  • Page 1 1 2 3 4 Video door phone - V600 RTS Installation instructions...

  • Page 2: Table Of Contents

    This guide describes the installation and use of this product. Any installation or use outside the sphere of application specified by Somfy is forbidden. This invalidates the warranty and discharges Somfy of all liability, as does any failure to comply with the instructions given herein.

  • Page 3: Conditions For Use

    The purchaser may incur civil and criminal liability in the event of misuse of the device by compromising the right to privacy or the image of a third-party. Under no circumstances may Somfy be held liable for any use of the video entry phone which contravenes the legal and regulatory provisions in force.

  • Page 4: Product Description

    This allows the indoor monitor to be used to control a small or large gate. The fingerprint scanner can control both a large or small gate. The indoor monitor is also fitted with an RTS (Radio Technology Somfy) radio transmitter. This wireless control is used to operate a garage door, lighting, roller shutters or even a Somfy gate.

  • Page 5: Dimensions (Mm)

    Used to connect the monitor station to a gate motorisation or an electric door-opener/lock. Speaker volume adjustment button This is used to adjust the volume of the door station speaker. dimensions (mm) 1 2 3 4 (thickness with (thickness with metal bracket) rain shield) Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 6: Standard Installation

    Cable to be used and its power plug 230V Less than 70 m 2-wire 0.5 mm² min. Between 70 and 100 mm 2-wire 0.75 mm² min. Sealed unit* 1 2 3 4 2-wire Not supplied Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 7: Installing The Monitor

    [4]. Clip the monitor onto its mounting bracket by first positioning the top of the monitor on the station, then the bottom. Note: Position the power plug wires between the mounting bracket and the monitor. monitor To a second monitor (optional) To the door station power plug wires Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 8: Installing The Door Station And Adjusting The Camera's Viewing Angle

    [6]. Install the door station in the rain shield. [7]. Screw the door station to the rain shield using the torx key. OFF: Electric door- power opener/lock cable supply cable monitor gate motorisation cable cable Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 9: Connecting The Door Station

    Important: The monitor power plug must be installed close to the monitor and must be easily accessible. The door station power plug can be installed inside the house or outside in a sealed unit (see page 5). Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 10: Setting The Fingerprint Scanner Parameters

    Place your finger back on the scanner again to store its print. - If the door station emits one beep, then 4 beeps, the fingerprint is already stored. Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 11: Exiting Programming Mode

    - the default administrator code (1234) is restored. Exiting programming mode yellow To exit programming mode, press # on the adjustment remote control. The indicator turns red. Note: Programming mode is exited automatically after 30 seconds of inactivity. Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 12: Video Entry Phone Settings

    CoNTRollINg Somfy RTS wIRElESS EquIpmENT programming the monitor on a Somfy RTS unit The monitor is equipped with a Somfy Radio Technology (RTS) transmitter. It is only compatible with devices equipped with Somfy Radio Technology (RTS). It is used to control the following Somfy equipment, individually or simultaneously: •...
  • Page 13 1 2 3 4 PROG DEXXO COMPACT RTS DEXXO COMPACT RTS Note: To clear the programming on the video entry phone on a Somfy garage door motorisation, repeat all the steps detailed above. Copyright © 2013 Somfy SAS. All rights reserved.
  • Page 14 2 mn RTS outdoor lighting receiver RTS indoor lighting receiver 1 2 3 4 Note: To clear the video entry phone programming on a Somfy lighting receiver, repeat all the steps detailed above. Copyright © 2013 Somfy SAS. All rights reserved.
  • Page 15 [1]. Identify the original control of the roller shutter, i.e. the remote control or the control point which only controls this roller shutter. Note: - If the original control is lost or broken, and it is the only one to control the roller shutter, contact one of our Somfy advisors.
  • Page 16 PROG < 0,5s 1 2 3 4 CONTROL BOX 3S RTS Note: To clear the video entry phone programming on a Somfy gate motorisation, see the motorisation guide. ELIXO 500 3S RTS < 0,5s 1 2 3 4 Copyright © 2013 Somfy SAS. All rights reserved.

  • Page 17: Stored Fingerprints Memory

    3 V type CR2430 Range 200 m (in open space) door station Power supply 14.5 V DC Camera 1/3 CCD 72° Night vision 0.05 LUX visible LEDs Operating temperature -20°C to +55°C Copyright © 2013 Somfy SAS. All rights reserved.
