Summary of Contents for Kenwood KUF55X17
- Page 1 55cm Undercounter Freezer KUF55X17 installation / instructions manual...
-
Page 2: Table Of Contents
Contents safety warnings ........................3 unpacking ..........................5 installation ........................... 6 location ..........................6 levelling the unit ....................... 6 free space requirements ....................6 installing the door handle ....................7 reversing the door swing ....................7 cleaning before use ......................9 before using your unit ...................... -
Page 3: Safety Warnings
safety warnings For your continued safety and to reduce the risk of injury or electric shock, please follow all the safety precautions listed below. • Read all instructions carefully before using the unit and keep them for future reference. • Retain the manual. If you pass the unit onto a third party, make sure to include this manual. - Page 4 • Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance. • Do not store bottles or glass containers in the freezer compartment. Contents can expand when frozen (fizzy drinks) which may break the bottle and damage your freezer compartment.
-
Page 5: Unpacking
Thank you for purchasing your new Kenwood Freezer. These operating instructions will help you use it properly and safely. We recommend that you spend some time reading this installation/instruction manual in order that you fully understand all the operational features it offers. -
Page 6: Installation
installation installation location When selecting a position for your unit you should make sure the floor is flat and firm, and the room is well ventilated with an average room temperature of between 16°C and 43°C. Avoid locating your unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the electrical consumption. -
Page 7: Installing The Door Handle
installation installing the door handle 1. Remove the screws from the door. 2. Take the door handle and remove the 2 handle screw hole covers from the door handle. Align the door handle with the screw holes on the door and screw tightly. - Page 8 installation 1. Remove the two screws from the back of the top cover, then lift the top cover and place it on a padded surface to prevent from scratching. 2. Remove the four screws (2 from each side). Remove the upper hinge. Lift the door and place it on a padded surface to prevent from scratching.
-
Page 9: Cleaning Before Use
installation 5. Put back the top cover. Tighten the 2 screws at the back of the top cover. 6. Transfer the door handle to the other side of the door accordingly. Remove the 2 door screw hole covers from the other side of the door and swap their position with the door handle. -
Page 10: Product Overview
product overview main unit Thermostat Control Dial Freezer Drawer Ice Tray... -
Page 11: Operation
operation switching on your unit 1. Connect the mains cable to the mains socket. The internal temperature of your unit is controlled by a thermostat. There are three settings: Mid, Cold and Colder. 2. After the unit has been on for 20 minutes adjust the thermostat control dial to Mid. -
Page 12: Defrosting Frozen Food
• Exclude as much air from the container as possible. You could buy a special vacuum pump which sucks excessive air out of the packaging. • Leave a small amount of air space when freezing liquids to allow expansion. • You can use the space in the freezer most efficiently if you freeze liquids (or solids with liquids, e.g. -
Page 13: Cleaning
cleaning defrosting Frost might build up in the unit after it has been used for a period of time. Scrape away the frost using a plastic scraper (not included). Do not use a metal or sharp instrument to scrape away the frost, nor should you use any electrical appliances to aid defrosting. -
Page 14: Maintenance
maintenance care when handling / moving your unit Hold the unit around its sides or base when moving it. Under no circumstances should it be lifted by holding the edges of the top surface. servicing The unit should be serviced by an authorised engineer and only genuine spare parts should be used. -
Page 15: Specifications
Model KUF55X17 Appliance Category Category 8 (Upright freezer) Overall Dimension (H x W x D) 845 x 560 x 575 mm Fresh Food Storage Volume Frozen Food Storage Volume 81 L Defrosting Type Static Climate Class N, ST, T This appliance is intended to be used at an ambient temperature between 16°C and 43°C. - Page 16 DSG Retail Ltd. (co. no. 504877) 1 Portal Way, London, W3 6RS, UK Manufactured for DSG Retail Limited under Licence from Fisher & Paykel Appliances Italy SpA. DSG Retail Limited is responsible for after sales service. IB-KUF55X17-170118V1...
