Case SR270 Tier 4B Service Manual

Hide thumbs Also See for SR270 Tier 4B:

Service manual (61 pages)

Service manual (61 pages)

Table Of Contents

Quick Links

SR270 / SV300

Tier 4B (final)

Alpha Series Skid Steer Loader

SR270 PIN NFM481941 and above; SV300 PIN NFM470295 and above

TR340 / TV380

Tier 4B (final)

Alpha Series Compact Track Loader

TR340 PIN NFM482972 and above; TV380 PIN NFM483044 and above

SERVICE MANUAL

Part number 47685161

edition English

June 2015

Table of Contents

Need help?

Do you have a question about the SR270 Tier 4B and is the answer not in the manual?

Questions and answers

Autumn Janae Massey

January 31, 2025

I cannot for the life of me find the part number for the button that controls the rear mirror in the ASCO SR270B.

1 comments:

Mr. Anderson

May 14, 2025

The provided context does not include specific information about a button that controls the rear mirror for the Case SR270 Tier 4B. There is no mention of a rear mirror control button or its part number in the supplied service and identification documentation.

To find the exact part number for that button, you would typically need to consult the parts catalog or operator's manual specific to the Case SR270 Tier 4B, or contact a CASE Construction dealership with the machine’s Product Identification Number (PIN).

Would you like me to help you locate that part number or a detailed parts diagram?

This answer is automatically generated

delbert j vandevander

July 8, 2025

Return line on my 340 case is blowing off. tried it with cap off tank. still comes off with 2 strong clamps. ??

Summary of Contents for Case SR270 Tier 4B

Page 1 SR270 / SV300 Tier 4B (final) Alpha Series Skid Steer Loader SR270 PIN NFM481941 and above; SV300 PIN NFM470295 and above TR340 / TV380 Tier 4B (final) Alpha Series Compact Track Loader TR340 PIN NFM482972 and above; TV380 PIN NFM483044 and above SERVICE MANUAL Part number 47685161 edition English...
Page 2 SERVICE MANUAL SR270 TIER 4B (FINAL) [NFM481941 - ] SV300 TIER 4B (FINAL) [NFM470295 - ] TR340 TIER 4B (FINAL) [NFM482972 - ] TV380 TIER 4B (FINAL) [NFM483044 - ] 47685161 24/06/2015...
Page 3 TR340 TIER 4B (FINAL) F5BFL413A*B007 [NFM482972 - ] TV380 TIER 4B (FINAL) North America F5BFL413A*B007 [NFM483044 - ] North America SR270 TIER 4B (FINAL) F5BFL413A*B007 [NFM481941 - ] SV300 TIER 4B (FINAL) North America F5BFL413A*B007 [NFM470295 - ] 47685161 24/06/2015...
Page 4 Contents INTRODUCTION Engine..................10 [10.001] Engine and crankcase ............. 10.1 [10.216] Fuel tanks .
Page 5 Thanks very much for your reading, Want to get more information, Please click here, Then get the complete manual NOTE: If there is no response to click on the link above, please download the PDF document first, and then click on it. Have any questions please write to me: admin@servicemanualperfect.com...
Page 6 [35.359] Main control valve ..............35.4 [35.525] Auxiliary hydraulic valves and lines .
Page 7 [55.019] Hydrostatic drive control system ........... 55.9 [55.512] Cab controls.
Page 8 47685161 24/06/2015...
Page 9 INTRODUCTION 47685161 24/06/2015...
Page 10: Table Of Contents
Contents INTRODUCTION Foreword - Important notice regarding equipment servicing (*) ....... . 3 Safety rules (*) .
Page 11: Foreword - Important Notice Regarding Equipment Servicing
In any case, no warranty is given or attributed on the product manufactured or marketed by the manufacturer in case of damages caused by parts and/or components not approved by the manufacturer.
Page 12: Safety Rules
INTRODUCTION Safety rules SR270 TIER 4B (FINAL) [NFM481941 - ] SV300 TR340 TIER 4B (FINAL) [NFM482972 - ] TV380 Personal safety This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible death or injury.
Page 13: Safety Rules - Personal Safety
INTRODUCTION Safety rules - Personal safety SR270 TIER 4B (FINAL) [NFM481941 - ] SV300 TR340 TIER 4B (FINAL) [NFM482972 - ] TV380 Carefully study these precautions, and those included in the external attachment operators manual, and insist that they be followed by those working with and for you.
Page 14: Safety Rules - Ecology And The Environment
Improper disposal of batteries can contaminate the soil, groundwater, and waterways. CASE CONSTRUCTION strongly recommends that you return all used batteries to a CASE CONSTRUCTION dealer, who will dispose of the used batteries or recycle the used batteries properly.
Page 15: Torque - Minimum Tightening Torques For Normal Assembly
INTRODUCTION Torque - Minimum tightening torques for normal assembly SR270 SV300 TR340 TV380 METRIC NON-FLANGED HARDWARE NOM. LOCKNUT LOCKNUT SIZE CL.8 CL.10 CLASS 8.8 BOLT and CLASS 10.9 BOLT and W/CL8.8 W/CL10.9 CLASS 8 NUT CLASS 10 NUT BOLT BOLT PLATED PLATED UNPLATED...
Page 16 INTRODUCTION METRIC FLANGED HARDWARE NOM. CLASS 8.8 BOLT and CLASS 10.9 BOLT and LOCKNUT LOCKNUT SIZE CLASS 8 NUT CLASS 10 NUT CL.8 CL.10 W/CL8.8 W/CL10.9 BOLT BOLT PLATED PLATED UNPLATED UNPLATED W/ZnCr W/ZnCr 2.4 N·m (21 lb 3.2 N·m (28 lb 3.5 N·m (31 lb 4.6 N·m (41 lb 2.2 N·m (19 lb...
Page 17 INTRODUCTION 1. Manufacturer's Identification 2. Property Class 3. Clock Marking of Property Class and Manufacturer's Identification (Optional), i.e. marks 60 ° apart indicate Class 10 properties, and marks 120 ° apart indicate Class 8. INCH NON-FLANGED HARDWARE LOCKNUT LOCKNUT NOMINAL SAE GRADE 5 BOLT SAE GRADE 8 BOLT GrB W/ Gr5...
Page 18 INTRODUCTION INCH FLANGED HARDWARE NOM- LOCKNUT LOCKNUT SAE GRADE 5 BOLT and SAE GRADE 8 BOLT and INAL GrF W/ Gr5 GrG W/ Gr8 SIZE BOLT BOLT UNPLATED PLATED UNPLATED PLATED or PLATED W/ZnCr or PLATED W/ZnCr SILVER GOLD SILVER GOLD 12 N·m (106 lb 13 N·m (115 lb...
Page 19 INTRODUCTION Inch Lock Nuts, All Metal (Three optional methods) 20090268 Grade Identification Grade Corner Marking Method (1) Flats Marking Method (2) Clock Marking Method (3) Grade A No Notches No Mark No Marks Grade B One Circumferential Notch Letter B Three Marks Grade C Two Circumferential Notches...
Page 20: Torque - Standard Torque Data For Hydraulics
INTRODUCTION Torque - Standard torque data for hydraulics SR270 TIER 4B (FINAL) [NFM481941 - ] SV300 TR340 TIER 4B (FINAL) [NFM482972 - ] TV380 INSTALLATION OF ADJUSTABLE FITTINGS IN STRAIGHT THREAD O RING BOSSES 1. Lubricate the O-ring by coating it with a light oil or petroleum.
Page 21 INTRODUCTION PIPE THREAD FITTING TORQUE PIPE THREAD FITTING Torque (Maximum) Thread Size Before installing and tightening pipe fittings, clean the 1/8-27 13 N·m (10 lb ft) threads with a clean solvent or Loctite cleaner and apply 1/4-18 16 N·m (12 lb ft) sealant L ®...
Page 22: Basic Instructions - Shop And Assembly
Only use CNH Original Parts or CASE CONSTRUCTION Original Parts. Only genuine spare parts guarantee the same quality, duration, and safety as original parts, as they are the same parts that are assembled during standard production. Only CNH Original Parts or CASE CONSTRUCTION Original Parts can offer this guarantee.

This manual is also suitable for:

Alpha series Sv300 tier 4b Tr340 tier 4b Tv380 tier 4b
