This upgrade kit contains the power bridge adapter that, when properly installed, allows the 6C110 chassis to
support the 6C210-1 and 6C210-2 power supplies.
Only qualified personnel should perform the following installation procedures.
Required Tools
The following tools are required to install the 6C110 power bridge adapter:
•
ESD wrist strap
•
Phillips head screwdriver
•
Flat head screwdriver
•
Hex nut driver (.25-inch)
Equipment Checklist
Ensure the upgrade kit contains the following items before proceeding with the installation. If any components are
missing, contact Cabletron Systems. Information on contacting Cabletron Systems is available at the end of this
document.
•
Power Bridge Adapter (1)
•
Standoffs (3)
•
Support Clip (1)
•
Blank Faceplate (1)
Related Manuals
Use the 6C110 Overview and Setup Guide to supplement the procedures and other technical data provided in this
manual:
This manual can be obtained on the World Wide Web in Adobe Acrobat Portable Document Format (PDF) at the
following site:
http://www.cabletron.com/
9033011
6C110 POWER BRIDGE ADAPTER
INSTALLATION INSTRUCTIONS
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for Cabletron Systems SmartSwitch 6C110
Summary of Contents for Cabletron Systems SmartSwitch 6C110
-
Page 1: Required Tools
6C110 POWER BRIDGE ADAPTER INSTALLATION INSTRUCTIONS This upgrade kit contains the power bridge adapter that, when properly installed, allows the 6C110 chassis to support the 6C210-1 and 6C210-2 power supplies. Only qualified personnel should perform the following installation procedures. Required Tools The following tools are required to install the 6C110 power bridge adapter: •... -
Page 2: Installing The Power Bridge Adapter
Installing the Power Bridge Adapter These instructions apply to users that will equip the 6C110 chassis with 6C210-1 or 6C210-2 power supplies. If legacy 6C205-2 or 6C205-3 power supplies will be used, DO CAUTION NOT install the power bridge adapter. All Cabletron Systems interface modules are sensitive to static discharges. - Page 3 3. Remove the three screws from the lower backplane, as shown in Figure 2. Upper Backplane Lower Backplane 4. Using a .25-inch hex nut driver, install the three standoffs into the holes that held the screws removed in step 3. See Figure 4.
- Page 4 Front View of Support Clip Installation Location Upper Right Hand Corner of Lower Backplane Upper Backplane Lower Backplane 9033011 6C110 Power Bridge Adapter Installation Instructions Side View of Installation Chassis Card Cage Back Panel Chassis Back Panel of Chassis Figure 3 Installing the Support Clip Figure 4 Installing the Standoffs Support Clip Chassis Card Cage...
- Page 5 6. Connect the rear (black) power bridge adapter connectors to the lower backplane connectors of the chassis. Ensure that the connectors are firmly seated together, and the screw holes of the power bridge adapter align with the standoffs installed in step 4 and the support clip installed in step 5. See Figure 5. Lower Backplane Connectors (2) 7.
- Page 6 Align the plastic guide runner of the blank faceplate with the slotted paths on the top and bottom of the opening. Forcing a misaligned blank faceplate into place can damage the chassis backplane. CAUTION 2. With the blank faceplate inserted into the slotted paths, carefully slide the module forward until the front panel of the blank faceplate is flush with the face of the 6C110.
-
Page 7: Getting Help
Getting Help For additional support related to this device or document, contact Cabletron Systems using one of the following methods: World Wide Web Phone Internet mail Login Password To send comments or suggestions concerning this document, contact the Cabletron Systems Technical Writing Department via the following email address: TechWriting@cabletron.com Make sure to include the document Part Number in the email message.
