SuperServer
®
9029GP-TNVRT
USER'S MANUAL
Revision 1.0a

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SUPERSERVER 9029GP-TNVRT

Summary of Contents for Supermicro SUPERSERVER 9029GP-TNVRT

  • Page 1 SuperServer ® 9029GP-TNVRT USER’S MANUAL Revision 1.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/...

  • Page 4: Table Of Contents

    SuperServer 9029GP-TNVRT User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 Rear Features ........................12 Chassis Trays ........................14 1.5 Motherboard Layout ......................15 Quick Reference Table ......................16...
  • Page 5 Contents Creating the Processor Carrier Assembly ..............35 Assembling the Processor Heatsink Module ..............36 Preparing the CPU Socket for Installation..............37 Installing the Processor Heatsink Module ..............38 Memory ..........................39 Memory Support ......................39 Memory Population Guidelines ..................40 Memory Population Sequence ..................40 Installing Memory ......................43 Motherboard Battery ......................44 3.4 Chassis Components ......................45 Installing the GPU Trays ....................45...
  • Page 6 SuperServer 9029GP-TNVRT User's Manual 5.3 SuperDoctor 5 ........................67 ® 5.4 IPMI ............................68 Chapter 6 UEFI BIOS 6.1 Introduction .........................69 Starting BIOS Setup Utility ....................69 6.2 Main Setup .........................69 6.3 Advanced Setup Configurations ..................71 6.4 Event Logs .........................99 6.5 IPMI ..........................101 6.6 Security ..........................104...
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Overview

    SuperServer 9029GP-TNVRT User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the 9029GP-TNVRT SuperServer. The system is 10U, supporting 16 NVIDIA Tesla V100 GPUs. Sixteen GPUs are distributed evenly between two compute nodes (trays) and work as a single unified 2-petaFLOP system.

  • Page 9: System Features

    Two Intel Xeon Scalable processors, supporting Intel UltraPath Interconnect (UPI) of up to 10.4 GT/s; Note: The Intel Xeon Processor Scalable Family includes Platinum 8100 processors, Gold 6100/5100 processors, Silver 4100 processors, and Bronze 3100 processors. For the latest CPU/memory updates, refer to our website at http://www.supermicro.com/products/motherboard/Xeon/C620/X11DPG-HGX2.cfm. Socket Type Socket P0-LGA3647 Memory Supports up to 3 TB of DDR4 3DS ECC RDIMM, LRDIMM, in 24 DIMM slots;...

  • Page 10: Server Chassis Features

    SuperServer 9029GP-TNVRT User's Manual 1.4 Server Chassis Features Control Panel Power switches and status indicators are located on the control panel. Figure 1-1. Control Panel View Control Panel Features Item Feature Description Dual color LED power switch: yellow indicates standby, green shows...

  • Page 11: Front Features

    Chapter 1: Introduction Front Features The SC1018G-R12K is a 10U chassis. Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description Control Panel See previous page for details. Sixteen NVMe hot-swap 2.5" storage drive carriers; each has status Drive Bays indicators (see Section 3.4) Fans Eight 9-cm fans and six 8-cm fans...

  • Page 12: Rear Features

    SuperServer 9029GP-TNVRT User's Manual Rear Features Figure 1-3. Chassis Rear View Rear Chassis Features Item Feature Description GPU Trays Each tray holds up to eight GPUs Switch Trays Each tray hold up to eight Network Interface Cards BMC Sticker Sticker shows the BMC default password (see Section 5.4)
  • Page 13 Chapter 1: Introduction Figure 1-4. Rear I/O Ports Input/Output Ports Description Description USB 1 (USB 3.0) LAN1 USB 2 (USB 3.0) LAN2 (shared) IPMI LAN Six NVLink Bridge Assemblies Figure 1-5. Chassis Rear View Showing NVLink Bridge Assemblies NVLink bridge assemblies connect one GPU tray to the other. These must be installed to set up the system (see instructions in Chapter 3).

  • Page 14: Chassis Trays

    SuperServer 9029GP-TNVRT User's Manual Chassis Trays Figure 1-5. Chassis Trays Rear Chassis Trays Item Feature 1, 2 GPU Trays 3, 4 Switch Trays Head Node Tray Power Tray...

  • Page 15: Motherboard Layout

    Chapter 1: Introduction 1.5 Motherboard Layout Below is a layout of the X11DPG-HGX2 with jumper, connector and LED locations shown. See the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. JBM_ JBM_ JBM_ JBM_ E1 E2 E3...

  • Page 16: Quick Reference Table

    SuperServer 9029GP-TNVRT User's Manual Quick Reference Table Jumper Description Default Setting JBR1 Not supported (was BIOS Recovery) JBT1 CMOS Clear Open (Normal) JPL1 LAN port enable Pins 1-2 (Enabled) JPME1 Manufacturing Mode Select Pins 1-2 (Enabled) JPG1 VGA Enable Pins 1-2 (Enabled)

  • Page 17: Other Boards And Bridges

    Chapter 1: Introduction 1.6 Other Boards and Bridges The system also includes: • Switch boards (X11DPG-HGX2-SW)—Provide direct communication between the GPUs and NICs without passing though the CPUs. Note: The two switch boards must always be present for the GPUs and NICs to be detected. •...

  • Page 18: System Block Diagram

    SuperServer 9029GP-TNVRT User's Manual 1.7 System Block Diagram C C P P U U N N O O D D E E 2x M.2 NVMe CPU1 CPU2 Lower Slot Upper Slot S S W W I I T T C C H H # # 1 1...

  • Page 19: Chapter 2 Rack Installation

    Chapter 2: Rack Installation Chapter 2 Rack Installation This chapter provides advice and instructions for mounting your system in a rack. Caution: Equipment installalation should be conducted by service or trained person. 2.1 Preparing for Setup The box in which the system was shipped should include the hardware needed to install it into the rack.

  • Page 20: Server Precautions

    SuperServer 9029GP-TNVRT User's Manual Server Precautions • Caution: The assembled system may weigh over 400 lbs. When moving it, remove the GPU trays to reduce weight, and use a lift and multiple people. • Review the electrical and general safety precautions in Chapter 3.

  • Page 21: Reliable Ground

    Chapter 2: Rack Installation Reliable Ground A reliable ground must be maintained at all times. To ensure this, the rack itself should be grounded. Particular attention should be given to power supply connections other than the direct connections to the branch circuit (i.e. the use of power strips, etc.). To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable.

  • Page 22: Installing The Rails

    SuperServer 9029GP-TNVRT User's Manual 2.2 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. Also refer to the installation instructions that came with the rack. This rail set fits a rack between 28" and 33.5" deep. Do not use a two post "telco" type rack.

  • Page 23: Installing The Server

    Chapter 2: Rack Installation Figure 2-2. Installing the Left Rail 2.3 Installing the Server Caution: The assembled system may weigh over 400 lbs. Use a lift and multiple people to move it. 1. If you want to install the optional chassis handles, use screws including a thumbscrew through the bottom hole of each handle.
  • Page 24 SuperServer 9029GP-TNVRT User's Manual Figure 2-3. Installing the Server onto the Rails...

  • Page 25: Chapter 3 Component Installation And Maintenance

    Chapter 3: Component Installation and Maintenance Chapter 3 Component Installation and Maintenance This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and part numbers given. Remove power from the system before installing or replacing components. 3.1 Removing Power Use the following procedure to verify that power has been removed from the system.

  • Page 26: Accessing The System

    SuperServer 9029GP-TNVRT User's Manual 3.2 Accessing the System The system is comprised of six trays. Each tray can be removed from the chassis using release levers. Before removing the trays, power down, as described in Section 3.1. Figure 3-1. Chassis Rear with Trays Out...
  • Page 27 Chapter 3: Component Installation and Maintenance Figure 3-2. Tray Levers Released...
  • Page 28 SuperServer 9029GP-TNVRT User's Manual Removing a GPU Tray 1. Remove the NVLink bridge assemblies, as described in this chapter, Section 3.4. 2. On the release levers, remove the locking screws, one each side 3. Press the release lever latches outward and pull the levers.
  • Page 29 Chapter 3: Component Installation and Maintenance Removing a Switch Tray 1. On the release levers, remove the locking screws, one each side 2. Use the tab on the edge of the lever to rotate the lever out. 3. Use the levers to pull out the tray. Note: When re-inserting the tray, be sure the levers are in the fully open positions.
  • Page 30 SuperServer 9029GP-TNVRT User's Manual Removing the Head Node (motherboard) Tray • On the release lever on the right side, press the outward and pull out the tray. Note: When re-inserting the tray, be sure the levers are in the fully open positions.
  • Page 31 Chapter 3: Component Installation and Maintenance Removing the Power Supply Tray 1. On the each side of the chassis, remove the two locking screws. 2. Press the release lever latches outward and pull the levers. Locking screws Figure 3-6. Locking Screws for the Power Supply Tray 3.
  • Page 32 SuperServer 9029GP-TNVRT User's Manual Removing the Chassis Top Section One section of the chassis top can be removed. This is useful when removing the midplane. 1. On the each side of the chassis, remove the locking screws. 2. Pull up on the two release levers and lift off the top section.

  • Page 33: Motherboard Components

    Thermal grease is pre-applied on a new heatsink. No additional thermal grease is needed. • Refer to the Supermicro website for updates on processor support. • All graphics in this manual are for illustration only. Your components may look different.

  • Page 34: Overview Of The Processor Heatsink Module

    SuperServer 9029GP-TNVRT User's Manual Overview of the Processor Heatsink Module The Processor Heatsink Module (PHM) contains a heatsink, a processor carrier assembly. Heatsink with Thermal Grease Processor Carrier Processor Processor Heatsink Module Bottom View...

  • Page 35: Creating The Processor Carrier Assembly

    Chapter 3: Component Installation and Maintenance Creating the Processor Carrier Assembly To install a processor into the processor carrier, follow the steps below: 1. Hold the processor with the LGA lands (gold contacts) facing up. Locate the small, gold triangle in the corner of the processor and the corresponding hollowed triangle on the processor carrier.

  • Page 36: Assembling The Processor Heatsink Module

    SuperServer 9029GP-TNVRT User's Manual Assembling the Processor Heatsink Module After creating the processor carrier assembly, mount it onto the heatsink to create the processor heatsink module (PHM): 1. Note the label on top of the heatsink, which marks the heatsink mounting holes as 1, 2, 3, and 4.

  • Page 37: Preparing The Cpu Socket For Installation

    Chapter 3: Component Installation and Maintenance Preparing the CPU Socket for Installation This motherboard comes with a plastic protective cover on the CPU socket. Remove it carefully to install the Processor Heatsink Module (PHM). CPU Socket with Plastic Protective Cover Remove the plastic protective cover from the CPU socket.

  • Page 38: Installing The Processor Heatsink Module

    SuperServer 9029GP-TNVRT User's Manual Installing the Processor Heatsink Module After assembling the Processor Heatsink Module (PHM), install it onto the CPU socket: 1. Align hole 1 of the heatsink with the printed triangle on the CPU socket. See the left image below.

  • Page 39: Memory

    Memory Support The X11DPG-HGX2 motherboard offers 24 slots that support up to 3 TB of DDR4 3DS LRDIMM/LRDIMM/RDIMM ECC 2666 MHz modules. Check the Supermicro website for possible updates to memory support. DDR4 Memory Support for the Intel Xeon Scalable processor...

  • Page 40: Memory Population Guidelines

    Then, if using two DIMMs per channel, install the second DIMM in the black slot. The following memory population sequence table was created based on guidelines provided by Intel to support Supermicro motherboards. The diagram is for illustrative purposes; your motherboard may look different.
  • Page 41 Chapter 3: Component Installation and Maintenance Memory Population for the X11 DP Motherboard, 24 DIMM Slots CPUs/DIMMs Memory Population Sequence 1 CPU & 1 DIMM CPU1: P1-DIMMA1 1 CPU & 2 DIMMs CPU1: P1-DIMMA1/P1-DIMMD1 1 CPU & 3 DIMMs CPU1: P1-DIMMC1/P1-DIMMB1/P1-DIMMA1 1 CPU &...
  • Page 42 SuperServer 9029GP-TNVRT User's Manual Note: The diagram below shows DIMM module population for each CPU installed on the motherboard. Install the processors starting with CPU Socket 1. Pin 1 CPU1 CPU2 Figure 3-9. DIMM Slots...

  • Page 43: Installing Memory

    Chapter 3: Component Installation and Maintenance Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge.

  • Page 44: Motherboard Battery

    SuperServer 9029GP-TNVRT User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in Section 3.1 and remove the cover as described in Section 3.2..

  • Page 45: Chassis Components

    Chapter 3: Component Installation and Maintenance 3.4 Chassis Components Installing the GPU Trays The GPUs are installed into the trays by the vendor and shipped separately. You must install the trays. Fully Open Release Lever Figure 3-11. Installing the GPU Trays Installing GPU Trays 1.

  • Page 46: Installing The Nvlink Bridges

    SuperServer 9029GP-TNVRT User's Manual Installing the NVLink Bridges After both GPU trays are installed, they must be connected by the NVLink bridge assemblies. Align- ment Latch Poles Mechanism Figure 3-12. NVLink Bridge Assembly (front and back) Installing a Bridge Assembly 1.

  • Page 47: Switch Trays

    Chapter 3: Component Installation and Maintenance Figure 3-13. Installing an NVLink Bridge Assembly Removing a Bridge Assembly 1. Hold the bridge assembly with both hands, fingers under the assembly and thumbs on top of the latch. 2. Keeping the assembly strictly perpendicular, squeeze to pull the latch down while pulling the assembly straight out from the GPU trays.

  • Page 48: Storage Drives

    If RAID is configured, these drives can be removed or replaced without powering down the system. In addition the system features two internal M.2 SSDs. Note: Enterprise level drives are recommended for use in Supermicro servers. For information on recommended HDDs, visit the Supermicro website at http://www.supermicro.com/products/ nfo/files/storage/SBB-HDDCompList.pdf.
  • Page 49 Chapter 3: Component Installation and Maintenance Removing Drive Carrier 1. Press the release button on the drive carrier to extend the drive carrier handle. 2. Use the handle to pull the drive out of the chassis. Figure 3-14. Removing a Hard Drive Carrier...
  • Page 50 SuperServer 9029GP-TNVRT User's Manual Installing a Drive 1. Remove the screws securing the dummy drive into the drive carrier, and remove the dummy drive. 2. Install a drive into the carrier with the printed circuit board side facing down so that the mounting holes in the drive align with those in the carrier.

  • Page 51: Hot-Swap For Nvme Drives

    Chapter 3: Component Installation and Maintenance Hot-Swap for NVMe Drives Supermicro Ultra servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using IPMI. Note: If you are using VROC, see the VROC appendix in this manual instead.

  • Page 52: Checking The Temperature Of An Nvme Drive

    SuperServer 9029GP-TNVRT User's Manual Checking the Temperature of an NVMe Drive There are two ways to check using IPMI. Checking a Drive • IPMI > Server Health > NVMe SSD – Shows the temperatures of all NVMe drives, as in Figure 3-4.

  • Page 53: System Cooling

    2. Push the release tab and pull the failed fan from the chassis. Fans can be replaced while the system is running. 3. Replace the failed fan with an identical fan, available from Supermicro. Push the new fan into the housing. Note that the fan module top is labelled.

  • Page 54: Air Shroud

    SuperServer 9029GP-TNVRT User's Manual Air Shroud Generally you do not need to remove the air shroud to perform any service on the system. However, if you need to temporarily remove it (the air shroud should always be in place when the system is operating), follow this procedure.

  • Page 55: Power Supply

    The failed power module can be replaced without powering-down the system. Replace with the same model. Replacement modules can be ordered directly from Supermicro. An amber light on the power supply is illuminated when the power is switched off. An green light indicates that the power supply is operating normally.

  • Page 56: Expansion Card Installation

    SuperServer 9029GP-TNVRT User's Manual Expansion Card Installation The system includes support for two PCIe expansion cards using pre-installed riser cards. Installing External PCI Expansion Cards 1. Power down the system as described in Section 3.1 and remove the motherboard tray.

  • Page 57: Removing The Mid-Plane

    Chapter 3: Component Installation and Maintenance Removing the Mid-Plane In unusual case that the mid-plane must be removed: 1. Power down as described in Section 3.1 and remove the chassis top cover. 2. Remove all trays from the rear of the chassis as described in Section 3.2. 3.

  • Page 58: Chapter 4 Motherboard Connections

    SuperServer 9029GP-TNVRT User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 59 Chapter 4: Motherboard Connections RAID Key Header A RAID Key header is located at JRK1 on the motherboard. It supports VMD used in creating optional advanced NVMe RAID configurations. (See NVMe/VROC appendix.) Intel RAID Key Pin Definitions Pin# Definition Ground 3.3V Standby Ground PCH RAID Key...

  • Page 60: Ports

    SuperServer 9029GP-TNVRT User's Manual 4.3 Ports Figure 4-2. Rear I/O Ports Input/Output Ports Description Description USB 1 (USB 3.0) LAN1 USB 2 (USB 3.0) LAN2 IPMI LAN Network Ports Two 10 Gb LAN ports (LAN1,LAN2) provide contact with a network.

  • Page 61: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 62 SuperServer 9029GP-TNVRT User's Manual LAN Port Enable/Disable Change the setting of jumpers JPL1 to enable or disable the LAN chip. The default setting is Enabled. LAN Port Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled Pins 2-3 Disabled Management Engine (ME) Recovery...

  • Page 63: Led Indicators

    Chapter 4: Motherboard Connections BIOS Recovery Close pins 2-3 of jumper JBR1 for BIOS recovery. The default setting is on pins 1 and 2 for normal operation. BIOS Recovery Jumper Settings Jumper Setting Definition Pins 1-2 Normal Pins 2-3 BIOS Recovery 4.5 LED Indicators LAN LEDs The Ethernet ports each have two LEDs.

  • Page 64: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 65 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 66: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or a DVD.

  • Page 67: Superdoctor 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 68: Ipmi

    SuperServer 9029GP-TNVRT User's Manual 5.4 IPMI The X11DPG-HGX2 supports the Intelligent Platform Management Interface (IPMI). IPMI provides remote access, monitoring and management through the baseboard management controller (BMC) and other management controllers distributed among different system modules. There are several BIOS settings that are related to IPMI.

  • Page 69: Chapter 6 Uefi Bios

    Chapter 6 UEFI BIOS Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the UEFI BIOS setup utility and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted since this manual was published.
  • Page 70 SuperServer 9029GP-TNVRT User's Manual The Main tab page allows you to set the date and time, and it displays system information. System Date/System Time Use this option to change the system date and time. Highlight System Date or System Time using the arrow keys.

  • Page 71: Advanced Setup Configurations

    Chapter 6 UEFI BIOS 6.3 Advanced Setup Configurations Use the arrow keys to select the Advanced tab and press <Enter> to access the submenu items. Caution: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable. If this occurs, revert to the manufacture default settings.
  • Page 72 SuperServer 9029GP-TNVRT User's Manual Bootup NumLock State Use this feature to set the Power-on state for the Numlock key. The options are Off and On. Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled.
  • Page 73 Chapter 6 UEFI BIOS CPU Configuration  Warning: Setting the wrong values in the following sections may cause the system to malfunction. Processor Configuration The following CPU information will be displayed: • Processor BSP Revision • Processor Socket • Processor ID •...
  • Page 74 SuperServer 9029GP-TNVRT User's Manual PPIN Control Select Unlock/Enable to use the Protected-Processor Inventory Number (PPIN) in the system. The options are Unlock/Enable and Unlock/Disable. Hardware Prefetcher (Available when supported by the CPU) If this feature is set to Enable, the hardware prefetcher will prefetch streams of data and instructions from the main memory to the Level 2 (L2) cache to improve CPU performance.
  • Page 75 Chapter 6 UEFI BIOS Advanced Power Management Configuration  Power Technology Select Energy Efficient to support power-saving mode. Select Custom to customize system power settings. Select Disabled to disable power-saving settings. The options are Disable, Energy Efficient, and Custom. The following items are configurable if Custom is selected above. Power Performance Tuning Select BIOS to allow the system BIOS to configure the Power-Performance Tuning BIAS setting below.
  • Page 76 SuperServer 9029GP-TNVRT User's Manual Turbo Mode Select Enable for processor cores to run faster than the frequency specified by the manufacturer. The options are Disable and Enable. Hardware PM (Power Management) State Control  Hardware P-States If this feature is set to Disable, the hardware power management will choose a P-state setting for the system based on an OS request.
  • Page 77 Chapter 6 UEFI BIOS CPU T State Control  Software Controlled T-States If this feature is set to Enable, CPU throttling settings will be supported by the software of the system. The options are Enable and Disable. Chipset Configuration  North Bridge ...
  • Page 78 SuperServer 9029GP-TNVRT User's Manual Isoc Mode Select Enable to enable Isochronous support to meet QoS (Quality of Service) require- ments. This feature is especially important for Virtualization Technology. The options are Disable, Enable, and Auto. SNC (Sub NUMA Cluster) Select Enable for Sub-NUMA (Non-uniform memory access) Cluster support. Select Auto for 1-cluster or 2-cluster support depending on the status of IMC (Integrated Memory Controller) Interleaving.
  • Page 79 Chapter 6 UEFI BIOS IMC Interleaving Use this feature to configure interleaving settings for the Integrated Memory Controller (IMC), which can improve memory performance. The options are Auto, 1-way Interleave, or 2-way Interleave. Data Scrambling for DDR4 Select Enable to enable data scrambling for DDR4 memory to enhance system perfor- mance and security.
  • Page 80 SuperServer 9029GP-TNVRT User's Manual Memory RAS Configuration  Use this submenu to configure Memory RAS (Reliability, Availability, Serviceability) settings: Static Virtual Lockstep Mode Select Enable to support Static Virtual Lockstep mode to enhance memory performance. The options are Disable and Enable.
  • Page 81 Chapter 6 UEFI BIOS out after an SDDC event has occurred. After the event, the SDDC+1 ECC mode is activated to protect against any additional memory failure caused by a ‘single-bit’ error in the same memory rank. The options are Disable and Enable*. (The option "Enable" can be set as default when it is supported by the motherboard.) ADDDC (Adaptive Double Device Data Correction) Sparing (Available when this feature is supported by the CPU and Intel Run Sure is set to...
  • Page 82 SuperServer 9029GP-TNVRT User's Manual IOU2 (IIO PCIe Br3) This feature configures the PCI-E Bifurcation setting for a PCI-E port specified by the user. The options are x4x4x4x4, x4x4x8, x8x4x4, x8x8, x16, and Auto. MCP0 (IIO PCIe Br4) This feature configures the PCI-E Bifurcation setting for a PCI-E port specified by the user.
  • Page 83 Chapter 6 UEFI BIOS Socket 1 PCI-E Br0D00F0 – Port 0 Socket 1 PcieBr1D00F0 – Port 1A Socket 1 PcieBr2D00F0 – Port 2A Socket 1 PcieBr3D00F0 – Port 3A Socket 1 PcieBr4D00F0 – MCP 0 Socket 1 PcieBr5D00F0 – MCP 1 (Above available for CPU 2 Configuration only) PCI-E Port The Auto mode (default) removes the EXP port if there is no device, or errors on that...
  • Page 84 SuperServer 9029GP-TNVRT User's Manual Prioritize TPH If TPH is not disabled, select Enable to prioritize the TPL requests. The options are Enable and Disable. Relaxed Ordering Select Enable to allow certain transactions to be processed and completed before other transactions that have already been enqueued. The options are Disable and Enable.
  • Page 85 Chapter 6 UEFI BIOS II0-PCIE Express Global Options PCIe Hot Plug Select Enable to support Hot-plugging for the selected PCI-E slots which will allow the user to replace the devices installed in the slots without shutting down the system. The options are Enable, Disable, Auto, and Manual.
  • Page 86 SuperServer 9029GP-TNVRT User's Manual Server ME (Management Engine) Configuration  This feature displays the following system ME configuration settings. • Operational Firmware Version • Backup Firmware Version • Recovery Firmware Version • ME Firmware Status #1/ME Firmware Status #2 •...
  • Page 87 Chapter 6 UEFI BIOS SATA Port 0 – SATA Port 7 Hot Plug Select Enable to support Hot-plugging for the device installed on a selected SATA port which will allow the user to replace the device installed in the slot without shutting down the system.
  • Page 88 SuperServer 9029GP-TNVRT User's Manual I/O inactivity, and will return the link to an active state when I/O activity resumes. The options are Enable and Disable. sSATA Port 0 – sSATA Port 7 Hot Plug Select Enable to support Hot-plugging for the device installed on a selected SATA port which will allow the user to replace the device installed in the slot without shutting down the system.
  • Page 89 Chapter 6 UEFI BIOS PCI PERR/SERR Support Select Enabled to log the runtime error event when a PERR (PCI/PCI-E Parity Error) error or an SERR (System Error) error has occurred to a PCI-E device. The options are Enabled and Disabled. Maximum Read Request Select Auto for the system BIOS to automatically set the maximum size for a read request for a PCI-E device to enhance system performance.
  • Page 90 SuperServer 9029GP-TNVRT User's Manual  Network Stack Configuration Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Unified Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. *If "Network Stack" is set to Enabled, the following items will display: Ipv4 PXE Support Select Enabled to enable Ipv4 PXE boot support.
  • Page 91 Chapter 6 UEFI BIOS Device Settings This feature displays the base I/O port address and the Interrupt Request address of a serial port specified by the user. Change Settings This feature specifies the base I/O port address and the Interrupt Request address of Serial Port 1.
  • Page 92 SuperServer 9029GP-TNVRT User's Manual Bits Per second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines.
  • Page 93 Chapter 6 UEFI BIOS Putty KeyPad This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SCO, ESCN, and VT400. Redirection After BIOS Post Use this feature to enable or disable legacy Console Redirection after BIOS POST.
  • Page 94 SuperServer 9029GP-TNVRT User's Manual mark as a parity bit to be sent along with the data bits. Select Space to add a Space as a parity bit to be sent with your data bits. The options are None, Even, Odd, Mark and Space.
  • Page 95 Chapter 6 UEFI BIOS Legacy Console Redirection Settings  Legacy Serial Redirection Port Select the COM port to display redirection of Legacy OS and Legacy OPROM messages. The options are COM1 and COM2/SOL. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) The submenu allows the user to configure Console Redirection settings to support Out-of- Band Serial Port management.
  • Page 96 SuperServer 9029GP-TNVRT User's Manual ACPI Settings  Use this feature to configure Advanced Configuration and Power Interface (ACPI) power management settings for your system. NUMA Support (Available when the OS supports this feature) Select Enabled to enable Non-Uniform Memory Access support to enhance system perfor- mance.
  • Page 97 Chapter 6 UEFI BIOS • Active PCR Banks • Available PCR Banks Pending Operation Use this feature to schedule a TPM-related operation to be performed by a security (TPM) device at the next system boot to enhance system data integrity. Your system will reboot to carry out a pending TPM operation.
  • Page 98 SuperServer 9029GP-TNVRT User's Manual Endorsement Hierarchy Select Enabled for Endorsement Hierarchy support, which provides separate controls to address the user's privacy concerns because the primary keys in this hierarchy are certified by the TPM or a manufacturer to be used only in an authentic TPM device that is attached to an authentic platform.

  • Page 99: Event Logs

    Chapter 6 UEFI BIOS 6.4 Event Logs Use this tab page to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot. The options are Enabled and Disabled. Erasing Settings (can be changed when Smbios Event Log is enabled) Erase Event Log Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log...
  • Page 100 SuperServer 9029GP-TNVRT User's Manual SMBIOS Event Log Standard Settings (can be changed when Smbios Event Log is enabled) Log System Boot Event Select Enabled to log system boot events. The options are Enabled and Disabled. MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter.

  • Page 101: Ipmi

    Chapter 6 UEFI BIOS 6.5 IPMI Use this tab page to configure Intelligent Platform Management Interface (IPMI) settings. The following items will be displayed: • IPMI Firmware Revision: This feature indicates the firmware revision of the BMC (Baseboard Management Controller) used in your system. •...
  • Page 102 SuperServer 9029GP-TNVRT User's Manual When SEL is Full This feature allows the user to specify what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
  • Page 103 Chapter 6 UEFI BIOS When Static is selected, the user must manually enter the following values. • Station IP Address • Subnet Mask • Gateway IP Address...

  • Page 104: Security

    SuperServer 9029GP-TNVRT User's Manual 6.6 Security Use this tab page to configure Security settings. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long.
  • Page 105 Chapter 6 UEFI BIOS Attempt Secure Boot If this feature is set to Enabled, Secure Boot will be activated when a Platform Key (PK) is entered. A Platform Key is a security key used to manage the security settings of the platform firmware used in your system.
  • Page 106 SuperServer 9029GP-TNVRT User's Manual Key Exchange Keys  This feature allows the user to enter and configure a set of values to be used as a Key-Exchange-Keys for the system. This set of values also indicate the size, the keys numbers, and the key source of the Key-Exchange-Keys.

  • Page 107: Boot

    Chapter 6 UEFI BIOS 6.7 Boot Use this tab page to configure Boot Settings. Boot Mode Select Use this feature to select the type of devices to be used for system boot. The options are Legacy, UEFI (Unified Extensible Firmware Interface), and Dual. Fixed Boot Order Priorities This feature prioritizes the order of a bootable device from which the system will boot from the top of the list to the bottom.
  • Page 108 SuperServer 9029GP-TNVRT User's Manual Delete Drive Option Select the target boot driver to delete from the boot priority list.  UEFI Application Boot Priorities Boot Option #1 Choose UEFI: Built-in EFI Shell or Disabled.  Network Drive BBS Priorities Boot Option #1...

  • Page 109: Save & Exit

    Chapter 6 UEFI BIOS 6.8 Save & Exit Use this tab page to configure Save & Exit settings. Save Options Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration and reboot the computer.
  • Page 110 SuperServer 9029GP-TNVRT User's Manual Default Options Restore Optimized Defaults To load manufacturer default settings which are intended for maximum system performance but not for maximum stability, select and press <Enter>. Save As User Defaults To enable the user to save any changes to the BIOS setup for future use, select and press <Enter>.

  • Page 111: Appendix A Bios Error Codes

    When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 112: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 113 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 114 SuperServer 9029GP-TNVRT User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 115 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 116 SuperServer 9029GP-TNVRT User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 117 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 118 SuperServer 9029GP-TNVRT User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...
  • Page 119 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 120 SuperServer 9029GP-TNVRT User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 121 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 122 SuperServer 9029GP-TNVRT User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 123 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 124 SuperServer 9029GP-TNVRT User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 125 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 126 SuperServer 9029GP-TNVRT User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 127 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 128 SuperServer 9029GP-TNVRT User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 129 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 130 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 131 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 132: Appendix C System Specifications

    SuperServer 9029GP-TNVRT User's Manual Appendix C System Specifications Processors Dual Intel Xeon Scalable processors (non-Fabric model only) in a Socket P0-LGA3647 Chipset Intel C621 BIOS 64 MB SPI AMI BIOS SM Flash UEFI BIOS Memory Supports up to 3 TB of DDR4 3DS ECC RDIMM, LRDIMM, in 24 DIMM slots; up to 2666MHz...
  • Page 133 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Part 15 Subpart B, Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Delegated Directive (EU) 2015/863 and Directive 2012/19/EU...

  • Page 134: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 135 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 136 SuperServer 9029GP-TNVRT User Manual 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 137 Appendix D: UEFI BIOS Recovery 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
  • Page 138 SuperServer 9029GP-TNVRT User Manual 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process.

  • Page 139: Appendix E Crash Dump Using Ipmi

    In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. For this purpose you can download a crash dump of status information using IPMI. The IPMI manual is available at https://www.supermicro.com/ solutions/IPMI.cfm.
  • Page 140 SuperServer 9029GP-TNVRT User's Manual Downloading the Crash Dump File 1. In the IPMI interface, click the Miscellanous tab, then the Trouble Shooting option. 2. Click the Dump button and wait five minutes for the file to be created. (No confirm ation message will appear.)

  • Page 141: Appendix F Cpu-Based Raid For Nvme

    Appendix F CPU-Based RAID for NVMe Appendix F CPU-Based RAID for NVMe Intel Virtual RAID on CPU (Intel VROC) is an enterprise RAID solution for NVMe SSDs ® directly attached to Intel Xeon Scalable processors. Intel Volume Management Device (VMD) is an integrated controller inside the CPU PCIe root complex.
  • Page 142 SuperServer 9029GP-TNVRT User's Manual Additional Information Additional information is available on the product page for the Supermicro add-on card and the linked manuals. www.supermicro.com/products/accessories/addon/AOC-VROCxxxMOD.cfm F.1 Hardware Key The Intel VROC hardware key is a license key that detects the Intel VROC SKU and activates the function accordingly.
  • Page 143 Appendix F CPU-Based RAID for NVMe F.2 Enabling NVMe RAID RAID for NVMe SSDs must be enabled through the UEFI BIOS. 1. Install the patch as described in the Restrictions and Requirements section on a previous page. 2. Reboot the server. 3.
  • Page 144 SuperServer 9029GP-TNVRT User's Manual 6. Press [F4] to save the configuration and reboot the system. 7. Press [DEL] to enter BIOS. 8. Switch to Advanced > Intel® Virtual RAID on CPU > All Intel VMD Controllers > Create RAID Volume.
  • Page 145 Appendix F CPU-Based RAID for NVMe F.3 Status Indications An LED indicator on the drive carrier shows the RAID status of the drive. Drive Carrier Status LED Indicator Status State (red) Normal function Locating 4 Hz blink Fault Solid on Rebuilding 1 Hz Blink IBPI SFF 8489 Defined Status LED States...

Table of Contents
