- Page 1 ZPV002 MINI CAR SERVICE GUIDE...
- Page 2 Please follow the directions in the attached service guide to check the connections on your ride on. Most times it is a loose plug or switch that causes electric ride’s to stop working. Keep in mind the ride will not operate if the power adaptor/charger cable is plugged into the ride, this is a safety feature to ensure a child does not take off while it’s plugged in and damage it.
- Page 3 Item #: 4233 Model: ZPV002 description :PAW PATROL 、 step4 step1 step2 step3 step5 step8 step6 step7 step8 step9 step10 1.pls check if the power switch is connected like image shown...
- Page 4 step1 step2 step3 step4 step5 step6 step7 step8 step9 step10. step11 step12. 2. open the seat ,then unlock the screws check the auto-set fuse connection...
- Page 5 step1 step2 step3 step4 step5 step6 step7 3.replace the gear box a.Per the above step ,unlock the screws b.disconnect the plug of the battery and gear box c.disconnect the battery wire.the disassemble the driving wheel and rear wheel ,then pull out the rear axle d.unlock the screws of the grey plastic box ,then open it to get the gear box...
- Page 6 step1 step2 step3 step4 step5 step6 step7. step8. 4. turn over the vehicle ,to check if the pedal switch is connected step9. step10.
- Page 7 MOTOR PLUG – PIN TROUBLESHOOT No. Pin pushed to side. Yes. Pin is central. When plugged together the pin is not connecting with other plug.
