Summary of Contents for URC MX-HomePro MXHP-R500
- Page 1 MX-HomePro MXHP-R500 Remote Control Owner’s Manual...
-
Page 2: Table Of Contents
MX-HomePro MXHP-R500 Remote Control Table of Contents Congratulations................2 Features and Benefits..............2 Before Getting Started..............3 Parts Guide..................3 Connecting the Lithium Polymer Battery......4 Using the Micro USB Charger.............4 Two-Way via Wi-Fi................4 Using the MX-HomePro MXHP-R500........5 Displaying the Settings Screen..........6 Network Settings................7 Base Station (Hub) Setup............7 TRF-ZW Z-Wave Accessory Account Info.......8... - Page 3 OPERATIONAL, TECHNICAL, OR EDITORIAL, ERRORS/OMISSIONS MADE IN THIS MANUAL. The information in this manual is subject to change without prior notice. MXHP-R500 Owner’s Manual © 2016 Universal Remote Control, Inc. URC- Control the Experience is a registered trademark of Universal Remote Control, Inc.
-
Page 4: Congratulations
MX-HomePro MXHP-R500 Remote Control Congratulations! Thank you for purchasing the MXHP-R500 Wi-Fi remote control for your home automation system. This remote offers two-way control of your connected devices throughout the home or small office space. Controlling and monitoring your home’s devices is as simple as using the MXHP-R500’s Wi-Fi communication. -
Page 5: Before Getting Started
MX-HomePro MXHP-R500 Remote Control Before Getting Started ● Designed for use on your local wireless network The MX-HomePro MXHP-R500 Remote Control is designed for use on your local wireless network. Used in conjunction with a MX-HomePro MXHP-H500 Base Station, the MXHP-R500 can also control your home’s audio/video devices. -
Page 6: Connecting The Lithium Polymer Battery
MX-HomePro MXHP-R500 Remote Control Connecting the Lithium Polymer Battery Press the spring lock down to unlock and remote the cover. The battery is included in the box when shipped from the factory. Place the battery into the battery compartment, making sure to align the contacts on the battery to the contacts on the MXHP-R500. -
Page 7: Using The Mx-Homepro Mxhp-R500
MX-HomePro MXHP-R500 Remote Control Using the MX-HomePro MXHP-R500 The MXHP-R500’s Home Menu pages display the activities and device in your system. Press the Home page button to view your activities and devices. Navigate the home page by using the Up and Down Navigation buttons. Press any button adjacent to the screen to select an activity or device. -
Page 8: Displaying The Settings Screen
MX-HomePro MXHP-R500 Remote Control Displaying the Settings Screen You can enter the Settings menu by pressing and holding the Home and Enter (ENT) buttons for three seconds. Use the Up and Down navigation buttons to navigate between the Settings Items. To select, press the button on the side of the LCD screen or the Select button when a line item is highlighted. -
Page 9: Network Settings
MX-HomePro MXHP-R500 Remote Control Network Settings The screen displays network information about your MXHP- R500 Remote Control and the wireless network it is connected to. Within this screen you are able to scan for Wi- Fi networks, select a network to connect to, and enter any custom settings required. -
Page 10: Trf-Zw Z-Wave Accessory Account Info
Base Station network properties. TRF-ZW Z-Wave Accessory Account Info The Accessory Account info item allows the entry of an URC TRF-ZW Z-Wave account username and password. The MXHP-R500 Remote Control provides a two-way interface... -
Page 11: Sleep Timers
MX-HomePro MXHP-R500 Remote Control Contact your installation professional to acquire Z-Wave home lighting, comfort and security products to use with your MXHP-R500 Remote Control. Sleep Timers You can adjust the amount of time the LCD remains ON when the remote is not in use. The time can be set independently based on whether the remote is using battery power or connected to the Micro USB charger. -
Page 12: Brightness
MX-HomePro MXHP-R500 Remote Control Brightness Selecting the Brightness item results in the display of a screen that allows for setting the brightness of the MXHP- R500 Remote Control’s LCD Screen. Adjust the screen brightness by pressing the adjacent hard buttons to increase or decrease the brightness level. Once the brightness is adjusted, press the Save button. -
Page 13: System
MX-HomePro MXHP-R500 Remote Control System The System information screen displays data about your MXHP-R500’s Operating System and Memory, among other information. Press the More button to view further system information. Pressing Go Back button exists to remote’s Settings menu. -
Page 14: Button Light
MX-HomePro MXHP-R500 Remote Control Button Light You can adjust the brightness of the LEDs that backlight the buttons of the MXHP-R500. Press the adjacent hard buttons to increase or decrease the button light level. Once the button light is adjusted, press the Save button. Pressing the... -
Page 15: Power
MX-HomePro MXHP-R500 Remote Control Power You can display the remaining battery level by selecting Power. You can also adjust when the Low Battery warning screen appears. Once the power is adjusted, press the Save button. Pressing the Go Back button reverts to the remote’s... -
Page 16: Sound
MX-HomePro MXHP-R500 Remote Control Sound You can adjust the button sounds of the MXHP-R500. Press the adjacent hard buttons to increase or decrease the button volume level. Once the sound is adjusted, press the Save button. Pressing the Go Back button reverts to the remotes... -
Page 17: Pickup
MX-HomePro MXHP-R500 Remote Control Pickup You can set your MXHP-R500 to turn on when the remote is picked up. Simply select Low, Med, or High (Turn ON) or Off. After the pickup has been adjusted, the System Menu is displayed once again. -
Page 18: Firmware Update
MX-HomePro MXHP-R500 Remote Control Firmware Update Selecting Firmware Update results in the display of a screen that checks for a firmware update for the MXHP-R500 Remote Control and the MXHP-H500 Hub (if necessary). If a firmware update is available, the below screen is displayed. -
Page 19: Factory Default
MX-HomePro MXHP-R500 Remote Control Factory Default WARNING! Selecting this button resets the memory of the MXHP-R500 to the factory settings. All programming will be lost! Selecting Yes sets the MXHP-R500 to factory default. Selecting No returns the MXHP-R500 to the Setup Menu... -
Page 20: Exit
MX-HomePro MXHP-R500 Remote Control Exit When you have finished adjusting Settings, simply press the Exit button to return to normal operation. Specifications LCD: 2 Inch Screen (240 by 320) LCD Backlighting by LED Devices: Supports up to 255 Devices with text, less with... - Page 21 (2) years from purchase when such is purchased from URC. This limited warranty is valid only in the United States of America. URC warrants that the software will substantially conform in any material respect to its functional specifications at the time of delivery.
- Page 22 In the event of any warranty claim, URC will, at its sole option, repair the URC equipment using new or comparable rebuilt parts, or exchange the URC equipment for new or rebuilt equipment.
- Page 23 It is likely that such data, software, or other materials will be lost during service and URC will not be responsible for any such damage or loss. A dated purchase receipt, bill of sale, installation contract or other verifiable proof of purchase is required.
-
Page 24: End User Agreement
PROFITS OR BUSINESS OPPORTUNITY, EVEN IF URC IS ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL URC BE LIABLE FOR LOSS OF OR DAMAGE TO DATA, COMPUTER SYSTEMS OR COMPUTER PROGRAMS. URC'S LIABILITY, IF ANY, FOR DIRECT... -
Page 25: Precautions And Information Concerning Rechargeable Lithium Polymer Batteries
MX-HomePro MXHP-R500 Remote Control RIGHTS WHICH VARY FROM STATE TO STATE OR JURISDICTION TO JURISDICTION. End User Agreement The terms and conditions of the End User Agreement are available at www.universalremote.com/eua.php shall apply. Precautions and Information Concerning Rechargeable Lithium Polymer Batteries ●... - Page 26 MX-HomePro MXHP-R500 Remote Control guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is...
- Page 27 MX-HomePro MXHP-R500 Remote Control Federal Communication Commission (FCC) Radiation Exposure Statement This remote device is approved as a hand-held and hand- operated only portable (relative to hand) device which is normally operated at 5 cm from a person's body.
