Epson PictureMate Deluxe Viewer Edition Product Information

Epson picturemate deluxe viewer: product information
Hide thumbs Also See for PictureMate Deluxe Viewer Edition:
Table of Contents

Advertisement

Quick Links

Printer Parts

Power light
On button
Menu
button
Back button
Menu navigation
buttons
Control Panel
Handle
Paper
support
Front
EXT/IF (USB) port for
cameras, external drive, or
optional Bluetooth Adapter
USB port for
computer
Photo cartridge
Back
Zoom
buttons
Cancel
button
Memory
card light
Print button
viewer
screen
Memory
card door
Output
tray
Battery cover
AC inlet
Cartridge door
PictureMate Deluxe Viewer Edition
Accessories
PictureMate Print Pack (part# T5570)
Includes 100 sheets of PicureMate Photo Paper and a
PictureMate Photo Cartridge
PictureMate Deluxe Viewer Edition
Rechargeable Battery (part# C12C831074)
Enables printing outdoors or in other places without
convenient electrical outlets
PictureMate Deluxe Viewer Edition
Carrying Case
Soft case that holds PictureMate, power cable, extra
PictureMate Print Pack, and more
Epson Bluetooth Photo Print Adapter
(part# C12C824142)
Allows printing wirelessly from Bluetooth-enabled cell
phones, PDAs, or computers to PictureMate
Printer Specifications
Printing
Nozzle
configuration
90 nozzles × 6: yellow, magenta, cyan,
photo black, red, blue
Print direction
Bidirectional with logic seeking
Control code
ESC/P Raster, EPSON Remote command
Input buffer
64KB
Mechanical
Paper capacity
20 sheets
Dimensions
Storage
Width: 10.0 inches (256 mm)
Depth: 6.1 inches (154 mm)
Height: 6.6 inches (167 mm)
Printing
Width: 10.0 inches (256 mm)
Depth: 12.0 inches (305 mm)
Height: 6.6 inches (167 mm)
Weight
6.2 lb (2.8 kg) without photo cartridge or
battery
4/05
PictureMate Deluxe Viewer Edition
- 1
