EEI–2934
THREE SEATER
Thank you for purchasing the MODWAY THREE SEATER!
Before you start, here are some helpful advice:
1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2.Owing to the size and weight of the three seater, we recommend that it is assembled by two adults, on a
carpeted or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3.Please do not use any tools other than those provided or recommended in these instructions.
4.Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5.Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6.Please keep all pieces out of reach of small children.
Component:
1
7
3
Customer Service 908-368-1025 www.modwayfurniture.com
5
5
6
7
1
7
2
8
2
8
︱
Hardware:
A
B
5
6
6
1
4
2
Bolt M8x40mm
x 16
Allen Wrench M5
x 1
1. Chair Back
x6
2. Chair Seat
x3
3. Left Frame
x1
4. Right Frame
x1
5. Back Cushion
x3
6. Seat Cushion
x3
7. Batyline
x3
8. Middle Frame
x1
Page 1 of 5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for modway EEI–2934
Summary of Contents for modway EEI–2934
- Page 1 EEI–2934 THREE SEATER Thank you for purchasing the MODWAY THREE SEATER! Before you start, here are some helpful advice: 1.We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. 2.Owing to the size and weight of the three seater, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 EEI–2934 THREE SEATER STEP 1: Please assembled middle seater first including the back side. Please put left side top and bottom wooden bar trough pre drilled holes one by one. Insert wooden bar or Chair Back (1) and Chair Seat (2) on Middle Frame (8). STEP 2: Insert 2 pieces of Bolt (A) into the pre-drilled holes on Chair seat (2) through the top pre-drilled holes on Middle Frame (8).
- Page 3 EEI–2934 THREE SEATER STEP 3: Insert Batyline fabric (7) on wooden bar. STEP 4: Carefully position Left Frame (3) to the assembled Chair Back (1) and Chair Seat (2) as shown. Insert the tenon on Chair Back (1) and Chair Seat (2) into the rabbet on Left Frame (3). Customer Service 908-368-1025 www.modwayfurniture.com Page 3 of 5...
- Page 4 EEI–2934 THREE SEATER STEP 5: Insert 2 pieces of Bolt (A) into the pre-drilled holes on Chair Back (1) through the top pre-drilled holes on Left Frame (3). Insert 2 piece of Bolt (A) into the pre-drilled holes on Chair Seat (2) through the top pre-drilled holes on Left Frame (3).
- Page 5 EEI–2934 THREE SEATER STEP 7: Carefully position Right Frame (4) to the assembled Chair Back (1) and Chair Seat (2) as shown. Insert the tenon on Chair Back (1) and Chair Seat (2) into the rabbet on Right Frame (4). Insert 2 pieces of Bolt (A) into the pre-drilled holes on Chair Back (1) through the top pre-drilled holes on Right Frame (4).
