MX0048
4x4 HDMI Seamless Matrix Switcher
INTRODUCTION
MX0048 è un sistema matriciale di elaborazione video HDMI ad alta velocità che può essere facilmente configurato e
controllato per varie applicazioni in tre differenti modalità di uscita (Matrice, Dual e Video Wall).
Nel modo Matrice il funzionamento è quello tipico di una normale matrice. Nel Dual mode, 2 ingressi vengono visualizzati
in modo POP su una uscita con la particolarità che 2 uscite visualizzano lo stesso segnale. Esse sono per default la 1-2 e
la 3-4. Il Video wall, come è intuibile, visualizza una sola delle 4 sorgenti allargata sui 4 monitor di uscita (effetto "splice").
La matrice supporta l'intera gamma di risoluzioni video fino a WUXGA o 1080p e formati audio differenti fino a 7.1CH
LPCM a 192 kHz frequenza di campionamento.
Può essere gestita tramite i pulsanti del pannello anteriore, controllo IR, RS-232, Telnet, o GUI. Un'applicazione software
è altrettanto fornita.
FEATURES
• HDMI, HDCP1.1 and DVI compliant
• Deep color support 8/10/12 bit source
• Seamless switching
• Supports four different modes: Matrix mode/ Dual mode/ Quad /
TV Wall mode
■ Matrix mode: Can routes and output any 4 source to any 4 dis-
plays with seamless switching
Note: Under output timing 1080i@50/60 input 4 will be disabled,
OSD will show "IN 4 Disabled"
■ Dual mode: Can display POP (Picture Of Picture) & PiP (Picture
In Picture) image com-bined by 2 sources to be presented on
the HDMI output ports (Dual A and Dual B)
■ Quad mode: Can output all sources to a display (4 in 1) as a full
image.
■ TV Wall mode: Can output any source to 4 displays (2 by 2
Video wall) as a full image with adjustable Bezel Correction for 4
displays
• Supports OSD, RS232, Telnet, WebGUI, Remote control and on-pan-
el controls
• Input resolutions support VGA~WUXGA and 480i~1080p
• Output resolutions support 480p~1080p
• Supports different input resolution and output resolution selectable
from OSD menu. The factory default value for the output resolution
is 720p@60Hz/ 2CH LPCM
• Audio supports LPCM 2CH, 6CH, 8CH/AC3/DTS/Dolby Digital Plus/
Dolby TruHD & DTS-HD
