the Softune Workbench will go in its debugger state. The Window will look like this: MCU-AN-390070-E-V29 - 18 - © Fujitsu Microelectronics Europe GmbH...
- Page 19 Look at the Starter Kit Board. The LEDs of Port0 have to flash alternately. The LCD on the emulator should display: “EXEC Vol:OK [Enter]:Menu” To end debugging, choose Debug/End debug in the Softune Menu Bar. The emulator system will then halt. © Fujitsu Microelectronics Europe GmbH - 19 - MCU-AN-390070-E-V29...
-
Page 20: Troubleshooting
Menu 1.) LAN 1.) IP Address: (defined by System Administrator) 2.) Subnet Mask: (defined by System Administrator) 3.) MAC Address: (defined by System Administrator) 4.) Port Address: (defined by System Administrator) MCU-AN-390070-E-V29 - 20 - © Fujitsu Microelectronics Europe GmbH... -
Page 21: Using Lan
LAN interface is started. Follow the next steps. When the following window is displayed, make sure that Monitor program auto-loading is selected: Follow the next steps and finally press Finish. © Fujitsu Microelectronics Europe GmbH - 21 - MCU-AN-390070-E-V29... - Page 22 3V Evaluation Chip. Note that these devices have no C pin. In this case please set SW3 of the MB2147 adapter board to correct C pin setting (Chapter 2.1.4) 3V Evaluation Chip, must be supplied with 5 Volts. Please see note in chapter 2.1.6. MCU-AN-390070-E-V29 - 22 - © Fujitsu Microelectronics Europe GmbH...
- Page 23 MB2147-10 MB2132-457 Flash-CAN-100P-M06 439(L)(S)PF IC149-100-014-B5 IC149-100-114-B5 438(L)(S)PFV NQPACK100SD 540GCR MB2147-10 MB2132-496 439(L)(S)PFV HQPACK100SD IC149-100-014-S5 IC149-100-114-S5 443GPF 440GCR MB2147-10 MB2132-457 Flash-CAN-100P-M06 IC149-100-014-B5 IC149-100-114-B5 455(S)PMT NQPACK048SD 456(S)PMT 495G MB2147-10 MB2132-466 Flash-CAN-48P-M26 HQPACK048SD 457(S)PMT © Fujitsu Microelectronics Europe GmbH - 23 - MCU-AN-390070-E-V29...
- Page 24 HQPACK64SB140 +64SD- 64QF-8L) 568PFM 560CRF MB2147-10 MB2132-461 N. A. NQPACK120SD220 574APFV 570ACR MB2147-10 MB2132-468 Flash-EVA2-120P-M13 HQPACK120SD226 NQPACK120SE 574APFF 570ACR MC2147-10 MB2132-461 HQPACK120SE IC149-100-014-S5 IC149-100-114-S5 583C(A)PF 580BCR MB2147-10 MB2132-457 Flash-CAN-100P-M06 IC149-100-014-B5 IC149-100-114-B5 MCU-AN-390070-E-V29 - 24 - © Fujitsu Microelectronics Europe GmbH...
- Page 25 MB2147-20 MB2147-561 823PFV HQPACK080SD 822PF NQPACK080RA 820CR MB2147-20 MB2147-560 823PF HQPACK080RA 340A NQPACK100RB179 867A(S)PF MB2147-20 MB2147-582 Flash-CAN-100P-340 -101/-102 HQPACK100RB179 340A 867(A)PFV MB2147-20 MB2147-581 -101/-102 NQPACK048SD 897(S)PMT 495GCR MB2147-10 MB2132-466 Flash-CAN-48P-M26 HQPACK048SD © Fujitsu Microelectronics Europe GmbH - 25 - MCU-AN-390070-E-V29...
