- Page 1 Disney McQueen 2 in 1 Car Troubleshooting Guide...
- Page 2 Please follow the directions in the attached service guide to check the connections on your ride on. Most times it is a loose plug or switch that causes electric ride’s to stop working. Keep in mind the ride will not operate if the power adaptor/charger cable is plugged into the ride, this is a safety feature to ensure a child does not take off while it’s plugged in and damage it.
-
Page 3: Troubleshooting Guide
TROUBLE SHOOTING GUIDE Item#: 8736 Description: CARS MOTORISED RIDE ON step2 step2 step1 step1 step3 step4 1. Per above steps to check the forward/revise switch connection... - Page 4 step1(from the bottom) step2 step3 step4 step5 step6 2.Per above steps to take off the dashboard before checking the power switch and plugs for switches...
- Page 5 step1 step2 step3 step4 step5 3.Per above steps to check the pedal switch connection...
- Page 6 step1 step2 step3 step4 step5 step6 4.per above steps to check the internal wire and plug is connected, and make sure the fuse is connected Please pay attention during installation and disassembly.
- Page 7 MOTOR PLUG – PIN TROUBLESHOOT No. Pin pushed to side. Yes. Pin is central. When plugged together the pin is not connecting with other plug.
