Assembly Instructions
Formentera Occ Chair
SKU–566545
THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS
PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT
THE NEAREST COST PLUS WORLD MARKET STORE.
IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOM ER SERVICE CALL
CENTER TOLL FREE AT 877- 967-5362 FOR ASSISTANCE.
Page 1
Advertisement
Table of Contents
Related Manuals for World Market Formentera Occ 566545
Summary of Contents for World Market Formentera Occ 566545
- Page 1 THANK YOU FOR YOUR PURCHASE. IF YOU HAVE ANY QUESTIONS PERTAINING TO THE ASSEMBLY OF THIS FURNITURE PIECE, PLEASE CONTACT THE NEAREST COST PLUS WORLD MARKET STORE. IF YOU ARE NOT NEAR A STORE, PLEASE CALL OUR CUSTOM ER SERVICE CALL CENTER TOLL FREE AT 877- 967-5362 FOR ASSISTANCE.
- Page 2 Component List LABEL PICTURE DESCRIPTION BACK REST SEAT LEFT FRAME RIGHT FRAME BACK CUSHION SEAT CUSHION Q’TY Q’TY LABEL PICTURE DESCRIPTION LABEL PICTURE DESCRIPTION LONG ALLEN BOLT WOOD PLUG 8x50 Ø14/Ø17x8mm SHORT ALLEN BOLT ALLEN KEY 8x40 Page 2...
- Page 3 Assembly Preparation Before Beginning: • Unpack all hardware bags and components to ensure y ou have all parts- • Read instructions, cover to cover- • Have 2 adults on hand for assembly- • Do not assemble on flooring or carpet- •...
- Page 4 Assembly Steps Step 1 (H-1) ALLEN BOLT 8x50 x4 (H-2) ALLEN BOLT 8x40 x2 (H-4) ALLEN KEY x1 - Attach the Back Rest (A) to Seat (B) with Long Allen Bolts (H-1) by using Allen Key (H-4). - Attach the Left Frame (C) to Back Rest (A), with Short Allen Bolts (H-2) using Allen Key (H-4). - Attach the Seat (B) to Left Frame (C) , with Long Allen Bolts (H-1) using Allen Key (H-4).
- Page 5 Assembly Steps Step 3 (H-3) WOOD PLUG Ø14/Ø17x8mm - Insert Wood Plug (H-3) into bolt holes and tap gently with hammer until flush to cover all holes as shown. Step 4 Step 5 - Place Back Cushion (E) and Seat Cushion (F) on as shown. The Chair is ready to use.
- Page 6 Care & Maintenance • Do not put hot items directly on furniture surface. Do not clean furniture with harsh cleansers or polish. • Do not place furniture near heating or cooling vents. • Do not write on furniture without a padded barrier to protect the surface. •...
