Using the water dispenser.

Child
safeguard
4

Features and Parts List

Loading the Dispenser and Start Up

Sanitize the dispenser water tanks prior to
installing a full bottle of water for the first time
(see "Sanitizing and Cleaning the Water Tanks").
IMPORTANT: Make sure the dispenser is
unplugged. Before placing the water bottle on the
dispenser, wash hands and wipe the top of the
bottle with a clean cloth. Avoid touching the part
of the bottle that will be in contact with the water
dispenser.
Make sure the water level in the top of the
dispenser is low enough to allow for proper
bottle installation. Failure to do so may cause
the dispenser to overflow.
1. Peel the label from the top cover of the
bottle (if present). Do not remove the
entire bottle cap.

Child Safeguard

The HOT dispenser button is equipped with
a child safeguard that reduces the risk of hot
water being dispensed accidentally or by small
children. To dispense water, rotate the knob
counterclockwise and push the button in. The
knob will reset automatically when the button
is released.
Bottle Support Collar—Black (WS28X10048)
Separator (WS28X10013)
Cold Water Tank
Control Panel
Hot , Room Temperature
Buttons
Dispenser Drip Tray (WS28X10031) and Grille (WS28X10032)
Compartment Drip Tray (WS29X10029)
Chiller Compartment. The compartment is intended solely for
use in chilling canned and boxed beverages and packaged
nonperishables.
Compartment Shelf (WS28X10028)
Drainage Cap (WS01X10008)
Silicon Stopper (WS01X10007)
2. Place the bottle on top of the dispenser
as shown, aligning the dispensing valve
probe to the center of the water bottle
cap. Press down until the probe
penetrates the bottle cap, allowing the
bottle to rest on the support collar.
3. IMPORTANT: Press both dispense buttons
until water runs from both taps.
4. Plug in the dispenser.
5. Set the clock, hot water temperature level
and energy saver cycle. See the Start Up and
Operation Adjustment section for detailed
instructions.
6. Press the
7. Allow 30 minutes for water to reach hot
and cold temperatures.
Contact a local water bottle distributor to
purchase water bottles.
The dispenser heats water up to a temperature
of 195°F (91°C). Water temperatures above 125°F
(52°C) can cause severe burns or death from
scalding. Children, the disabled and the elderly
are at highest risk of being scalded.
CAUTION:
supervised by a parent when using this product.
, Cold Water Dispenser
(power) button.
Children should be
