Remove the Existing SMB-1 Firmware PROM

To remove the existing SMB-1 Firmware PROM, follow the steps detailed in the instruction sheet packaged with the
extraction tool.

Insert the Replacement SMB-1 Firmware PROM

1. Align the diagonal corner of the replacement SMB-1 Firmware PROM with the diagonal corner of the socket.
2. Gently and evenly push the SMB-1 Firmware PROM into the socket.
3. Reinsert the module in the slot in the SmartSwitch 9000 chassis from which it was taken.

Getting Help

For additional support related to this device or document, contact the Cabletron Systems Global Call Center:
Before calling the Cabletron Systems Global Call Center, have the following information ready:
• Your Cabletron Systems service contract number
• A description of the failure
• A description of any action(s) already taken to resolve the problem
(e.g., changing mode switches, rebooting the unit, etc.)
• The serial and revision numbers of all involved Cabletron Systems products in the network
• A description of your network environment (layout, cable type, etc.)
• Network load and frame size at the time of trouble (if known)
• The device history (i.e., have you returned the device before, is this a recurring problem, etc.)
• Any previous Return Material Authorization (RMA) numbers
