INSTALLATION MANUAL
AIR CONDITIONER (SPLIT TYPE)
Indoor Unit
RAS-10, 13, 18J2FVG-TR
Outdoor Unit
RAS-10, 13, 18J2AVSG-TR
R32
ENGLISH
TÜRKÇE
1112151109

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAS-10J2FVG-TR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Toshiba RAS-10J2FVG-TR

  • Page 1 INSTALLATION MANUAL ENGLISH AIR CONDITIONER (SPLIT TYPE) TÜRKÇE Indoor Unit RAS-10, 13, 18J2FVG-TR Outdoor Unit RAS-10, 13, 18J2AVSG-TR 1112151109...
  • Page 2: Table Of Contents

    CONTENTS İÇİNDEKİLER PRECAUTIONS FOR SAFETY..........1 GÜVENLİK ÖNLEMLERİ............1 ACCESSORY PARTS..............5 AKSESUAR PARÇALARI............5 INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR İÇ VE DIŞ ÜNITENIN MONTAJ ŞEMASI........6 UNITS..................6 İsteğe Bağlı Montaj Parçaları..........6  İÇ ÜNİTE..................7 Optional Installation Parts.............6  INDOOR UNIT................7 Montaj Yeri................7  Installation Place..............7 Bir Delik Açılması...
  • Page 3: Precautions For Safety

    PRECAUTIONS FOR SAFETY PRECAUTIONS FOR SAFETY Read the precautions in this manual carefully before This appliance is filled with R32. operating the unit. • Before installation, please read these precautions for safety carefully. • Be sure to follow the precautions provided here to avoid safety risks. The symbols and their meanings are shown below.
  • Page 4 DANGER • FOR USE BY QUALIFIED PERSONS ONLY. • TURN OFF MAIN POWER SUPPLY BEFORE ATTEMPTING ANY ELECTRICAL WORK. MAKE SURE ALL POWER SWITCHES ARE OFF. FAILURE TO DO SO MAY CAUSE ELECTRIC SHOCK. • CONNECT THE CONNECTING CABLE CORRECTLY. IF THE CONNECTING CABLE IS CONNECTED WRONGLY, ELECTRIC PARTS MAY BE DAMAGED.
  • Page 5 WARNING • Never modify this unit by removing any of the safety guards or bypassing any of the safety interlock switches. • Do not install in a place which cannot bear the weight of the unit. Personal injury and property damage can result if the unit falls. •...
  • Page 6 CAUTION • Exposure of unit to water or other moisture before installation could result in electric shock. Do not store it in a wet basement or expose to rain or water. • After unpacking the unit, examine it carefully for possible damage. •...
  • Page 7: Accessory Parts

    ACCESSORY PARTS ACCESSORY PARTS ACCESSORY AND INSTALLATION PARTS Parts name (Q’ty) Parts name (Q’ty) Installation plate* x 1 Wireless remote control* x 1 Battery x 2 Remote control holder* x 1 Filter** Filter** Mounting screw** Ø4 x 25 Flat head wood screw Ø3.1 x 16 Insulation sheet x 1 (for some models only) Drain nipple*** x 1 (for heating model only) Cap water proof*** x 2 (for some models only)
  • Page 8: Installation Diagram Of Indoor And Outdoor Units

    INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS Do not allow the drain hose to get slack. Air filter Installation plate Cut the piping hole sloped slightly. 50 mm or more 50 mm or more Make sure to run the drain hose sloped downward.
  • Page 9: Indoor Unit

    INDOOR UNIT INDOOR UNIT Mounting the installation plate and screw position Installation Place (Unit : mm) A place which provides the spaces around the indoor unit as shown in the ● diagram. A place where there are no obstacles near the air inlet and outlet. ●...
  • Page 10: How To Install Indoor Unit

    2. Put water in the drain pan and make sure that the water is drained out of How to Install Indoor Unit doors. 3. When connecting extension drain hose, insulate the connecting part of extension drain hose with shield pipe. 1.
  • Page 11: Concealed Installation

    Mounting directly on the floor. Concealed Installation 1) Fix the leg of indoor unit on the floor with 2 mounting screws. 2) Fix the upper part of indoor unit on the wall with 4 mounting screws. The special method to install the indoor unit bury in the wall is shown here. Please make sure to change to wall burying mode.
  • Page 12: How To Open The Air Inlet Grille

    with Snowfall and Cold Temperatures 4. In case of lattice establishment How to open the air inlet grille Follow the following figure, make sure to keep enough distance ● between lattice, frame and wall. Be sure to switch to wall burying mode. ●...
  • Page 13: Outdoor Unit

    OUTDOOR UNIT OUTDOOR UNIT When using a multi-system outdoor unit refer to the installation manual ● Precautions about Installation in Regions provided with the model concerned. with Snowfall and Cold Temperatures Installation Place Do not use the supplied drain nipple for draining water. Drain the water from ●...
  • Page 14: Draining The Water

    Draining the Water Refrigerant Piping Connection • Holes are provided on the base plate of the outdoor unit to ensure that the Flaring defrost water produced during heating operations is drained off efficiently. If a centralized drain is required when installing the unit on a balcony or 1.
  • Page 15: Evacuating

    2. Connect the charge hose to the port of the vacuum pump. Model RAS-10J2FVG-TR RAS-13J2FVG-TR RAS-18J2FVG-TR 3. Open fully the low pressure side handle of the gauge manifold valve. 4. Operate the vacuum pump to start evacuating. Perform evacuating for Power source 220–240V ~ 50Hz 220–240V ~ 50Hz 220–240V ~ 50Hz...
  • Page 16: Others

    OTHERS OTHERS Unit B setup. Gas Leak Test Press and hold MODE button for more than 20 seconds. When A setup changed to B setup : 5 beeps will sound and operation lamp blinks for 5 seconds. When B setup changed to A setup : 5 beep will sound. Test Operation To switch the TEST RUN (COOL) mode, press OPERATION button for 10 seconds (The beeper will make a short beep).
  • Page 17: Güvenli̇k Önlemleri̇

    GÜVENLİK ÖNLEMLERİ GÜVENLİK ÖNLEMLERİ Üniteyi çalıştırmadan önce bu kılavuzdaki önlemleri dikkatlice Bu aygıt R32 ile doldurulmuştur. okuyun. • Lütfen, montaj işleminden önce güvenliğiniz için bu önlemleri dikkatli bir şekilde okuyun. • Güvenlik risklerinden sakınmak için burada verilen önlemleri uyguladığmızdan emin olun. Semboller ve anlamları aşağıda gösterilmektedir. UYARI : Bu ünitenin yanlış...
  • Page 18 TEHLİKE • SADECE KALİFİYE PERSONEL TARAFINDAN KULLANILMALIDIR. • HERHANGİ BİR ELEKTRİK İŞİNE BAŞLAMADAN ÖNCE CİHAZI ŞALTERDEN KAPATIN. BÜTÜN ELEKTRİK ŞALTERLERİNİN KAPALI OLMASINA DİKKAT EDİN. EĞER BU SAYILANLARI YAPMAYI İHMAL EDERSENİZ ELEKTRİK ÇARPMASI MEYDANA GELEBİLİR. • BAĞLANTI KABLOLARINI DÜZGÜN BİR ŞEKİLDE TAKIN. EĞER BAĞLANTI KABLOLARI YANLIŞ...
  • Page 19 UYARI • Bu üniteyi, güvenlik önlemlerinden herhangi birini kaldırarak veya emniyet kilit şalterlerinden herhangi birini baypas yaptırarak asla değiştirmeyin. • Üniteyi ağırlığını kaldıramayacağı bir yere monte etmeyin. Eğer ünite düşerse, yoldan geçen insanların yaralanmasιna ve malların hasar görmesine neden olabilir. •...
  • Page 20 DİKKAT • Cihaz monte edilmeden önce suya veya herhangi bir nemli ortama maruz kalιrsa, elektrik çarpması meydana gelebilir. Cihazı nemli bir ortamda muhafaza etmeyin veya yağmur veya su altında bırakmayın. • Cihazı paketinden çıkardıktan sonra olası bir hasara karşı dikkatlice inceleyin. •...
  • Page 21: Aksesuar Parçalari

    AKSESUAR PARÇALARI AKSESUAR PARÇALARI AKSESUAR VE MONTAJ PARÇALARI Parça adı (Miktar) Parça adı (Miktar) Montaj plakası* x 1 Uzaktan kumanda* x 1 Piller x 2 Uzaktan kumanda muhafazası* x 1 Filtresini** Filtresini** Montaj vidası** Ø4 x 25 Düz basil ahşap vidası Ø3,1 x 16 Yalıtım borusu x 1 (yalnızca bazı...
  • Page 22: İç Ve Diş Ünitenin Montaj Şemasi

    İÇ VE DIŞ ÜNITENIN MONTAJ ŞEMASI İÇ VE DIŞ ÜNITENIN MONTAJ ŞEMASI Boşaltma hortumunu gevşek bırakmayın. Hava Filtresini Montaj plakası Hortum deliğini hafifçe eğimli kesin. 50 mm veya daha fazla 50 mm veya daha fazla Boşaltma hortumunun aşağı doğru Filtresini eğik vaziyette olmasına dikkat edin.
  • Page 23: İç Üni̇te

    İÇ ÜNİTE İÇ ÜNİTE Montaj plakasının yerleştirilmesi Montaj Yeri (Birim : mm) Şemada gösterildiği gibi iç ünitenin etrafιnda alan bιrakιlabilecek bir yer. ● Hava giriş ve çιkιşlarιnι engellemeyecek bir yer. ● Dιş ünitede yapιlacak boru montajιnι kolaylaştιran bir yer. ● Ön panelin açιlmasιnι...
  • Page 24: Dış Ünitenin Monte Edilmesi

    2. Drenaj kabının içine su koyun ve suyun dışarı atıldığından emin olun. Dış ünitenin monte edilmesi 3. Ek boşaltma hortumunu bağlarken hortumun bağlantı kısmını koruyucu bir boruyla yalıtın. 1. Hava giriş ızgarasını sökün. Hava giriş ızgarasını açın ve şeridi sökün. 2.
  • Page 25: Gizli Yalıtım

    Doğrudan zemine monte etme. Gizli yalıtım 1) İç ünitenin bacağını zemine 2 montaj cıvatasıyla sabitleyin. 2) İç ünitenin üst kısmını duvara 4 montaj cıvatasıyla sabitleyin. Burada, iç üniteyi duvara gömülü olarak monte etmek için özel yöntem gösterilmektedir. (Zemine montaj) Lütfen duvara gömülü moda geçtiğinizden emin olun. 1.
  • Page 26: Hava Giriş Izgarası Böyle Açılır

    4. Kafese montaj durumunda Hava giriş ızgarası böyle açılır Aşağıdaki resime bakarak, kafes, iskelet ve duvar arasında yeterli Aşağıdaki resime bakarak, kafes, iskelet ve duvar arasında yeterli ● Karlι mesafe bırakmaya dikkat edin. Duvara gömülü moda geçtiğinizden emin olun. ● Kafes ahşap olmalıdır.
  • Page 27: Montaj Yeri

    50 veya daha fazla 50 veya daha fazla DlŞ ÜNİTE DlŞ ÜNİTE Çoklu sistem dış mekan ünitesi kullanırken, ilgili model ile birlikte verilen ● Karlι ve Soğuk Bölgelerde Montaj kurulum kılavuzuna bakınız. İle İlgili Önlemler Montaj Yeri Boşaltma suyu için birlikte verilen boşaltma nipelini kullanmayιn. Suyu ●...
  • Page 28: Su Tahliyesi

    Su Tahliyesi Soğutma Maddesi Boru Bağlantısı • Isıtma işlemleri sırasında ortaya çıkan çözülmüş (defrost) suyun etkili Kıvırma bir şekilde tahliye edilmesini sağlamak için dış mekan ünitesinin taban plakasında delikler yapılmıştır. 1. Bir boru kesici yardιmιyla boruyu kesin. Üniteyi balkona veya duvara kurarken merkezi tahliyenin gerekli olması 2.
  • Page 29: Boşaltma

    Alt kol (Tamamen kapalι tutun) 2. Güç kaynağını özel olarak klima için kullanılması için hazırlayın. Şarj hortumu Şarj hortumu Modeller RAS-10J2FVG-TR RAS-13J2FVG-TR RAS-18J2FVG-TR Bağlantι borusu Elektrik 220–240V ~ 50Hz 220–240V ~ 50Hz 220–240V ~ 50Hz Geri akmayι önleyen vakumlu pompa adaptörü...
  • Page 30: Di̇ğerleri̇

    DİĞERLERİ DİĞERLERİ B Ünitesi Ayarı. Gaz Kaçağı Testi En az 20 saniye boyunca MODE tuşuna basılı tutun. A ayarı B ayarına değiştiğinde: 5 kez uyarı sesi çalar ve 5 saniye boyunca kullanım lambası yanıp söner. B ayarı A ayarına değiştiğinde: 5 kez uyarı sesi çalar Test İşlemi TEST RUN (COOL) modunu açmak için 10 saniye boyunca OPERATION düğmesini basιlι...
  • Page 32 1112151109...
