WorkForce®1
Model WF1
User's Information
Top LED Indicators (4)
Side Button
Emergency
Alarm
Button
System Status
Indicators
(4 Side LEDs)
Grace Industries, Inc.
Top Button
Antenna
WorkForce® model WF1 is a worker-worn
motion-sensing Man-Down Alarm that uses
independent, high performance RF (radio-
frequency) wireless signaling to help protect
workers in dangerous and hazardous environ-
ments.
WorkForce® provides real-time motion-sensing,
including fall-detection, and contains an Emer-
gency Alarm Button to immediately transmit a
distress alarm signal.
WorkForce® Alarm Monitoring (AM) version
also receives distress alarm signals from other
workers equipped with WorkForce® and alerts
the user with audible and visual indicators.
Other emergency signaling features of Work-
Force® include Evacuate, PAR, Roll-Call and
optional Out-of-Range indication.
A complete worker safety system can be
achieved by using additional Grace monitoring
products with locating capabilities.
Side Button
Alarm Ring
LEDs
Piezo
Sounder
Micro B USB Connection
for Confi guration
and Battery Charging
Rear View
with Grip Clip
for attachment
WorkForce WF-1-H UI 2019-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WorkForce 1 and is the answer not in the manual?

Questions and answers

Related Manuals for Grace Industries WorkForce 1

Summary of Contents for Grace Industries WorkForce 1

  • Page 1 Side Button Rear View Emergency with Grip Clip Alarm for attachment Alarm Ring Button LEDs System Status Piezo Indicators Sounder (4 Side LEDs) Micro B USB Connection for Confi guration and Battery Charging Grace Industries, Inc. WorkForce WF-1-H UI 2019-12...
  • Page 2 (90 seconds to Alarm used for example) Alarm Inhibit Timer: When WorkForce® receives an alarm message from another GRACE Industries device and that alarm is cleared, the Alarm ACTIVATING WorkForce®: Simultaneously pressing both side buttons turns Inhibit Timer provides a 30 second period of time where the WorkForce®...
  • Page 3 • Audio Alarm pauses briefl y as an aid for determining direction when personnel need assistance. < 10% 10-25% 26-50% 51-75% 76-100% • Radio LED fl ashes Green when transmitting the emergency radio signal. Battery Battery Battery Battery Battery Power Power Power Power Power Grace Industries, Inc.

  • Page 4: Battery Charging

    System Status LEDs will indicate the current level of charge. • Battery fully charged: All 4 LEDs will blink Green • Partially charged: While charging, these LEDs will cycle from #4 up to the current Battery Power Level. Grace Industries, Inc.

  • Page 5: Specifications

    (2) l’utilisateur de l’appareil doit accepter which case the user will be required to correct the interference at tout brouillage radioélectrique subi, même si le brouillage est his own expense. susceptible d’en compromettre le fonctionnement. Grace Industries, Inc.

  • Page 6: Warranty Information

    This warranty is void if any attempt to repair or replace parts was made or attempted by other than qualifi ed Grace Industries, Inc. personnel. This warranty is void if any of the sealed compartments are opened or tampered with.
  • Page 7 This Page is Intentionally Blank - except for this part - Grace Industries, Inc.
  • Page 8 305 Bend Hill Road, Fredonia, PA 16124 USA www.graceloneworker.com (724)-962-9231 Grace Industries, Inc.
