- Page 1 OWNER’S MANUAL ENGLISH 繁體中文 AIR CONDITIONER (SPLIT TYPE) For general public use Indoor unit RAS-10, 13J2KV-HK Outdoor unit RAS-10, 13J2AV-HK 1118350275 1118350275-00_S01_182x257_12p_S_p70_190327.indd 1 24/6/2562 11:23:07...
-
Page 2: Precautions For Safety
PRECAUTIONS FOR SAFETY ● Keep this manual where the operator can easily find it. ● Read the precautions in this manual carefully before operating the unit. ● This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons. ● The precautions described herein are classified as DANGER, WARNING and CAUTION. They both contain important information regarding safety. Be sure to observe all precautions without fail. DANGER ● Do not install, repair, open or remove the cover. It may expose you to dangerous voltages. Ask the dealer or the specialist to do this. ● Turning off the power supply will not prevent potential electric shock. ● The appliance shall be installed in accordance with national wiring regulation. ● Means for disconnection from the supply having a contact separation of at least 3 mm in all poles must be incorporated in the fixed wiring. ● The appliance must be stored in a room without continuously operating ignition sources (for example, open flames, an operating gas appliance or an operating electric heater). ● In order to avoid fire, explosion or injury, do not operate the unit when harmful gases (e.g. flammable or corrosive) are detected near the unit. WARNING ● Do not expose your body directly to cool or warm air for a long time. ● Do not insert your finger or any article into the air inlet/outlet. ● When an abnormality (burning smell, etc.) occurs, stop the air conditioner and disconnect the power supply or turn off the breaker. ● This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction... - Page 3 PRECAUTIONS FOR SAFETY ● The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). ● Be aware that refrigerants may not contain an odour. ● Do not pierce or burn as the appliance is pressurized. Do not expose the appliance to heat, flames, sparks, or other sources or ignition. Else, it may explode and cause injury or death. CAUTION ● Do not wash the unit with water. It may cause an electric shock. ● Do not use this air conditioner for other purposes such as preserving food, breeding animal, etc. ● Do not step or put anything on the indoor/outdoor unit. It may cause an injury or damage the unit. ● Do not touch aluminium fin because it may cause an injury. ● Before cleaning the unit, turn off the main switch or the circuit breaker. ● When the unit won’t be used for a long time, turn off the main switch or the circuit breaker. ● It is recommended that maintenance be performed by a specialist when the unit has been operated for a long time. ● The manufacturer shall not assume any liability for the damage caused by not observing the description of this manual. 1118350275-00_S01_182x257_12p_S_p70_190327.indd 3 24/6/2562 11:23:07...
-
Page 4: Automatic Operation
INDOOR UNIT DISPLAY ONE-TOUCH Press the “ONE-TOUCH” button for fully automated operation that is 1 ECO (White) customized to the typical consumer preferenced in your region of the world. 2 Wi-Fi access (White) The customized settings control temperature air flow strength, air flow 3 Hi-Power (White) direction and other settings to provide you alternate contact with 4 Timer (White) “ONE-TOUCH” of the button. If you prefer other settings you can select from 5 Operation (White) the many other operating functions of your Toshiba unit. ● Display brightness can be adjusted, follow procedure on #. Press : Start the operation. Require Wireless LAN connecting adapter which available as accessory. AUTOMATIC OPERATION PREPARATION BEFORE USE Preparing Filters To automatically select cooling, heating or fan only operation 1. Open the air inlet grille and remove the air filters. 1. Press : Select Auto A. 2. Attach the filters. (see detail in the accessory sheet). Loading Batteries (when use wireless operation.) 2. Press : Set the desired temperature Min 17°C, Max 30°C. -
Page 5: Maintenance
Setting Daily Timer MAINTENANCE Press Press : Set the ON timer. Firstly, turn off the circuit breaker. Indoor Unit and Remote Control • Clean the indoor unit and the remote control with a wet cloth when Press button during needed. Press : Set the OFF timer. the ( or ) mark flashing. • No benzine, thinner, polishing powder or chemically-treated duster. • During the daily timer is activating, both arrows ( , ) are indicated. Air filters Note: Clean every 2 weeks. • Keep the remote control in accessible transmission to the indoor unit; 1. Open the air inlet grille. 2. Remove the air filters. otherwise, the time lag of up to 15 minutes will occur. 3. Vacuum or wash and then dry them. • The setting will be saved for the next same operation. 4. Reinstall the air filters and close the air inlet grille. - Page 6 安全預防措施 ● 將本手冊放置在操作人員容易找到的地方 。 ● 在操作本設備之前 ， 請仔細閱讀本手冊中的注意事項 。 ● 本設備供專業或經過培訓的用戶在商店 、 輕工業和農場作業內使用 ， 或供非專業人士的商業使用 。 ● 本文所述的預防措施分為危險 、 警告和小心 。 它們均包含有關安全的重要信息 。 務必遵守所有注意事項的要求 。 危險 ● 不要安裝 、 修理 、 打開或拆下蓋子 。 這樣做可能會讓你暴露在危險的電壓下 。 請經銷商或專業人士來執行此操作 。 ● 關閉電源並不能防止潛在的觸電危險 。 ● 電器安裝應按照國家布線規範的規定執行 。 ●...
- Page 7 安全預防措施 ● 該設備必須存放於無持續操作火源 （例如明火 、 操作中的燃氣設備或操作中的電加 熱器） 的房間中 。 ● 註意制冷劑可能無氣味 。 ● 當設備被施壓時 ， 不要刺穿或燃燒 。 不要將設備暴露在高溫 、 火焰 、 火花或其他火源 或點燃的環境中 。 否則可能發生爆炸並導致傷亡 。 注意 ● 請勿用水清洗設備 。 可能會導致觸電 。 ● 請勿將本空調用於其他用途 ， 如保存食物 、 飼養動物等 。 ●...
- Page 8 室內機顯示器 單觸 1 ECO 節能 （白色） 按下 ONE-TOUCH (單觸)按鈕進行完全自動化的操作,它是根據所在地區 用戶的 2 Wi-Fi 連接 （白色） 典型參數選擇定制的 。 定制設置控制溫度氣流強度 、 氣流方向和其他設 置以便使 3 高功率 （白色） 您可以選擇使用 ONE-TOUCH 按鈕 。 如果您更喜歡其他設置,可以從東芝設備 的 4 定時器 （白色） 許多其他操作功能中進行選擇 。 5 操作 （白色） 按 : 啟動操作 。 顯示器亮度可以調整 ， 請按照第 # 的步驟来 操作 。 ● 需要隨配件而提供的無線局域網連接適配器 。 自動操作 使用前的準備 自動選擇制冷 、 加熱或僅開啟風扇操作 準備過濾器 1. 按下...
- Page 9 設置每日計時器 維修 按下 鍵 ： 設置ON （開啓） 按下 首先 ， 關閉斷路器 。 計時器 室內機和遙控器 在 （ 或 ） 標記閃爍時按下 • 必要時用濕布清潔室內機和遙控器 。 按下 鍵 ： 設置OFF （ 關閉） • 不可使用汽油 、 稀釋劑 、 拋光粉或化學處理的噴粉機 。 鍵 。 計時器 。 空氣過濾器 • 在激活每日計時器期間...
- Page 10 1118350275-00_S01_182x257_12p_S_p70_190327.indd 10 24/6/2562 11:23:18...
- Page 11 1118350275-00_S01_182x257_12p_S_p70_190327.indd 11 24/6/2562 11:23:18...
- Page 12 1118350275 1118350275-00_S01_182x257_12p_S_p70_190327.indd 12 24/6/2562 11:23:19...
