Courtyard Creations RTS498J Assembly Instructions Manual

3 person padded sling swing
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
!
Do not discard of any of the packaging until you have checked that you have all of the
parts and fittings required.
!
Keep children away during assembly. This item contains small parts that can be
swallowed by children. Children should always be under direct adult supervision while
using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
3 Person Padded Sling Swing
RTS498J
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 1 OF 6
COURTYARD CREATIONS INC.

Advertisement

loading
Need help?

Need help?

Do you have a question about the RTS498J and is the answer not in the manual?

Questions and answers

Related Manuals for Courtyard Creations RTS498J

Summary of Contents for Courtyard Creations RTS498J

  • Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 COURTYARD CREATIONS INC. PAGE 1 OF 6...

  • Page 2: Phillips Screwdriver

    C. Lay out all of the parts and match them with the table below. PARTS LIST PART MATERIAL PART MATERIAL PART Q’TY PART Q’TY CODE CODE RTS498J-CS01 17C01A0721091Y4 BOLT M6*60 62RUS417SH101 17C01A0714003Y4 BOLT M6*40 REAR CROSS BRACE 62RUS497AI101 17C01A0821061Y4 LATERAL CROSS BRACE BOLT M8*60 62RUS497AN101...
  • Page 3 Note: When fastening with bolts and nuts, always use a washer (#18 and #19) between the tube and the bolt and the tube and the nut. Step 2 Step 1: Step 1 Fasten the front and rear upright supports (#4 and #5) at the top by using bolts (#13), washers (#18), and plastic nuts (#20).
  • Page 4 Step 6: Open the seat assembly (#7) and fasten a swing arm tube (#8) and a swing arm (#6) to the seat back by using bolt (#14) and washer (#19). Do the same procedure for both sides. Fasten another swing arm tube (#8) to the swing arm (#6) at the front bend by using bolt (#14), washers (#19), and plastic nut (#21).
  • Page 5 Step 9: Slide the canopy/frame connectors (#22) onto the U-shaped side canopy braces (#10) and fasten into position by using screws (#17). Make sure that the teeth of the canopy connectors are facing towards the inside of the swing. See Fig. E – Step 1 and Step 2. Step 1 Step 2 Step 10:...
  • Page 6 Step 14: Re-check and re-tighten all of the nuts and bolts to assure stability. Note: To avoid danger of suffocation, always keep plastic bags or small parts away from babies and children. Fig. G Cleaning and Maintenance • Wash frame and fabric parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach, acid, or other solvents on the frame or fabric.
