VIESMANN
Installation and service instructions
for contractors
Vitodens 222-F
Type B2TA, 3.2 to 35 kW
Gas condensing storage combi boiler
Gas Council No.
41-819-15; 41-819-16; 41-819-17
Natural gas and LPG versions
For applicability, see the last page
VITODENS 222-F
Please keep safe.
5773 216 GB
10/2015
