ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE!
PARTS LIST
PART
MATERIAL
NO.
CODE
1
RUS498B-CS11-1
2
RUS498B-CS01-1
3
17XA1010-----Y3
4
17C01A0828061YX
5
17C01A0822061YX
Use the correct bolts as indicated. Do not tighten any of the bolts until the swing is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and
!
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
!
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
!
Quote the following FQC No. when contacting the service center.
!
V-3
INTENDED FOR RESIDENTIAL USE ONLY.
PART
SWING ARM
SUSPENSION CHAIN
BOLT M8*90
BOLT M8*65
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
STOP
DO NOT RETURN TO THE STORE!
RUS498B
PART
MATERIAL
Q'TY
NO.
CODE
1
6
17FA08060601-YX
2
7
18000C06001
2
8
17KAA0201----Y4
4
9
17KAB1201----Y4
2
10
61R498BC00001BA
PAGE 1 OF 3
PART
WASHER d8.5*D17*1.6
PLASTIC NUT M8*P1.25
HEX. KEY WRENCH 6MM
NUT WRENCH 13&17MM
CUSHION
COURTYARD CREATIONS INC.
Q'TY
12
6
1
1
2
